  • Page 1 Repeater StereoPlus Dive into Various Soundscapes. Repite lo que te gusta.
  • Page 2 Dive into Various Soundscapes 5-Channel Stereo Mixer. The StereoPlus allows you to sum 5 monophonic signals with independent panning options, resulting in a stereo output. Our engineering laboratory is unique in the world, stay tuned!
  • Page 3 Index StereoPlus Description. Module installation. Page 1. Page 8, 9 and 10 Module features. Electrical specifications and recommendations. Page 2. Page 10, 11 and 12. Functions, inputs, and outputs. Warranty. Page 2, 3, 4, 5, 6 and 7. Page 12 and 13.
  • Page 5 3. Functions, Inputs and Outputs. ZanySignals' design prioritizes ease of interpretation and use, allowing for quick and straightforward integration into your workflow. As a result, it's more ergonomic in its knobs, ensuring anyone feels comfortable when interacting with each module.
  • Page 6 Next, a brief explanation of the segmentation of this module's parameters will be provided. The primary functions are assigned to the large black knobs. Secondary and tertiary functions are represented by the small black and blue knobs, respectively. Switches are implemented to toggle or hold a function. Function 1 Function 2...
  • Page 7 The E-switches are designed to allow for three possible functions. Function 1 Function 3 Function 2 Signal inputs are provided through 1/8" jacks, which are clearly distinguished from the outputs as they have a simple boundary, unfilled outline. Inputs Signal outputs are provided via 1/8" jacks, which in this case feature a fully highlighted or filled silkscreen.
  • Page 8 StereoPlus Features: Primary Knobs: Master: This knob controls the amplitude of the resulting L and R additive synthesis signal. The range spans from -∞ (no output) to 6dBu, given the combination of input signals.
  • Page 9 Secondary Knobs: Panning: This knob allows you to select through which channel the output signal will be obtained. In the central position (S), you'll get an equal level or volume for L and R. At the knob's minimum position (left side), the output signal will be on the L channel, while at its maximum position (right side), the output will be only on the R channel.

  • Page 10: Operation

    Stereo Output for the pre-listening channel. 4. Operation. The StereoPlus is a 100% analog module designed for additi- ve synthesis for stereo output. It allows for the combination of mono input signals and distributes them across the L and R channels using their panning knobs.

  • Page 11: Module Installation

    Similarly, the switches for each channel (5) allow for layered sound design, enabling or disabling waves in a more straightforward manner. Each input wave, such as a VCO with an amplitude of 10Vpp, when input only to one channel with the attenuator Knob (3) at 0dBu and setting the Master knob to +6dBu, results in an output signal level greater than -3dBu (1.8Vpp).
  • Page 12 Avoid directly touching any electrical contact of the distribution bus and the power source. The StereoPlus module requires a ±12V power supply, which means a 10-pin connector (2x5 pins). Connect the Ribbon cable to the 10-pin female connector on the module's circuit board.

  • Page 13: Electrical And Mechanical Specifications

    -12V -12V STRIPE STRIPE Install the StereoPlus into the Eurorack case rails and secure it using the 4 mounting screws of 3mm fine thread. Turn on your Eurorack case and verify its proper functioning. 6. Electrical and Mechanical Specifications: Power Supply: +12V, -12V.
  • Page 14 Horizontal Width: 27 HP. Height: 3U. Depth: 35mm from the front panel to the 16-pin Molex con- nector. 50mm from the knobs to the Molex connector. Note Always be aware of the output and input levels of each signal to prevent damage to this or any other module. Given the large audio levels of Eurorack, you should connect to modules specifically designed to accept these levels.

  • Page 15: Warranty

    2.2Vpp, equivalent to 0dBu. 7. Warranty. ZanySignals warrants this product against defects in materials or assembly for a period of one year from the date of purchase (proof of purchase receipt is required). Ensure all products are listed on the receipt.
  • Page 16 During the warranty period (1 year for this module), the defective product will be repaired or replaced at ZanySignals' discretion. It is necessary to return the product to ZanySignals' facilities, with the consumer covering the shipping costs. This allows us to review and inspect the module's defects and proceed with the repair.
  • Page 17 A of the Shiny at the Gate A input. This process is extracted from the Shiny output, selecting this channel to pass through the filter via the switch, and then summed to the first input of the StereoPlus (Stereo Mixer). 14 14...
  • Page 18 Following this, take the 1/4" output and connect it to the Gate input of the LowBlow. Its output then feeds into channel two of the StereoPlus. Finally, activate the 1/8" output from the AltDoor through the Gate B input of the Shiny. Extract the signal from its B output and input it into channel three of the StereoPlus, achieving a left (L) and right (R) output.
  • Page 19 Consulte el manual en línea para obtener información Consulte el manual en línea para obtener información detallada de este y otros productos. detallada de este y otros productos. www.zanysignals.com www.zanysignals.com Designed and created by ZanySignals. Sonorus spaces to expand the mind. Sonorus spaces to expand the mind.
  • Page 20 Made in Colombia ¡Pues pues! Sonorus spaces to expand the mind.
