HEAD HDSP02 User Manual

ENGLISH – USER MANUAL
IPX7 Wireless speaker with bike holder -- - HDSP02
1 . Characteristics
1 .1 Technical specifications
Playtime: Up to 9 hours
Battery: 600 mAh
Power: 3 W
Audio frequency range: 20 Hz - 20 kHz
Protection rating: IPX7 (water and sweat proof)
Operation range: 10 meters
Wireless frequency range: 2.402-2.480 GHz
Maximum transmitted power in frequency ranges: -0.16dbm
Technology: True Wireless Stereo
Impedance: 40 Ω
Sensitivity: 80dB
Charging time: 3 hours
Dimensions: Ø9.5 x 4.9 cm
Weight: 220 g
Material: ABS
1 .2 In the box
1 x Speaker
1 x Strap
1 x USB-A to USB-C cable (50 cm)
1 x User manual
1.3 Product details
1- Power button
2- Multifunctional button
3- Volume -/Previous track
4- Volume +/Next track
1 .4. Speaker LED indicators
The speaker's LED indicators informs about the connection and the
battery state:
Charging
speaker
Charged
speaker
Low battery
Pairing mode
2. Initial setup
5- USB-C charge port
6- AUX-IN port
7- LED function indicator
8- LED charge indicator
When charging the speaker, the LED
charge indicator will be steady red. It
means that the speaker is charging but
is not fully charged.
The LED charge indicator will turn off
when fully charged.
When the speaker is below 20%
battery, the LED charge indicator
flashes red.
After turning on the speaker, it will
automatically enter in pairing mode.
The LED function indicator will flash
red and blue and change to a steady
blue after connected.
