- Page 1 Angle Polisher Angle Polisher Pulidora Angular AP14008 AP14008M UAP14008 UAP14008-9 UAP14008-91 AP14008-2 AP14008S AP14008-6 AP14008-8 AP14008-9 AP14008-2P ingcoglobal INGCO GLOBAL...
- Page 2 |English The symbols in instruction manual and the label on the tool Double insulated for additional protection. Read the instruction manual before using. CE conformity. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
-
Page 3: General Power Tool Safety Warnings
|English GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 |English a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
- Page 5 |English and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 6 |English Additional Safety Warnings e e f f y y t t n n i i t t s s u u r r t t c c o o i i r r o o l l l l a a r r e e t t a a o o i i...
- Page 7 |English and excessive accumulation of powdered metal may cause electrical hazards. o) Do not operate the power tool near flammable materials. Sparks could ignite these materials. p) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock.
- Page 8 |English e) Always use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different from grinding wheel flanges. f) Do not use worn down wheels from larger power tools.
- Page 9 |English Residual risks Even when the power tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the power tool’s construction and design: a) Health defects resulting from vibration emission if the power tool is being used over longer period of time or not adequately managed and properly maintained.
- Page 10 10|English Technical Data AP14008 AP14008M AP14008-2 AP14008-6 AP14008-8 AP14008S AP14008-9 UAP14008 Model No: AP14008-2P (ISREAL Plug) (BS Plug) (INMENTRO Plug) (SAA Plug) 1400W 1400W Rated voltage 220-240V~50/60Hz 110-120V~50/60Hz No-Ioad speed 1500-4500/min 1500-4500/min Disc diameter 180mm 7˝ Weight 3 .5Kg 3.5Kg...
-
Page 11: Unpacking The Machine
|English Unpacking the Machine Carefully remove the machine from its packaging check that you have remo- ved all p arts from the packaglng Description of the Machine Switch Auxiliary handle 3. Spindle lock Wool polishing bonnet & polishing pad 5. Speed control Using the Machine ~ 50/60H z •... -
Page 12: Exploded View
12|English EXPLODED VIEW AP14008,AP14008M,UAP14008,AP14008-2,AP14008-6,AP14008-8,AP14008-9,AP14008S,AP14008-2P UAP14008-9,UAP14008-91... -
Page 13: Spare Part List
13|English SPARE PART LIST AP14008,AP14008M,UAP14008,AP14008-2,AP14008-6,AP14008-8,AP14008-9,AP14008S,AP14008-2P UAP14008-9,UAP14008-91 No. Exploding view No. Exploding view Bearing Sheath sander plate Bearing Gear shaft Spring ST4*80 screw Rotor Wind Screen Stator 6201 Bearing Brand Reduction Gear Box ST4*10 screw M8*20 screw Right Brush Cover side handle... - Page 14 14|English AP14008 AP14008M AP14008-2 AP14008-6 AP14008-8 AP14008-9 AP14008S UAP14008 Modelo No AP14008-2P (ISREAL Plug) (BS Plug) (SAA Plug) (INMENTRO Plug) Potencia nominal de entrada 1400W 1400W Tensión nominal 220-240V~50/60Hz 110-120V~50/60Hz 1500-4500/min 1500-4500/min Velocidad sin carga Diámetro de la almohadilla 180mm 7˝...
- Page 15 |English Desembalaje de la máquina Retire con cuidado la máquina de su embalaje y compruebe que haya retirado todas las piezas del embalaje. Descripción de la máquina 1. El interruptor de encendido desactiva la energía cuando se le libera 2. Soporte del manillar 3.
- Page 16 |English Mantenimiento Desenchufe la toma de corriente cuando la máquina no esté en uso. La máquina está diseñada para operar sin problemas por un largo período de tiempo con mínimo mantenimiento. La limpieza regular de la máquina con y su uso correcto, prolonga la vida útil de la máquina.
- Page 17 INGCO TOOLS CO.,LIMITED www.ingco.com MADE IN CHINA 0919.V11 AP14008 AP14008M UAP14008 AP14008-2 UAP14008-9 UAP14008-91 AP14008S AP14008-6 AP14008-8 AP14008-9 AP14008-2P...
