Summary of Contents for EVZEN ELITE AVENZOR PRO EVZ5
- Page 1 ® ELITE AVENZOR EVZ5 Wireless Controller PS5 PRO CONTROLLER v1.3 Instruction Manual ACUH-ZCT2B EVZ5...
-
Page 2: Control Panel
Access the Control Panel To access the control panel, first remove the cover with the Evzen logo using the screwdriver provided in the kit. Insert the screwdriver into the designated spot shown in the image below, and gently apply outward pressure. - Page 3 Ajustments Map Remapping System Height Limiter Opening Screws Mechanical Remap System With the panel open, use the screwdriver to adjust the point you want. Turn it until you reach the desired setting. Each paddle offers four adjustment options. Refer to the guide below for details. Guide...
- Page 4 Paddle Pre-travel Adjustment Pre-Travel Pre-travel refers to the distance the paddle travels before activating the command. Reducing this distance makes the response faster, minimizing mechanical delays. However, an excessively short travel may lead to accidental clicks or phantom clicks. Therefore, fine-tuning is essential to ensure that the button maintains optimal sensitivity, providing a precise and efficient user experience.
- Page 5 L1/R1 Pre-travel Adjust The Avenzor has a unique fine-tuning screw for the pre-travel of the R1 and L1 buttons. To access this screw, you need to remove the button cover, following the detailed instructions below. This adjustment allows you to customize the sensitivity of the buttons, ensuring precise performance tailored to your preferences.
- Page 6 L1/R1 Pre-travel Adjust Adjustment With the button cover removed, locate the screw inside the piece. This is the screw that allows you to adjust the pre-travel. Turning the screw clockwise increases the pre-travel. Turning the screw counterclockwise decreases the pre-travel. Reinstall the Button Cover To reinstall the cover on the button, simply position it in its original place and apply slight pressure to snap it back into place.
- Page 7 Changing Paddles To change and adjust the paddles, use the L key provided with the controller. Remove the Control Panel With the cover removed, remove the screws securing the base. Panel Screws Philips Key...
- Page 8 Customize the central paddles You can change the style of the central paddles by swapping them. Remove the central paddles...
- Page 9 Controllers Mounted with Two Paddles Controllers equipped with two factory-mounted paddles include a protec- tive vinyl covering the central paddle slots. To install the four paddles, carefully remove the protective vinyl by pulling one end to fully detach it.
