USER MANUAL
CHARGED PLATE MONITOR
CPM-766

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPM-766 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Prostat CPM-766

  • Page 1 USER MANUAL CHARGED PLATE MONITOR CPM-766...

  • Page 3: Table Of Contents

    Table of Contents Important Safety Information INTRODUCTION Before you Start GETTING STARTED Battery Pack Sleep Mode Touchscreen Display Rear and Side Panels OPERATION Power Touchscreen/Basic Navigation Home Screen Functions Screen Test Setup SETTINGS General Settings Test Parameters Profiles, Locations & Areas Memory DECAY TEST BALANCE (OFFSET VOLTAGE)

  • Page 4: Important Safety Information

    Please read the Safety Instructions before using your Meter. Refer to the table below for an explanation of symbols which may be on your Prostat product. In this manual, a Warning identifies conditions and actions that pose hazards to the user. A Caution identifies conditions and actions that may damage the Meter or the equipment under test.
  • Page 5 • To avoid electric shock or fire hazard, do not operate this apparatus with the covers removed. • To avoid injury or fire hazard, do not operate this apparatus in an explosive environment. • Do not drop or strike the product. If the product is damaged, contact a Prostat Authorized Service Center.

  • Page 6: Introduction

    The CPM-766 is equipped with a Li-ion battery pack that can be recharged through a USB connection. With a battery life of over 250 hours when in standby, it enables you to conduct around 1000 tests on average.

  • Page 7: Before You Start

    Before You Start Table 1 is a list of the items included with your Charged Plate Monitor. Part No. Description CPM-766 Prostat Charge Plate Monitor • 801B-012 Rechargeable Li-ion Battery Pack • PFP-861LL 72 inch Test Lead, Green • PFA-861H...

  • Page 8: Getting Started

    CAUTION! The charged plate monitor contains electrostatic discharge sensitive (ESDS) components and includes precision alignment of circuit elements. Only Prostat trained and qualified instrument repair personnel should perform service. WARNING! To prevent electrical shock, do not touch energized circuits, leads or fixtures while grounded.
  • Page 9 Figure 1. Connect the provided charger to an outlet to charge your Charged Plate Monitor Figure 2. Connect the provided USB-C Cable to a computer to charge your Charged Plate Monitor It is recommended to turn off the instrument before plugging in the USB cable or wall charger. Once charging has begun, you may leave the instrument in its off position, or leave it on.

  • Page 10: Sleep Mode

    Sleep Mode The instrument automatically enters "Sleep Mode" and blanks the display if there is no function change for 10 minutes, unless the instrument is actively performing a test. Tapping anywhere on the active display awakens the instrument. Touchscreen Display The touchscreen lets you interact directly with what is on the display.
  • Page 11 Number Feature Indication The Prostat Logo. Displays the date. The date can be configured in the DATE Settings menu. Displays the time. The time can be configured in the TIME Settings menu. BATTERY PERCENTAGE Indicates how much charge remains in the battery.

  • Page 12: Rear And Side Panels

    Rear and Side Panels Table 4 is a list of the connectors and functions. Figure 4. Rear Panel...
  • Page 13 Figure 5. Side Panel Number Description BNC Analog Output Connector USB-C Connector Temperature and Humidity Sensor Earth Ground Connectors Bluetooth Antenna Table 4. Rear and Side Panel Connectors...

  • Page 14: Power

    Power The Charged Plate Monitor has 2 options for the power source: • Li-Ion Battery • USB-C Battery Power Source This instrument is battery operated, do not connect with any other utility line. The lithium-ion battery pack is usually already installed when shipped. If you received it separately, you can easily install it inside the battery compartment located at the bottom of the instrument.

  • Page 15: Touchscreen/Basic Navigation

    • Date (if this was set) • Current Profile The charge plate monitor automatically enters "Sleep Mode" and blanks the display if there is no function change or button press for 10 minutes, unless the instrument is actively making a measurement.

  • Page 16: Home Screen

    Home Screen The Home screen is the first screen to appear after plugging the battery in and setting the date and time. The Home screen display the Time, Date and the current Profile. To return to the Home screen from any other screens, press the Functions Screen The Functions screen is your primary access to all functions of the Charged Plate Monitor.

  • Page 17: Test Setup

    Test Setup Two green ground inputs jacks are installed on the instrument. Both are installed on the side panel. The AC adaptor does not provide a ground connection. Grounding the instrument is required to ensure accurate and repeatable measurements. For proper grounding, connect one end of the PFP-861LL Ground Lead to one of the green input jacks on the side panel of the instrument, and plug the other end to a ground reference, using the Q007B Grounding Cube.

