AAFIRST Jazz 1000 Operating Instructions Manual

Operating instructions for the contactless
Installation
This product should be installed by a suitably qualified professional from the water industry. Please refer to the product manual for further instructions.
Operating instructions
1. Green power LED indicates power is on.
2. Orange LED will light up during dispensing.
3. To activate dispensing place your hand in front of the sensor <4cm.
4. To stop dispensing remove your hand.
5. This unit is programmed to allow a maximum dispense time of 6 seconds per dispense.
6. If you require more than 6 seconds of water simply, remove your hand and reactivate the sensor as per step 3.
7. In the event of a malfunction turn the power off and contact your supplier.
8. Hi-visibility clothing may activate dispensing when in proximity <1m.
WCPC88CL2
WCPC88CL2 / WCPCT88CL2
WCPCT88CL2
Power (1)
Dispensing (2)
Sensor (3)
