CLEANING SOLENOID VALVE
1.
Unscrew the screws like the picture
MBSM04
ELECTRONIC MIXER TAP
2. Extract the rubber membrane.
3. Check if there are impurities and clean.
4. Clean the holes on the rubber membrane.
POWER SUPPLY : 4x1,5V batteries AA
SOLENOID VALVE TECHNICAL DRAWING
TECHNICAL DATA – INSTRUCTION FOR THE ASSEMBLAGE – PRECAUTIONS FOR USE
G1/2
SW23
G1/2
Advertisement
Summary of Contents for GGMgastro MBSM04
- Page 1 CLEANING SOLENOID VALVE Unscrew the screws like the picture MBSM04 ELECTRONIC MIXER TAP 2. Extract the rubber membrane. 3. Check if there are impurities and clean. 4. Clean the holes on the rubber membrane. POWER SUPPLY : 4x1,5V batteries AA SOLENOID VALVE TECHNICAL DRAWING TECHNICAL DATA –...
- Page 2 INFORMATIONS FOR THE USER FUNCTIONING: The infrared sensor (A) identifies the presence of the hands and the valve begins to provide the water till the sensor will no more detect the hands in front of the sensor SPECIFICATIONS or until the expiration of the maximum time of closing (VANDAL PROOF SYSTEM). If the infrared system detects an object for 5 minutes, the system cut off the water POWER SUPPLY Alkaline batteries (4x1,5V AA)
