UFP PRO Series Assembly Instructions

Items you may need
• Fence posts*
• Posthole digger
• Measuring tape
• Clear PVC cement
• Drill
* One per panel, plus one to complete the fence run.
6x8 Panel
• 15 — Panel pickets
• 2 — U-channels
• 1 — 3.5" Top rail
• 1 — 5.5" Mid rail
• 1 — 5.5" Reinforced
bottom rail
• 23 — Square balusters
Check local ordinances and regulations before building your
fence. Before construction, contact your local utility companies
to mark any underground cables and pipelines. In addition, it is
a good idea to discuss plans with any neighbors along your
proposed fence line.
Design and layout
• Determine the number of posts, panels and gates needed to
complete the job based on the total linear footage. Take into
consideration post, panel and gate widths when determining
the total number of each.
• Adjust layout to accommodate as many full panels as possible.
If you must use a partial panel, place it in the farthest rear
corner of the property.
• Locate property boundaries and drive stakes into the ground
at corners and ends of fence line, based on local municipality
regulations.
• Stretch twine or heavy string between stakes and pull tight
to mark layout of fence line.
• Be sure to measure your fence panels and gates prior to
determining the location of the postholes. Place posts in the
following order along string line:
• End/corner posts • Gate posts
©2020 UFP Retail Solutions, LLC. All rights reserved. UFP Retail Solutions is an affiliate of UFP Industries, Inc.
• Screwdriver • Gravel
• Level • Shims
• Chop saw • Pencil
• Safety glasses
• String line
• Gloves
• Concrete
Kit contents
6x6 Panel
• 11 — Panel pickets
• 2 — U-channels
• 1 — 3.5" Top rail
• 1 — 5.5" Mid rail
• 1 — 5.5" Reinforced
bottom rail
• 15 — Square balusters
Preparation Step 3
• Line posts
68956 U.S. Hwy 131, White Pigeon, MI 49099 616.365.4201 11266_7/20
PRO SERIES BALUSTER TOP AND CLOSED
PICKET TOP PANEL ASSEMBLY INSTRUCTIONS
54"
(solid panel)
(solid panel)
Post hole spacing is 71-5/8 in. post-center to post-center for the 6x6
panel and 95-5/8 in. post-center to post-center for the 6x8 panel
(fi g. 1). Mark post hole locations along string line. Double check all
measurements. Check local regulations for any special requirements
for post hole depth. The fence will be stronger if the end, corner
and gate posts are set at least 6" deeper than the line posts. Using
a posthole digger or power auger, dig the holes 10-12" wide and 6"
deeper than needed. Backfi ll the holes with 6" of gravel to drain water
away from the bottom of the posts (fi g. 2). Keep the height of your fence
panels in mind when digging your postholes.
Starting in the corner, mix concrete in the fi rst hole per the instruc-
tions on the bag. Mix thoroughly and install the post into the hole and
tap the post to the proper depth. We recommend a 2" gap from the
ground to the bottom of the panel. Use a level to ensure the fence
post is plumb and the post is square with the ground. Brace the post
with temporary supports as the concrete sets (per the instructions).
Level
Corner or End Post
71-5/8" or 95-5/8"
from post-center
to post-center
www.ufpi.com
94-1/2"
6x8 Panel
Post spacing: 90-5/8"
inside-to-inside
70-1/2"
54"
6x6 Panel
Post spacing: 66-5/8"
inside-to-inside
WoodbridgeDwg1/2.ai
Digging postholes
WoodbridgeDwg1/2.ai
Level
10" to 12"
Diameter
fi g. 2
fi g. 1
69-9/16"
69-9/16"
18" to 24"
6" of gravel
