Summary of Contents for TRENDnet TMR-61U2

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction ......................2 Safety Instruction ......................2 Feature..........................2 Package Contents ......................3 System Requirements......................3 LED Status (Optional) ...................... 3 Supported Memory Cards ....................4 2. Installation ......................5 Driver Installation for Windows 98SE................5 Utility Installation ......................6 MAC 9.x ...........................

  • Page 3: Introduction

    1. Introduction This USB 2.0 All-in-One Memory Card Reader/Writer supports most of the memory cards available in the market. In addition to those commonly used memory cards, it also supports Mini-SD, RS-MMC and MS DUO without the need of an adapter. Data can be exchanged between different slots.

  • Page 4: Package Contents

    Error! Style not defined. MultiMedia™ Card (MMC), MMC 4.0, RS MMC™, RS MMC 4.0, Memory Stick™ (MS), Memory Stick Pro (MS PRO), Memory Stick Duo™ (MS DUO), MS Pro MagicGate™, MS MagicGate™, MS Duo MagicGate™, MS Pro Duo™, MagicGate™, Memory Stick Select Function, Smart Media Card™ (SM), SM RAM Card, XD-Picture™...

  • Page 5: Supported Memory Cards

    Supported Memory Cards Slot 2 Slot 1 Secure Digital Card (SD), Compact Flash I/II SD Ultra Card, Mini SD CF Extreme III, CF Ultra II MultiMedia Card (MMC), Micro Drive (MD) MMC 4.0, RS MMC, Magicstor RS MMC 4.0 Slot 3 Slot 4 Smart Media Card (SM) Memory Stick (MS),...

  • Page 6: Installation

    Error! Style not defined. 2. Installation For Windows ME, 2000, XP and Vista, there is no additional driver installation is required. Simply plug the reader/writer to the computer and it’s ready to use. To better distinguish between different slots, refer to the “Icon Utility Installation” section to install the icon utility.

  • Page 7: Utility Installation

    3. Select Yes, I want to restart my computer now and click Finish. After restart, proceed with next section to install the color icon utility. Utility Installation This Utility will help you to identify which driver the memory card is connected to. Take these steps to install the utility.
  • Page 8 Error! Style not defined. 4. At the welcome screen, click Next. 5. If the reader/writer is not plugged to your computer, plug it as prompted and click OK. 6. Select Yes, I want to restart my computer now and click Finish. (Windows XP users will not see this screen;...
  • Page 9 After installation, an USB device icon will appear on the notification area of the taskbar under Windows ME, 2000 and XP only). You will also see a couple of removable disk icons each with an assigned drive letter in My Computer. You can write and read files to and from the device as you would with an ordinary disk drive.

  • Page 10: Mac 9.X

    Error! Style not defined. MAC 9.x 1. Insert the provided driver CD-ROM into your computer’s CD-ROM drive. Double-click the CD icon on the desktop and navigate to the directory of \MacDriver\Mac9.x. Copy and then paste the Max9xDriver.SIT file to the desktop.

  • Page 11: Installation Verification

    5. Click Restart. 6. After restart, plug the reader/writer to a free USB port of the Mac. Installation Verification To verify the driver installation under Mac 9.x, take these steps: 1. Click the Apple icon in menu bar and select Apple System Profiler. 2.

  • Page 12: Mac 10.X

    Error! Style not defined. MAC 10.x For Mac 10.x, no additional driver installation is required. Simply plug the reader/writer to a free USB port of your Mac and it’s ready to use. To verify that the reader/writer is properly plugged, take these steps: 1.

  • Page 13: Using The Card Reader/Writer

    3. Using the Card Reader/Writer Notes on Using the Card Reader When using the card reader/writer, pay attention to the following notes: USB 2.0 performance (high-speed of up to 480 Mbps) can only be expected when connected to an USB 2.0 port. The device runs at full speed (of up to 12Mbps) when connected to an USB 1.1 port.
  • Page 14 Error! Style not defined. 1. In the notification area, right-click the unplug/eject icon and select Unplug or eject hardware or Safely Remove Hardware. 2. Select the device you want to unplug, then click Stop and OK. 3. When Windows notifies you that it is safe to do so, click OK and unplug the reader/writer from your computer.

  • Page 15: Under Mac

    Under Mac For Mac, remember to drag the corresponding icon representing the card to the trash can before extracting a card. When prompted, click OK and now you can extract a card. Mac 9.x Mac 10.x...

  • Page 16: Specifications

    Error! Style not defined. 4. Specifications Description Model Slot 1 Compact Flash I/II, CF Extreme III, CF Ultra II, Micro Drive (CF/MD Slot) (MD), Magicstor Slot 2 (SD/MMC Slot) Secure Digital Card (SD), SD Ultra Card, Mini SD MultiMedia Card (MMC), MMC 4.0 RS MMC, RS MMC 4.0 Slot 3 Smart Media Card (SM), SM RAM Card,...

  • Page 17: Regulatory Compliance

    5. Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received. Including interference that may cause undesired operation.
  • Page 18 Error! Style not defined.
