SLI STEALTH II User Manual

Solar Lighting International
STEALTH II
LED SOLAR STREET LIGHT
USER MANUAL
40W / 80W / 120W
Please read and follow all instructions for
operation. Save this manual for future reference.
The Name Solar Lighting International is a Registered Trademark.
®
® , Inc.
Working Modes
Operation Instructions for Single-sided
Solar Street Light 40-23 / 80-23 / 120-23
BEFORE INSTALLING THE LIGHTS, READ THIS MANUAL.
1.
Determine the optimal angle to face the light fixture/solar panel. The optimal angle for the
solar panel is your latitude and facing south. Then attach the light onto the pole.
2. Press the Power Button button on the light. The fixture will light up for 3 seconds and then
turn of f, which indicates that the light and remote control are successfully activated.
To turn the system completely of f, press the Power Button button again, and the light will flash 3
3.
times and then turn of f.
FIXTURE LIGHTING OPTIONS
Press the button on the light to select the preferred working mode as shown below.
The light bar will light up for 3 seconds then turns o ff when each button is pressed.
REMOTE CONTROL FEATURES
Power Button
Constant Lighting Mode
Automatically operates at 50%
brightness from dusk to dawn or
until power is off.
Sensor Mode
Automatically operates at 30%
brightness. When motion is
detected, light increases to
100% until no motion is
detected for 30 seconds, then
returns to 30% brightness.
Detection up to 50 feet.
Customized Working
Mode
Automatically turns on at dusk
and remains at up to 80-100%
brightness for 4 hours, then it
automatically turns to 20%
brightness until dawn.
