MAIL BOSS
LOCKING SECURITY MAILBOXES
The Wall Mount Bin Style Locking Key Drop box is designed for your security and convenience.
This drop box is constructed of heavy duty galvanized steel and is designed to be installed on a
vertical wall.
Below you will find a list of hardware parts and detailed installation instructions. Please take
the time to carefully sort the hardware and familiarize yourself with the function of each piece for ease
of installation. Typical installation hardware has also been provided for your convenience.
Since concrete is a hard surface, take proper care when installing this hardware into hard surfaces,
making sure not to break the drill bit or screws provided. An electric drill may be required for hard
surface installation.
If you require assistance with assembly, part replacement, or any other matter, contact the
toll-free Epoch Design Service Center from anywhere in the Continental United States,
Monday through Friday, 9 AM - 5 PM Pacific Standard Time at 1-800-589-7990. You may also
email your request or comments to info@mailboss.com and a service representative will respond.
You will also find helpful hints and tips on our website: www.mailboss.com.
50
Key Hooks
For Key Storage
Rubber Grommets
4
Isolates key box from wall
Mounting Screws
4
Connect key box to any wall
Security Keys
3
Used to lock and unlock
your key box
1
Key Drop Bin
To collect deposited keys
1
Key Boss Drop Box
Locking security key storage
We strongly recommend that you WRITE DOWN YOUR COMBINATION / KEY NUMBER and
keep it in a safe place other than inside your Key Boss. Without a key number we will not be able to
provide replacement keys, you will have to purchase a new lock and keys set. For security purposes,
we reserve the right to deny key replacement without proof of purchase. Activate your free Mail Boss
lifetime warranty and register your key number at: www.Mailboss.com/Register
Key Boss
Key Boss
®
Parts and Hardware List
! IMPORTANT !
Have a question?... Need a part ASAP?...1-800-589-7990
Copyright © 2019 Epoch Design™ All rights reserved
®
Attachment Rivets
14
4
Used to connect rails
and shelf
Steel Washers
4
Used with mounting screws
4
Wall anchors
Used when installing
into drywall
3
Short Key Rail (front)
Mounted to the door
Long Key Rail
3
Mounted to the back
wall of the box
1
4 mm Drill Bit
For drilling holes into
concrete, brick,
mortar or wood
1
TORX (T25) Drive Bit
Used to drive screws
20-Dec-2019
Thank you.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Key Boss and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mail Boss Key Boss

  • Page 1 We strongly recommend that you WRITE DOWN YOUR COMBINATION / KEY NUMBER and keep it in a safe place other than inside your Key Boss. Without a key number we will not be able to provide replacement keys, you will have to purchase a new lock and keys set. For security purposes, we reserve the right to deny key replacement without proof of purchase.
  • Page 2 20-Dec-2019 Use a Phillips Head screwdriver to remove the handle from the inside of the bin door then re-attach the handle to the outside of the bin door. LEVEL Carefully place the box on the wall at about 130 cm to 165 6.5”...
  • Page 3 Key Snap Ring Front Key Rail Mounting Holes Front Rail Uprights If using the Key Boss as a deposit box, install the Key Drop Bin to the top holes of the door’s Front Rail Uprights. Secure by inserting two Attachment Rivets through the holes on the Key Drop Bin and into the door’s Front Rail Uprights.
  • Page 4 Key Rail will depend on your individual needs. We recommend attaching a key you will be storing within the Key Boss to the snap ring on a Key Tag, and hang it on the Front Key Rail (installed in step 5) where it works best for your needs.
  • Page 5 OPTIONAL COMBINATION LOCK If your Key Boss came with the optional combination lock, refer below for instructions on how to use: Hooked Set Your Own Combination: The combination can be changed in seconds without special tools or disassembly.
  • Page 6 MAIL BOSS 20-Dec-2019 ® Accessory items and parts available: www.mailboss.com Drop box Metro Townhouse Comment boss Available In All Colors Available In All Colors Available In All Colors Mail Manager Mail Boss Package Master Available In All Colors Available In All Colors...
  • Page 7 MAIL BOSS Key Boss Key Boss ® ® LOCKING SECURITY MAILBOXES Have a question?... Need a part ASAP?...1-800-589-7990 Copyright © 2019 Epoch Design™ All rights reserved...
  • Page 8 MAIL BOSS Key Boss Key Boss ® ® LOCKING SECURITY MAILBOXES Have a question?... Need a part ASAP?...1-800-589-7990 Copyright © 2019 Epoch Design™ All rights reserved...
