Installation Instructions Field Service Kit—Oil Tank Relay For CVHE, CVHF, CVHG, CDHF, and CDHG CenTraVac Chillers with Refrigerant/Oil Pump SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
(Global Harmonized System of Classification and compounds have the same potential impact to the Labeling of Chemicals) guidelines for information on environment. Trane advocates the responsible handling of allowable personal exposure levels, proper all refrigerants-including industry replacements for CFCs respiratory protection and handling instructions.
Page 3
Introduction WARNING Refrigerant may be under Positive Pressure! System contains oil and refrigerant and may be under positive pressure. Recover refrigerant to relieve pressure before opening the system. See unit nameplate for refrigerant type. Do not use non- approved refrigerants, refrigerant substitutes, or refrigerant additives.
PROD-SVB06A-EN. Overview WARNING The new relay (RLY03555) will be located in the Tracer Hazardous Voltage w/Capacitors! AdaptiView control panel. Disconnect all electric power, including remote To install the new relay without replacement of the disconnects before servicing.
Page 5
3. Remove old oil tank relay. Note: The oil tank relay will be wired to 1A7; the recommended position for the relay is shown in Figure 1. Original relay Figure Figure 4. Relay location 7. Connect wire to oil tank relay and wire relay to 1A7 (see 4.
Page 6
8. Remove terminal box. Figure 9. Terminal boxes Figure 7. Installed gasket Old Terminal Box New Terminal Box 11. Reconnect terminal box. Figure 10. Reinstalled terminal box 9. If you are re-using the original Fusite connector, then before attaching the Term-Lok adapters, remove the backing to expose the adhesive on the insulator (GKT04571), and then install the insulator over the Fusite pins.
Page 7
Figure 12. Oil tank relay connection diagram PART-SVN193B-EN...
Page 8
For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
