HMS Anybus Wireless Bolt 5G NV200 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENGLISH
®
™
Anybus
Wireless Bolt 5G
USER MANUAL
SCM-1202-232
Version 1.0
Publication date 2024-07-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Anybus Wireless Bolt 5G NV200 and is the answer not in the manual?

Questions and answers

Summary of Contents for HMS Anybus Wireless Bolt 5G NV200

  • Page 1 ENGLISH ® ™ Anybus Wireless Bolt 5G USER MANUAL SCM-1202-232 Version 1.0 Publication date 2024-07-09...
  • Page 2 The information in this document shall therefore not be construed as a commitment on the part of HMS Networks and is subject to change without notice. HMS Networks makes no commitment to update or keep current the information in this document.

  • Page 3: Table Of Contents

    ® ™ Anybus Wireless Bolt 5G Table of Contents 1. Preface ..........................1 1.1. About This Document ......................1 1.2. Document Conventions ..................... 1 1.3. Trademarks ........................2 2. Safety ............................ 3 2.1. General Safety ......................... 3 2.2. Intended Use ........................3 3.
  • Page 4 ® ™ Anybus Wireless Bolt 5G 6.2. Bolt 5G LED Status Indication ..................... 42 6.3. Ethernet RJ45 LED Status Indication ..................43 7. Maintenance ......................... 44 7.1. Time & Date Settings ......................44 7.1.1. Set Time ......................... 44 7.1.2. Network Time Protocol (NTP) Synchronization ............... 45 7.1.3.

  • Page 5: Preface

    This document describes how to install and configure Anybus Wireless Bolt 5G For additional documentation and software downloads, FAQs, troubleshooting guides and technical support, please visit www.hms-networks.com. 1.2. Document Conventions Lists Numbered lists indicate tasks that should be carried out in sequence:...

  • Page 6: Information Symbols

    Additional information which may facilitate installation and/or operation. Helpful advice and suggestions. 1.3. Trademarks ® ™ Anybus Wireless Bolt 5G is a trademarks of HMS Networks AB. All other trademarks are the property of their respective holders. Page 2 of 69 SCM-1202-232 Version 1.0...

  • Page 7: Safety

    ® ™ Safety Anybus Wireless Bolt 5G 2. Safety 2.1. General Safety CAUTION Ensure that the power supply is turned off before connecting it to the equipment. CAUTION To ensure proper functioning and electrical safety, connect the Bolt 5G Functional Earth (FE) connection to earth.

  • Page 8: Preparation

    Preparation 3. Preparation 3.1. Support and Resources For additional documentation, software downloads and technical support, please visit www.hms-networks.com. 3.2. Network Environment Ensure that you have all the necessary information about the capabilities and restrictions of your local network environment before installation.

  • Page 9: Firewall And Routing

    ® ™ Firewall and Routing Anybus Wireless Bolt 5G 3.6. Firewall and Routing There are routing options set for the system. By default, the firewall allows routing of: • Outgoing traffic for TCP, UDP and ICMP (for IPv4 only). • Incoming traffic for already established connections only. For other possible configurations, see NAT/Passthrough Settings.

  • Page 10: Installation

    ® ™ Anybus Wireless Bolt 5G Installation 4. Installation 4.1. Install SIM Card NOTE The supported SIM card type is Nano SIM (4FF). Figure 2. Insert SIM card To connect Bolt 5G to a cellular data network, install a cellular SIM card: Remove the SIM card holder plug.

  • Page 11: Installation Drawing

    ® ™ Installation Drawing Anybus Wireless Bolt 5G 4.2. Installation Drawing All measurements are in mm. Figure 3. Bolt 5G installation drawing SCM-1202-232 Version 1.0 Page 7 of 69...

  • Page 12: Surface Mounting

    ® ™ Anybus Wireless Bolt 5G Surface Mounting 4.3. Surface Mounting Before You Begin Placement Considerations For information about placement considerations, see Required Distance Between Devices (page Mounting Considerations • Mount the Bolt 5G on a machine or cabinet. • For information about surface heat considerations, see Surface Heat Considerations (page •...
  • Page 13 ® ™ Surface Mounting Anybus Wireless Bolt 5G Place the Bolt 5G housing sealing ring in its groove. In the mounting surface, drill a mounting hole with the size Ø M50 (50,5 mm). Option: To fix the Bolt 5G position, see To Lock the Bolt 5G Position (page 11).
  • Page 14 ® ™ Anybus Wireless Bolt 5G Surface Mounting Screw the Bolt 5G lock nut into place and tighten it. Tightening torque: 5 Nm ±10 % IMPORTANT To keep the Bolt 5G sealed against dirt and moisture, make sure the housing sealing ring is properly seated in its groove before tightening the lock nut.

