- Page 1 INSTALLATION INSTRUCTIONS For Low Profile Satdome Adapter: AMA-16 Refer to website for most up to date instructions and videos. WWW.SEAVIEWGLOBAL.COM...
-
Page 2: Parts Included
PARTS INCLUDED TOOLS NEEDED Sudbury Elastomeric Marine Sealant is recommended. To purchase call 800-655-7922 or visit www.seaviewglobal.com... - Page 3 Place the AMA-16 onto the mounting surface. Mark the four bolt holes for drilling. Remove the AMA-16 from the mounting surface.
- Page 4 Drill the four bolt holes. Using a hole saw drill the center hole for cables to pass through. Remove the clear protective film on the AMA-16.
- Page 5 Be sure to go around the base holes. Apply marine adhesive sealant to the inside of the four bolt holes on the top plate. Place the AMA-16 onto the mounting surface, making sure that all the bolt holes line up.
- Page 6 Secure the AMA-16 to the mounting surface with the four supplied washers and your own nuts and bolts. Place the foam gasket ontop of the AMA-16. Mount the satellite dome ontop of the foam gasket.
- Page 7 Using your own hardware secure the satellite dome to the mount using four bolts and washers.
- Page 8 EUROPEAN OFFICE Tel: 800-655-7922 Tel: +33 4 94 53 27 70 www.seaviewglobal.com www.seaviewprogress.com...
