INSTALLATION CAUTIONS
A.
The screw of armature plate should not be fixed too tight. Proper elasticity should be guaranteed
for the rubber ring so that the armature plate can adjust itself to the appropriate position.
B.
Check the jumpers' position before connecting. Figure out it represents 12VDC or 24VDC.
C.
Please keep the surface of the lock clean, or the force will be reduced because of the dust, glue or
scotch tape on it.
All content and specifications are subject to change without prior notice
USER GUIDE
280KG MONITORED MAGNETIC LOCK
WBX280S-M
Advertisement
Summary of Contents for WBOX Technologies WBX280S-M
- Page 1 USER GUIDE 280KG MONITORED MAGNETIC LOCK WBX280S-M INSTALLATION CAUTIONS The screw of armature plate should not be fixed too tight. Proper elasticity should be guaranteed for the rubber ring so that the armature plate can adjust itself to the appropriate position.
- Page 2 General Installation All content and specifications are subject to change without prior notice...
- Page 3 Brackets Installation Different brackets are available according to different types of doors. For example, narrow door, frameless glass door and inward opening door. I Bracket- For armature plate ZL Bracket- For inward opening door For inward opening door, WBX280ZL bracket is When the door frame is too WBX280AS bracket needed is needed...
- Page 4 Circuit Board Diagram B.24VDC Input(By Changing Jumpers): A.12VDC Input(Default): 1. Check jumpers for 24VDC as above diagram 1. Check jumpers for 12VDC as above diagram 2. Connect the positive(+)lead from a 24VDC power source to V +. 2. Connect the positive(+)lead from a 12VDC power source to V +. 3.
