Secure Air MFV User Manual

Active carbon mobile unit
Hide thumbs

Advertisement

Table of Contents

Serial number 000-000000
USER MANUAL
MFV
Active carbon Mobile unit
Motor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFV and is the answer not in the manual?

Questions and answers

Summary of Contents for Secure Air MFV

  • Page 1 Serial number 000-000000 USER MANUAL Active carbon Mobile unit Motor...
  • Page 2 MFV19 user manual INDIX ............................. 1 INTRODUCTION ................Error! Bookmark not defined. Scope of the operating and maintenance manual......Error! Bookmark not defined. Storage of the instruction manual ..........Error! Bookmark not defined. Updating of the Instruction Manual ..........Error! Bookmark not defined. Glossary and pictograms...............
  • Page 3 MFV19 user manual INTRODUCTION Description Scope of the operating and maintenance manual This instruction manual is an integral part of the machine and has the purpose of providing all the necessary information for the following purposes:  Raise the awareness of operators as regards safety matters; ...
  • Page 4 MFV19 user manual INTRODUCTION Description Storage of the instruction manual The instruction manual must be kept safely and must be handed over to new owners in case of sale throughout the lifecycle of the machine. To help preserve the manual in good condition it must be handled with care and with clean hands, and it must not be placed on dirty surfaces.
  • Page 5 MFV19 user manual INTRODUCTION Description Glossary and pictograms This paragraph lists some terms which are not commonly used or with a meaning different from the common one. The meaning of the abbreviations and pictograms used is described below. The abbreviations and pictograms are used to indicate operator qualifications and state of the machine;...

  • Page 6: Residual Risk

    MFV19 user manual STATE OF THE MACHINE The state of the machine includes operating modes, for example automatic running mode, jog command, stop, etc., the condition of the safety devices on the machines such as protection devices provided (or not provided), pressed emergency button, type of isolation from energy sources, etc.

  • Page 7: Safety Signs

    MFV19 user manual PICTOGRAMS CONCERNING THE STATE OF THE MACHINE Pictograms inside a square/rectangle provide INFORMATION. Symbol Description Machine off: with hydraulic or electric power supply disconnected. Machine on: with hydraulic or electric power supply connected and in safe stop condition with open mobile protective devices (specifying which);...

  • Page 8: General Information

    Safety helmets must be worn Table 0 - 4.3 GENERAL INFORMATION Description Manufacturer’s identification data MANUFACTURER SECURE AIR® by GAMMA IMPIANTI S.r.l. REGISTERED OFFICE – ADMINISTRATIVE OFFICE VIA STROPPIANA,15 10071 BORGARO T.SE (TO) ITALY TEL +39 0114502031 – FAX +39 0114703927 E-mail: info@secureair.it ©| Gamma impianti S.r.l.
  • Page 9 MFV19 user manual GENERAL INFORMATION Description Machine identification data and plates Each machine is identified by an EC plate on which the reference data of the same are indelibly indicated. For any communication with the manufacturer or service centers, always mention these references. The position of the plate on the Machine may vary .

  • Page 10: Ec Declaration Of Conformity

    MFV19 user manual EC DECLARATION OF CONFORMITY (All. IIA DIR. 2006/42/CE) MANUFACTURER Gamma impianti S.r.l. Company Via Stroppiana, 15 10071 Address Postal code Province Borgaro T.se Italia City Nation DECLARES THAT THE MACHINE Mobile purifier for suction retouches and fumes Decription Model 000-000000...
  • Page 11 MFV19 user manual GENERAL INFORMATION OF THE MACHINE Description General description of the machine The mobile unit is the ideal solution for vacuuming and filtering the fumes that develop during paint, roller or can retouches or during other operations that produce CVO-SOV fumes and/or bad odours. To avoid its diffusion in the working environment, the sucked air is adequately filtered and recycled inside the working area with consequent energy savings.

  • Page 12: Initial Start-Up

    MFV19 user manual GENERAL INFORMATION OF THE MACHINE Description Technical data of the unit Power supply voltage Network frequency Installed power Maximum suction 2500 capacity Negative pressure 1400 extractor Machine air flow-rate 1500 G4 70% Filtration efficiency Acc. EN 779 Carb attivo (G2-G4)

  • Page 13: Machine Maintenance

    MFV19 user manual INITIAL START-UP Description Electrical panel The machine is equipped with an electrical panel positioned on the front side GREEN LIGHT ON : UNIT ON HOUR COUNTER: FOR FILTERS REPLACEMENT REGISTER INITIAL START-UP Description Use of suction arm (if applicable) Depending on the model, the machine can be equipped with one or two suction arms, which must be assembled separately using the instructions in the package.
  • Page 14 MFV19 user manual ATTENTION TO THE WEIGHT OF THE HIGH CARBON MODULE: THIS CHANGE MUST BE DO WITH TWO PEOPLE OPENING AND CLOSURE FILTERS It is recommended to replace at least 1 time a year all the filters present in the equipment to maintain the maximum performance of both suction and filtration.
  • Page 15 MFV19 user manual MACHINE MAINTENANCE Description Detail of the filters in the rigid pocket purifier 1- FIRST STAGE FILTRATION Corrugated filter cell Filter code: ACCRICFILTMFV1 Filter material Polyester fiber Regeneratability Flame behaviour DIN 53438 F1 2- SECOND STAGE FILTRATION Metal container with activated carbon Filter code: ACCRICFILTMFV2 Type of carbons Vegetable,...
  • Page 16 MFV19 user manual MACHINE MAINTENANCE Description Malfunctions FAULT TYPE CAUSE ACTION Check the motor dataplate and the mains Low voltage supply power supply STARTING PROBLEMS Check the connection of the plug and/or No power supply socket No power supply Check the connection of the plug and/or socket Motor burn out Replace extractor fan...
  • Page 17 MFV19 user manual MACHINE MAINTENANCE Description Maintenance programme ROUTINE CHECKS TYPE OF CHECK METHOD FREQUENCY DATE OF CHECK AND NAME OF MAINTENANCE OPERATOR OR MAINTENANCE GENERAL CHECK OF VISUAL DAILY THE CONDITION OF THE AIR CLEANER CLEANING MANUAL See note A CHECK OF THE VISUAL 150 HOURS...

  • Page 18: Operator's Notes

    MFV19 user manual OPERATOR’S NOTES Description Details of maintenance operations The following table must be filled in by a qualified technician authorised by GAMMA IMPIANTI SRL. It is of fundamental importance to keep these notes updated to keep track of the problems and maintenance carried out;...
  • Page 19 MFV19 user manual By GAMMA IMPIANTI s.r.l Via Stroppiana n° 15 10071 Borgaro T.se (To) - Italy Tel. +39 011 4502031 Fax +39 011 4703927 P.IVA IT05898600019 E-mail: info@secureair.it Web: www.secureair.it ©| Gamma impianti S.r.l. | all rights reserved reproduction of this manual, even partial, is forbidden...