  • Page 15: To Lock The Bolt 5G Position

    ® ™ To Lock the Bolt 5G Position Anybus Wireless Bolt 5G 4.4. To Lock the Bolt 5G Position The complete surface mounting procedure is described in, Surface Mounting (page Figure 4. Bolt 5G steering hole for locking screw To prevent the Bolt 5G from being rotated, use a screw and the Bolt 5G steering hole to fix the position. Before You Begin Locking screw dimension: M2.5 (2,5 mm) NOTE...
  • Page 16 ® ™ Anybus Wireless Bolt 5G To Lock the Bolt 5G Position Procedure Drill a mounting hole with the size Ø M50 (50,5 mm) for the Bolt 5G and a hole with the size Ø 3 mm for the locking screw. All measurements are in mm.
  • Page 17 ® ™ To Lock the Bolt 5G Position Anybus Wireless Bolt 5G Place the Bolt 5G in the surface mounting hole and fit the locking screw into the Bolt 5G steering hole. SCM-1202-232 Version 1.0 Page 13 of 69...

  • Page 18: Signal And Power Connector Cabling

    ® ™ Anybus Wireless Bolt 5G Signal and Power Connector Cabling 4.5. Signal and Power Connector Cabling 4.5.1. Signal and Power Connector Pinout An 18-pin connector cable assembly with individual wire leads is included with the product. Table 1. 18-Pin Signal and Power Connector Function Color 1-14, 16...

  • Page 19: Connect To Dc Power

    ® ™ Connect to DC Power Anybus Wireless Bolt 5G 4.6. Connect to DC Power Option when you use DC Power. To use Power over Ethernet (PoE), see Connect to Power Over Ethernet (PoE). Before You Begin CAUTION To ensure proper functioning and electrical safety, connect the Bolt 5G Functional Earth (FE) connection to earth.
  • Page 20 ® ™ Anybus Wireless Bolt 5G Connect to DC Power Procedure Connect to DC Power and Functional Earth (FE) Figure 7. DC Power and Functional Earth (FE) Connect Bolt 5G Power connector to Functional Earth (FE). Connect Bolt 5G Power connector to a power supply. Page 16 of 69 SCM-1202-232 Version 1.0...

  • Page 21: Connect To Power Over Ethernet (Poe)

    ® ™ Connect to Power Over Ethernet (PoE) Anybus Wireless Bolt 5G 4.7. Connect to Power Over Ethernet (PoE) Option when you use Power over Ethernet (PoE). To use DC Power, see Connect to DC Power (page 15). Before You Begin CAUTION To ensure proper functioning and electrical safety, connect the Bolt 5G Functional Earth (FE) connection to earth.
  • Page 22 ® ™ Anybus Wireless Bolt 5G Connect to Power Over Ethernet (PoE) Procedure Figure 9. Connect to Power Over Ethernet (PoE) Connect the Bolt 5G to Functional Earth (FE). Use the Bolt 5G steering hole to connect the functional earth connection cable to the Bolt 5G. Functional Earth (FE) Wire Screw Placement (page 17) To Lock the Bolt 5G Position (page 11).

  • Page 23: Connect To Ethernet

    ® ™ Connect to Ethernet Anybus Wireless Bolt 5G 4.8. Connect to Ethernet Figure 10. Connect to Ethernet Connect the Bolt 5G to Ethernet network. SCM-1202-232 Version 1.0 Page 19 of 69...

  • Page 24: Frequency Bands And Power Level

    ® ™ Anybus Wireless Bolt 5G Frequency Bands and Power Level 4.9. Frequency Bands and Power Level Standard Mode Bands Frequency (MHz) Transmit Power UMTS (Universal Mobile Wideband Code Division Multiple Access (WCDMA) 1920 – 1980 25 dBm Telecommunications 1850 – 1910 System) 1710 –...
  • Page 25 ® ™ Frequency Bands and Power Level Anybus Wireless Bolt 5G Standard Mode Bands Frequency (MHz) Transmit Power 814 – 849 703 – 748 2305 – 2315 3550 – 3700 1710 – 1780 1695 – 1710 663 – 698 698 – 716 2570 –...

