Summary of Contents for THOMSON Plus 270
-
Page 2: Table Of Contents
Streaming Box Plus 270 4K UHD User Manual Content Safety & Product Information Introduction Streaming Box 3.1. Front Panel 3.2. Rear Panel 3.3. Remote Control Installation 4.1. Packaging Content 4.2. Setup 4.3. Position Your Streaming Device 4.4. Remote Control Pairing 4.5. -
Page 3: Safety & Product Information
1. Safety & Product Information Your device has been carefully checked and packed before shipping. When unpacking it, make sure that all the parts are included and keep the packaging away from children. We recommend that you keep the carton during the warranty period, to keep your device perfectly protected in the event of repair or warranty. -
Page 4: Data Protection
2. Introduction With Google TV™ on the Streaming Box Plus 270, you can enjoy all the entertainment you love — with a little help from Google. Google TV brings movies, shows, and more from all of your subscriptions to one place. Need inspiration? Get curated recommendations and use Google’s powerful search to find shows across 10,000+... -
Page 5: Remote Control
3.3. Remote Control Standby: Quick Standby / Standby / On Press and hold this button to determine the shortcut function of this button. Briefly press the Star button to launch the selected favorite app or to select the input source. Profile Switch: Switches user profiles Microphone: Activates the Google Assistant and the microphone built into the remote control... -
Page 6: Installation
4. Installation 4.1. Packaging Content Streaming Box Installation 2 x AAA Voice remote HDMI Cable Power Adapter instructions Batteries control 4.2. Setup... - Page 7 HDMI POWER DC 12 V, 1.5 A AC 100-240 V 50/60 Hz POWER Optional USB 3.0 If an Internet connection via LAN is not available, the initial installation will prompt you to connect to the Internet via WLAN.
-
Page 8: Position Your Streaming Device
4.3. Position Your Streaming Device At least 12 inches away To ensure the accuracy of Far-field voice control, it is recommended to place the streaming device more than 12 inches away from the TV speakers. Please do not position your streaming device in any closed cabinet. 4.4. -
Page 9: First Installation
You can scan the QR code on the screen to set up your Streaming Box Plus 270 in the Google Home app on your smartphone or tablet. Or you can select “Set up on TV instead” at the bottom of the screen and follow the on-screen instructions. -
Page 10: Profiles
To change the order of your favorite apps, scroll to the end of the “Your apps” row and select “Reorder”. You can also add more apps to this row by selecting “Add apps”. Further down on the For You tab, you can select content that you would like to continue watching. Or browse personalized recommendations from Google to discover new movies and shows based on what you’ve watched and what interests you, so you can quickly find your next favorite. -
Page 11: Apps
5.3. Apps Select the Apps tab at the top of your screen to view all of your installed apps, or search for new apps you would like to install. Note: Some apps work only in your own network. These apps are not open internet services but only in-house solution for several TV sets in the same household. -
Page 12: Settings
6.1. Set your device name In this menu you have the option to select the name of your TV from the list of suggested names. You can also assign a customized name for your THOMSON Streaming Box Plus 270. 6.2. Display and sound In this menu you can configure various picture and function settings. -
Page 13: Google Cast
9. Hey Google-Hand-free voice control The Streaming Box Plus 270 supports the Hey Google function. The Hey Google function can be activated by pressing the microphone button on the remote control or via hands-free microphone, which is installed in the device, and which must first be activated in the Menu Settings >... -
Page 14: Updates
Can my Streaming Box Plus 270 also be used as Yes, the Streaming Box Plus 270 can be used for IPTV. In order to do so, you need to an IPTV box? download a preferred IPTV application. -
Page 15: Specifications
13. Specifications Audio & Video Display resolution: 4K Ultra HD Video resolution: 4Kx2K @ 60 fps, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio decoding: Dolby Digital, Dolby Digital Plus, Dolby Atmos MS12 System & Memory Operating system: Android TV™ OS Chipset: Amlogic S905X4-J CPU: ARM Quad 64-bit Cortex-A55 GPU: ARM Mali-G31 MP2... -
Page 16: General Data
General Data Power supply: AC 100 - 240 V AC ~ 50/60 Hz Input voltage: Power adapter 12 V 1.5 A Power consumption working: max. 18 W Power consumption in standby: 2.2 W Operating temperature: 0 ~ +40 °C Storage temperature: -40 ~ +70 °C Dimensions (W x D x H in mm): 118 x 118 x 43 Weight (in kg): 0.3 14. - Page 17 All rights reserved. ©2024 StreamView GmbH, Franz-Josefs-Kai 1, 1010 Vienna, Austria. This product has been manufactured and sold under the responsibility of StreamView GmbH. THOMSON, and the THOMSON logo are trademarks used under license by StreamView GmbH – further information at www.thomson-brand.com.
