- Page 1 USER MANUAL MIST...
-
Page 2: Packaging Content
Our vision is the perfect portable sound experience. With clever technical solutions, a joyful design and a sound free from compromise. Thank you for being a part of the ArcSound family! PACKAGING CONTENT The MIST speaker’s packaging includes the following:... -
Page 3: Table Of Contents
TABLE OF CONTENT Safety information............Control panel..............1) Mode selection button........2) Play / Pause button........3) Previous button..........4) Next button........... 5) Decrease volume button....... 6) Increase volume button......... 7) LED indicator..........8) Battery LED indicators........9) On / Off button..........Inputs and Outputs............ -
Page 4: Safety Information
5-40 degrees celci- us. Unplug the product during lightning/thunder storms. Arcsound products are all designed and manufactured to meet great quality standard. Refer all potential servicing of the product to qualified service personnel only. The product... -
Page 5: Control Panel
CONTROL PANEL 1) Mode selection button Press the mode button to select source. The LED indica- tor (7) will change colour depending on the selected source: Blue = Bluetooth, Purple = USB and Red= AUX. 2) Play / Pause button Press the PLAY/PAUSE button once to pause the music, press it again to continue playing the music. -
Page 6: Previous Button
3) Previous button Press the PREVIOUS button once to skip track back- wards to the previous song. When playing music from an AUX source, this button is not usable. 4) Next button Press the NEXT button once to skip track forward to the next song. -
Page 7: Led Indicator
7) LED indicator The LED indicator shows you which mode the speaker is set to, depending on which source has been selected. It will change colour depending on the selected source: Blue = Bluetooth, Purple = USB and Red= AUX. The LED indicator will be flashing blue when it is in Bluetooth mode but is not connected to a source. -
Page 8: Inputs And Outputs
INPUTS AND OUTPUTS 1) AUX (3.5mm) audio input jack Use the included 3.5mm audio cable to connect an exter- nal device via AUX to the speaker through the input jack. Press the ”MODE” button until the LED indicator is red to choose AUX as the sound source. -
Page 9: Usb Storage Device Input Jack
2) USB storage device input jack Insert a USB storage device with playable music files* in to the USB input jack. The speaker will automatically start playing the music. If another source is selected, press the ”MODE” button until the LED indicator is purple to choose USB as the sound source. -
Page 10: Connect Via Bluetooth
DC5V power adaptor. CONNECT VIA BLUETOOTH You can use your Bluetooth-compatible device (tablet, smartphone, computer, etc.) to stream music to the MIST speaker. Press the MODE button until the LED indicator is blue to select Bluetooth as source. If the LED indicator is flashing blue, the speaker is not connected to a Bluetooth-compatible device. -
Page 11: Specifications
SPECIFICATIONS Product model MIST Two-way bass radiator Product type Bluetooth speaker Frequency response 80Hz - 20kHz (+/-3dB) RMS output power Bass radiator 2pcs 90x50 mm Speaker woofer 3" coated paper cone Speaker tweeter 2" coated paper cone Bluetooth version USB decoder... - Page 12 Arcsound is a trademark of Winn Scandinavia AB, Örebro Sweden, www.winnscandinavia.com...