  • Page 26: Configuration

    ® ™ Anybus Wireless Bolt 5G Configuration 5. Configuration 5.1. Connect to Configure 5.1.1. Connect to PC and DC Power Option if you use DC Power. When configuring Bolt 5G it must be connected to a PC. Figure 11. Connect to PC and Power Connect the Bolt 5G Ethernet port to your PC.

  • Page 27: Access The Built-In Web Interface

    ® ™ Access the Built-In Web Interface Anybus Wireless Bolt 5G 5.2. Access the Built-In Web Interface 5.2.1. Required IP Address Settings NOTE The Bolt 5G default IP address is 192.168.0.1 and the subnet mask is 255.255.255.0. On the PC accessing the Bolt 5G built-in web interface, set a static IP address within the same IP address range as the Bolt 5G IP address.

  • Page 28: Login To The Built-In Web Interface

    ® ™ Anybus Wireless Bolt 5G Access the Built-In Web Interface 5.2.2. Login to the Built-In Web Interface The Bolt 5G built-in web interface can be accessed from a standard web browser. Before You Begin IMPORTANT For cybersecurity reasons, you are prompted to change the password at first login using the Bolt 5G factory default password.
  • Page 29 ® ™ Access the Built-In Web Interface Anybus Wireless Bolt 5G Figure 15. Home page SCM-1202-232 Version 1.0 Page 25 of 69...

  • Page 30: Bolt 5G Built-In Web Interface Overview

    ® ™ Anybus Wireless Bolt 5G Bolt 5G Built-In Web Interface Overview 5.3. Bolt 5G Built-In Web Interface Overview Use the Bolt 5G built-in web interface to configure, maintain and troubleshoot the Bolt 5G. Figure 16. The Bolt 5G built-in web interface Home page Table 2.

  • Page 31: Factory Default Settings

    ® ™ Factory Default Settings Anybus Wireless Bolt 5G 5.4. Factory Default Settings Bolt 5G comes with the following factory default settings for the Ethernet interface. Table 3. Bolt 5G Ethernet interface default settings IP Assignment Static IP Address 192.168.0.1 Subnet Mask 255.255.255.0 Internal DHCP Server...

  • Page 32: Setup Virtual Tunnel

    ® ™ Anybus Wireless Bolt 5G Setup Virtual Tunnel 5.5. Setup Virtual Tunnel In this example, a virtual tunnel is established between a Bolt 5G and a Tunnel Gateway to facilitate communication between a PLC and devices within a subnetwork. Figure 17.
  • Page 33 ® ™ Setup Virtual Tunnel Anybus Wireless Bolt 5G Bolt 5G Configuration Figure 18. Connect the Bolt 5G to your PC and to power Procedure Install a SIM card in the Bolt 5G SIM card holder. Install SIM Card (page Connect the Bolt 5G Ethernet port to your PC.

  • Page 34: Verify Connection

    ® ™ Anybus Wireless Bolt 5G Setup Virtual Tunnel Installation Figure 19. Connect the Bolt 5G Procedure Connect the Bolt 5G to power and Functional Earth (FE), see Installation (page Connect your Ethernet Device(s) to the Bolt 5G. Verify Connection Figure 20.

  • Page 35: Cellular Settings

    ® ™ Cellular Settings Anybus Wireless Bolt 5G 5.6. Cellular Settings On the Cellular page, configure the operator and SIM card settings, as well as the network settings for the 5G core network that the Bolt 5G is going to be connected to. Before You Begin When you are going to connect Bolt 5G to a cellular network, ensure that you have installed a SIM card in the Bolt 5G SIM card holder.

  • Page 36: Operator Selection

    ® ™ Anybus Wireless Bolt 5G Cellular Settings 5.6.2. Operator Selection Figure 22. Cellular page, Operator Selection Automatic By default, the Operator is set to Automatic. The mobile operator is assigned automatically. No Roaming When No roaming is enabled, the Mobile Country Code (MCC) and Mobile Network Code (MNC) of the SIM card installed in the Bolt 5G are automatically selected.