  • Page 18: Test Parameters

    Note: Audible indications for critical functions cannot be disabled, such as Low Battery and Error indication. Test Parameters The Test Parameters settings menu is where you set the test parameters for: • Decay Test • Balance Test • Automated Test •...

  • Page 19: Profiles, Locations & Areas

    Include Balance Test. You can elect to include or not include a BALANCE test as part of the cycle for an Automatic Test. If this setting is set to YES, the Automated Test will begin a single Balance Test. The test will then continue with the Decay tests.

  • Page 20: Memory

    Locations. This is where you can name up to 20 locations. This is useful for naming different departments, divisions, or even countries. Areas. This is where you can name each area of test, up to 100 areas. This is useful for naming a particular ionizer, work area or office.

  • Page 21: Balance (Offset Voltage)

    1. From the Functions Screen, tap POSITIVE DECAY or NEGATIVE DECAY. The screen displays a Zeroing Bar. The instrument will ground (zero) the floating plate. When the plate is zero, the display will show the voltage on the plate, which should be close to 0 volt. 2.

  • Page 22: Automated Test

    5. Tapping CANCEL will abort the test and return to its previous screen. 6. Once the test is completed the screen will display the Plate Voltage, Test Duration, Min/Max Peak Voltages, the Average Voltage, Temperature, Relative Humidity and Location/Area. 7. Tapping SAVE will save the results under the Location and Area selected. 8.

  • Page 23: Plate Voltage Retention

    3. Tap the CHARGE + button to charge the plate to +1,250 volts 4. Tap the CHARGE - button to charge the plate to -1,250 volts 5. Tapping EXIT will abort the test and return to its previous screen. 09 PLATE VOLTAGE RETENTION From the Settings, you can choose to verify if the isolated conductive plate retains the test voltage properly.

  • Page 24: Measurement Display

    10 MEASUREMENT DISPLAY Tables 3 and 4 are lists of visible readings and what the symbols mean during a live measurement: Symbol Description Symbol Description Balance Shows current test being performed Decay (+ / -) Shows current test being performed Location, Area Shows the Location and Area, if selected Location, Area...

  • Page 25: Internal Memory

    Tables 5 and 6 are lists of visible readings and what the symbols mean on the summary screen: Symbol Description Symbol Description Balance Duration The duration of the balance test Decay Time Time of decay in seconds Peak Voltage Min and max peak voltages Start Voltage The starting voltage from parameters The average between the peak...

  • Page 26: Drivers And Firmware

    An analog output jack is provided on the rear panel. The analog output is a BNC jack that can be used to connect the Charged Plate Monitor to an oscilloscope or other suitable devices. 1 volt at this output corresponds to 10 kV. The BNC connector on the rear panel comes with connector cap (766-020) to protect the connector.

  • Page 27: Update Firmware

    The instrument is now ready to communicate with Connect 2.0. Update Firmware Firmware updates are available to add new measurement functions or fix bugs. The up-to-date firmware version is available through the latest Prostat Connect 2.0 available at www.prostatcorp.com. To update firmware: 1.

  • Page 28: Maintenance And User Adjustment

    The case has been sealed and BREAKING THE SEALS WILL VOID THE WARRANTY. For complete service, disassembly, repair, and calibration information, contact Prostat or an Authorized Calibration Lab for assistance. • Clean the instrument case with a dry, soft, non-scratching cloth •...

  • Page 29: Battery Replacement

    • Do not disassemble the battery. • Repair the product before use if the battery leaks. • Use only Prostat approved power adapters to charge the battery. • Do not disassemble or crush battery cells and battery packs. • Do not keep cells or batteries in a container where the terminals can be shorted.

  • Page 30: Calibration Information

    Per IATA 2021 regulations. Regulations subject to change without notice. Calibration Information The charge plate monitor specifications are based on a 1 year calibration cycle. Recalibration must be done by qualified personnel. Contact your local Prostat Authorized Calibration Lab for more information about recalibration.

  • Page 31: Replacement Parts And Accessories

    Prostat Authorized Calibration Laboratory. To keep your product in optimum condition, we recommend having it verified and calibrated on an annual basis by Prostat or an Authorized Calibration Laboratory. The Charged Plate Monitor will not turn on If the battery level is less than 8%, the battery may be completely discharged. Using the provided USB cable, plug the instrument in and try to turn it on (refer to the Battery Pack section of this manual for more information.)
  • Page 36 ©2024 Prostat Corporation. Prostat, Prostat Corporation and the Prostat logo are trademarks or registered trademarks of Prostat Corporation or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. Complying with all applicable copyright laws is the responsibility of the user.
