MotoCrane RADICAL L/S Kit Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RADICAL L/S Kit Operation Manual v1.0
SEPTEMBER 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RADICAL L/S Kit and is the answer not in the manual?

Questions and answers

Summary of Contents for MotoCrane RADICAL L/S Kit

  • Page 1 RADICAL L/S Kit Operation Manual v1.0 SEPTEMBER 2022...

  • Page 2: Safety Signal Words

    ● The terms IMPORTANT and NOTE are also used to describe ideas for better and more e cient use of the RADICAL L/S Kit.

  • Page 3: Table Of Contents

    IMPORTANT: Restricted Use Statement Disclaimer and Limitations of Liability Limited Warranty Intellectual Property Intended Use of RADICAL L/S Kit Parts of the RADICAL L/S Kit RADICAL L/S Kit System Overview Installing RADICAL L/S Kit Components RADICAL L/S Kit Weight Chart...

  • Page 4: Important Product And Safety Instructions

    IMPORTANT: Restricted Use Statement The RADICAL L/S Kit must only be used by trained operators 18 years of age or older. Only appropriate motor vehicles driven on a closed course with paved or finished surfaces (for example, asphalt, concrete, or tarmac) or moderate off-road (for example, gravel or dirt roads) conditions may be used.

  • Page 5: Disclaimer And Limitations Of Liability

    RADICAL L/S Kit, and therefore no liability shall be assumed or accepted by MotoCrane, LLC for any resulting damage, death, or injury incurred directly or indirectly from the use of the RADICAL L/S Kit. By the act of use, setup or assembly, the user accepts all resulting liability.

  • Page 6: Intended Use Of Radical L/S Kit

    Intended Use of RADICAL L/S Kit The L/S Kit allows RADICAL w/ Heavylift to operate in 2 new modes “Long” and “Short”: Long Mode extends arm reach by 2ft for a total reach of 14ft with a rated payload capacity of 35lbs.

  • Page 7: Parts Of The Radical L/S Kit

    Parts of the RADICAL L/S Kit RADICAL L/S Kit System Overview...

  • Page 8: Installing Radical L/S Kit Components

    Installing RADICAL L/S Kit Components SHORT MODE Installation for Short Mode should occur after RADICAL is assembled up to the point of the Fulcrum with the Rear Boom attached, the Heavylift Drive Mount and Passive Mount installed, as well as Heavylift End Brace Boom Mounts installed to the Front and Rear booms.
  • Page 9 3. Attach a L/S Kit Lateral Brace to the Passive Mount and Center Brace Boom Mount using 2X SHCS M8. Make sure the clip receivers are hooked over the SHCS M4 fastener heads before letting go. Apply appropriate torque to the fasteners. 4.
  • Page 10 5. Attach the End Brace to the L/S Kit Lateral Brace and End Brace Boom Mount using 2x SHCS M8. Apply appropriate torque to the fasteners. 6. Repeat step 3, 4, & 5 on the other side. Loosen the mounts to make slight adjustments if necessary.

  • Page 11: Long Mode

    LONG MODE Installation for Long Mode should occur after RADICAL is assembled up to the point of the Fulcrum with the Rear Boom attached, the Heavylift Drive Mount and Passive Mount installed, as well as Heavylift End Brace Boom Mounts installed to the Front and Rear booms.
  • Page 12 3. Install the Front Boom to the Middle Boom by securing the clip receiver over the Middle Boom clip. Install the x2 SHCS M12 fasteners to the top flange of the boom and then install both Center Brace Boom Mounts to the Front Boom plate using 2X SHCS M12 on each side.
  • Page 13 5. Install an L/S Kit 14’ Mode adapter to the L/S Kit Lateral Brace using 2X SHCS M8, and apply appropriate torque to the fasteners. 6. Install a Heavylift Center Brace to the L/S Kit Adapter and Center Brace Boom Mount using 2X SHCS M8.
  • Page 14 7. Attach an End Brace to the Passive Mount and End Brace Boom Mount using 2x SHCS M8. Apply appropriate torque to the fasteners. 8. Attach an End Brace to the Center Brace and End Brace Boom Mount using 2x SHCS M8.

  • Page 15: Radical L/S Kit Weight Chart

    RADICAL L/S Kit Weight Chart Start by measuring the All-Up Weight (AUW) of the payload, then use the chart below to determine how much counterweight (CW) should first be installed before mounting the payload. “Payload” includes everything hanging from the RADICAL Isolator including AVM’ s like Tranquilizer, stabilized head, camera and accessories.

  • Page 16: Known Hazards

    RADICAL L/S Kit. This is not exhaustive, but represents some common hazards to watch out for. ● RADICAL L/S Kit mounting. Make sure the RADICAL L/S Kit is secured and does not shift around during operation. All fasteners must be tight and secured, as per the setup instructions.

  • Page 17: Weather & Water

    Weather & Water RADICAL L/S Kit parts are weather resistant. After using RADICAL L/S Kit in wet or dusty conditions, wipe all components down with a soft dry cloth. Revision History Revision Date Description September 2022 Initial Release MotoCrane Technical Support support@motocrane.com...