  • Page 37: Sim Settings

    ® ™ Cellular Settings Anybus Wireless Bolt 5G Procedure Figure 23. Operator settings example In the Operator drop down menu, select Manually. In the MCC field, enter the MCC code. In the MNC field, enter the MNC code. 5.6.3. SIM Settings Activate SIM Card Figure 24.

  • Page 38: Apn Settings

    ® ™ Anybus Wireless Bolt 5G Cellular Settings 5.6.4. APN Settings APN Assignment Automatic Figure 26. Cellular page, APN Assignment Automatic By default, APN assignment is set to Automatic. The APN (Access Point Name) is assigned automatically. APN Assignment Manually Ensure that you have the APN supplied by your carrier available.
  • Page 39 ® ™ Cellular Settings Anybus Wireless Bolt 5G APN Authorization By default, APN authorization is set to No authorization. When enabled, the Password Authentication Protocol (PAP) authentication method is used. NOTE APN authorization is to be configured only if your carrier has setup APN (Access Point Name) with username and password.

  • Page 40: Tunnel Settings

    ® ™ Anybus Wireless Bolt 5G Tunnel Settings 5.7. Tunnel Settings Before You Begin NOTE You can add up to 8 tunnels. Procedure On the Tunnel page, select the desired tunnel type: Wireless Bolt 5G, Tunnel Gateway or Other device from the Add tunnel to ...
  • Page 41 ® ™ Tunnel Settings Anybus Wireless Bolt 5G Select the tunnel and configure the Tunnel properties. Figure 30. Tunnel properties panel Setting Value Description VXLAN ID 0-16777215 Virtual Extensible LAN (VXLAN) is used to create a layer 2 network tunnel over the regular layer 3 network.

  • Page 42: Ethernet Settings

    ® ™ Anybus Wireless Bolt 5G Ethernet Settings 5.8. Ethernet Settings IMPORTANT By default, the Bolt 5G internal DHCP server is enabled. To avoid interference, keep only one DHCP server enabled on the network. By default, DHCP server is enabled. This means that the IP address settings are set automatically by the Bolt 5G internal DHCP server.

  • Page 43: Nat Settings

    ® ™ NAT Settings Anybus Wireless Bolt 5G 5.9. NAT Settings Figure 32. NAT page, Incoming traffic menu By default, NAT (Network Address Translation) is enabled, and 1:N is selected in the Incoming traffic drop-down menu. When 1:N is enabled: •...

  • Page 44: Verify Operation

    ® ™ Anybus Wireless Bolt 5G Verify Operation 6. Verify Operation 6.1. Bolt 5G Status Monitor Figure 33. Home page Tunnel Status View the connection status for the tunnel(s). Cellular Status Overview of connection status, signal strength and current cellular settings. Ethernet Status View the Ethernet network communication status and IP settings.

  • Page 45: Status Symbols

    ® ™ Bolt 5G Status Monitor Anybus Wireless Bolt 5G Status Symbols Symbol Description Internal error has occurred, and operation cannot be guaranteed. Examples for Run Time System: • Could not initialize WLAN device management control: Could not add device management data point wlan-station/rssi: Endpoint receive operation timed out (-32603).

  • Page 46: Bolt 5G Led Status Indication

    ® ™ Anybus Wireless Bolt 5G Bolt 5G LED Status Indication 6.2. Bolt 5G LED Status Indication Figure 34. Bolt 5G LED Indicators LED A LED B LED C LED D LED E LED F LED Status Cellular Status Power SPE RX LED SPE TX LED IO-Link Activity LED...

  • Page 47: Ethernet Rj45 Led Status Indication

    ® ™ Ethernet RJ45 LED Status Indication Anybus Wireless Bolt 5G 6.3. Ethernet RJ45 LED Status Indication Figure 35. RJ45 Ethernet LED indicators LED A – LINK/ACTIVITY Function No Ethernet link Yellow Ethernet link established Yellow, flashing 10/100/1000 Mbps Ethernet link activity LED B –...

