- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Fusion Storage Cabinet Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCASTC...
-
Page 2: Important Safety Instructions
Return the accessory to a service center for examination and repair. ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may have a component attached or setting on it. WARNING: Do not use this accessory outdoors. - Page 3 Installation Instructions FCASTC DIMENSIONS CENTER O F MO UNT 66.7 SHELF MOUNTING PATTERN 1.4 - 17.5 [35.0 - 445.0] ADJUSTABLE WIDTH RANGE 10.8 - 28.8 [273.5 - 731.0] ADJUSTABLE CABINET RANGE CABLE COVER UP TO 19.7 [500] 34.2 - 52.2 [ 869.5 - 1327.0]...
- Page 4 FCASTC Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions FCASTC TOOLS REQUIRED FOR INSTALLATION (included) 4 mm (included) 13 mm PARTS Assembled upright extrusion L (1) (as packaged) [Storage panel] H (1) [Storage box] A (1) [Upright extrusion] B (1) [Tube clamp] M (1) [Shelf bracket] C (10) - Page 6 FCASTC Installation Instructions Assembly And Installation Slide two assembled M8 x 20mm screws (C) and M8 nuts (D) down into the outside channels of the upright extrusion (A) until they are positioned above the lower bar of the Upright Extrusion Installation display mount.
-
Page 7: Storage Box Installation
Installation Instructions FCASTC Storage Box Installation Slide two assembled M8 x 20mm screws (C) and M8 nuts (D) up into the outside channels of the upright extrusion (A) until they are in the desired position of the top edge of the storage box (H). - Page 8 FCASTC Installation Instructions Configuring Storage Box Re-tighten the loose M8 x 20mm screw (D), then secure the storage box (H) to the upright extrusion (A) using two M8 flange nuts (E). (See Figure 9) Installing Storage Panel IMPORTANT ! : Make sure the storage box is level before tightening the nuts.
-
Page 9: Finishing Installation
Installation Instructions FCASTC Installing Rack Brackets Finishing Installation Attach the large cover (J) to the outside of the storage box (H). (See Figure 15) WARNING: Exceeding the weight capacity can result in NOTE: The bottom rail on the cover will hook into the bottom serious personal injury or damage to equipment! It is the edge of the storage box. - Page 10 FCASTC Installation Instructions Install the camera to the camera brackets (G) using the Secure the camera using two M8 washers (S) and two M8 hardware included with the camera. (See Figure 17) flange nuts (E). (See Figure 19) IMPORTANT ! : Make sure the camera is level before tightening the nuts.
- Page 11 Installation Instructions FCASTC Secure Cover Attachment (OPTIONAL) Mark the height of the space between the camera and storage box (H) on the small cover (K). NOTE: The large cover (J) can be installed more securely if 10. Cut the small cover (K) to the required size. (See Figure 21) additional security is required.
- Page 12 FCASTC Installation Instructions USA/International A 6436 City West Parkway, Eden Prairie, MN 55344 P 800.582.6480 / 952.225.6000 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No.