  • Page 48: Maintenance

    ® ™ Anybus Wireless Bolt 5G Maintenance 7. Maintenance 7.1. Time & Date Settings 7.1.1. Set Time Figure 36. Time & date page, Set time You can set the current browser time and date in the Bolt 5G. On the Time & date page, click Set time. Page 44 of 69 SCM-1202-232 Version 1.0...

  • Page 49: Network Time Protocol (Ntp) Synchronization

    ® ™ Time & Date Settings Anybus Wireless Bolt 5G 7.1.2. Network Time Protocol (NTP) Synchronization You can use the Network Time Protocol (NTP) to synchronize with computer clock time sources on a network. Figure 37. Time & date page, NTP synchronization enabled By default, NTP synchronization is disabled.

  • Page 50: Use Timezone Settings

    ® ™ Anybus Wireless Bolt 5G Time & Date Settings 7.1.3. Use Timezone Settings You can set the time zone for where the Bolt 5G is installed. Figure 38. Time & date page, Use timezone To set the Use timezone: On the Time &...

  • Page 51: Configuration File Handling

    ® ™ Configuration File Handling Anybus Wireless Bolt 5G 7.2. Configuration File Handling 7.2.1. Export Configuration You can export the current configuration, in order to store the configuration file as a backup or to import and use the same settings to configure additional Bolt 5G units. Figure 39.

  • Page 52: Import Configuration

    ® ™ Anybus Wireless Bolt 5G Configuration File Handling 7.2.2. Import Configuration To configure multiple Bolt 5G units with the same settings, you can import a configuration file. Before You Begin The supported file format is .conf. Procedure Figure 40. System page Import configuration file: On the System page, click Import.

  • Page 53: Revert Configuration

    ® ™ Revert Configuration Anybus Wireless Bolt 5G 7.3. Revert Configuration You can restore all settings in a configuration to the default settings. Figure 41. System page When you want to remove any configuration made in a current session and re-load the configuration from the Bolt 5G.

  • Page 54: Firmware Management

    ® ™ Anybus Wireless Bolt 5G Firmware Management 7.4. Firmware Management 7.4.1. View the Firmware Version On the Support page, you can view the current applied firmware version. Figure 42. Support page, Product information example 7.4.2. Firmware and Configuration Compatibility Compatibility after Firmware Upgrade Current configuration is still compatible after upgrading the firmware.

  • Page 55: Update Firmware

    ® ™ Firmware Management Anybus Wireless Bolt 5G 7.4.4. Update Firmware Before You Begin NOTE If the firmware update process is interrupted or if the power is lost during the update process, the update process will resume as soon as the Bolt 5G is powered on again. Procedure Figure 43.

  • Page 56: Web Server Certificate Settings

    ® ™ Anybus Wireless Bolt 5G Web Server Certificate Settings 7.5. Web Server Certificate Settings Install a web server certificate in the Bolt 5G. Before You Begin NOTE The Web Server Certificate file must contain both Certificate and Private key. NOTE The device certificate must be a Base64 encoded DER certificate.

  • Page 57: Remote Access To Bolt 5G Built-In Web Gui

    ® ™ Remote Access to Bolt 5G Built-In Web GUI Anybus Wireless Bolt 5G Result Figure 45. Example View site information > Connection is secure The web server certificate is uploaded in the web browser. In the web browser View site information, check that the Connection is secure. 7.6.

  • Page 58: Change The Bolt 5G Password

    ® ™ Anybus Wireless Bolt 5G Change the Bolt 5G Password 7.7. Change the Bolt 5G Password IMPORTANT For cybersecurity reasons, you are prompted to change the password at first login using the Bolt 5G factory default password. You are redirected to the Change password page, see Change the Bolt 5G Password (page 54).

  • Page 59: Troubleshooting

    Wireless Bolt 5G 8. Troubleshooting 8.1. Find the Bolt 5G IP Address You can use the software application HMS IPconfig to find the Bolt 5G IP address. Example 2. Device IP address detected in HMS IPconfig Figure 49. HMS IPconfig To download the installation files, please visit www.hms-networks.com...

  • Page 60: Diagnostics

    ® ™ Anybus Wireless Bolt 5G Diagnostics 8.2. Diagnostics 8.2.1. Event Log Figure 50. Event log page example To export the log data, click Export. An Excel XLSX file with the data is downloaded to your PC. How To Analyze the Information The log follows the FIFO principle, first in and first out.

  • Page 61: Commands

    ® ™ Diagnostics Anybus Wireless Bolt 5G 8.2.2. Commands On the Commands page you find tools for network troubleshooting and management. Before You Begin NOTE If Bolt 5G is installed on a private cellular network, the methods are limited according to the restrictions of the private network.
  • Page 62 ® ™ Anybus Wireless Bolt 5G Diagnostics Procedure Figure 51. Commands page From the Command drop-down menu, select a command type: Ping, Wget, or Nslookup. Enter a Target. • Ping: Enter the IP address (IPv4) 8.8.8.8 or 8.8.4.4. • Wget: Enter the URL of the file or directory you want to download or synchronize. •...
  • Page 63 ® ™ Diagnostics Anybus Wireless Bolt 5G Example 4. Nslookup response message from target webpage Example 5. Wget response message from target Speedtest SCM-1202-232 Version 1.0 Page 59 of 69...
  • Page 64 ® ™ Anybus Wireless Bolt 5G Diagnostics Example 6. Wget response message from target webpage Response message with elapsed time between the request being sent to the Target and the response being returned. Page 60 of 69 SCM-1202-232 Version 1.0...

  • Page 65: History Monitor

    ® ™ Diagnostics Anybus Wireless Bolt 5G 8.2.3. History Monitor On the History monitor page, you can view the status over time for the Connection State, Signal Strength, and Amplifier Temperature. Figure 52. History monitor page SCM-1202-232 Version 1.0 Page 61 of 69...

  • Page 66: Reboot Using The Built-In Web Interface

    ® ™ Anybus Wireless Bolt 5G Reboot Using the Built-In Web Interface 8.3. Reboot Using the Built-In Web Interface Before You Begin During reboot, the Bolt 5G is temporarily unavailable for approximately two minutes. Procedure Ensure that the Bolt 5G is powered on and running. Figure 53.
  • Page 67 ® ™ Reboot Using the Built-In Web Interface Anybus Wireless Bolt 5G To confirm the reboot, click Reboot. Figure 55. Confirm reboot Result You are logged out of the Bolt 5G built-in web interface and redirected to the login page. SCM-1202-232 Version 1.0 Page 63 of 69...

  • Page 68: Reboot Using The Reset Button

    ® ™ Anybus Wireless Bolt 5G Reboot Using the Reset Button 8.4. Reboot Using the Reset Button Before You Begin During reboot, the Bolt 5G is temporarily unavailable for approximately two minutes. Procedure To reboot the Bolt 5G: Ensure that the Bolt 5G is powered on. Figure 56.
  • Page 69 ® ™ Reboot Using the Reset Button Anybus Wireless Bolt 5G When the LED status indicators have flashed 3 times, release the Reset button, and wait while the Bolt 5G reboots. Figure 58. Release Reset button after the LED indicators have flashed 3 times Result You are logged out of the Bolt 5G built-in web interface and redirected to the login page.

  • Page 70: Reset Using The Built-In Web Interface

    ® ™ Anybus Wireless Bolt 5G Reset Using the Built-In Web Interface 8.5. Reset Using the Built-In Web Interface Procedure Ensure that the Bolt 5G is powered on and running. Figure 59. Power on the Bolt 5G Log in to the Bolt 5G built-in web interface. On the System page, click Factory default reset.
  • Page 71 ® ™ Reset Using the Built-In Web Interface Anybus Wireless Bolt 5G To confirm the factory default reset, click Reset. Figure 61. Confirm factory default reset Result You are logged out of the Bolt 5G built-in web interface and redirected to the login page. When the Bolt 5G has successfully rebooted, the Bolt 5G configuration is reset to the factory default configuration.

  • Page 72: Reset Using The Reset Button

    ® ™ Anybus Wireless Bolt 5G Reset Using the Reset Button 8.6. Reset Using the Reset Button IMPORTANT Factory Reset will result in the loss of all configuration settings and logs. Ensure that the Bolt 5G is powered on and running. Figure 62.

  • Page 73: Technical Data

    Anybus Wireless Bolt 5G 9. Technical Data 9.1. Technical Specifications Additional technical data and information related to the installation and use of this product can be found at www.hms-networks.com. Model identification NV200 Communication connector RJ45 Ethernet 10/100/1000 Mbit/s, PoE Signal and power connector...
