  • Page 1 TRT-3493-12 User Guide Rugged Tablet...

  • Page 2: Revision History

    Revision History Current Rev: 5.2 Date: 03.16.2022 Revision New Release 1.) New added 1pc Tablet Main Battery shipping along with Docking Station 2.) Win10 OS revision 3.) LTE category update 4.) Barcode Scanner SwiftDecoder supplement 5.) Battery Hot-swappable features supplement 6.) MIL-STD-810G Test Compliance update 1.) Update main battery description 1.) new added battery charger...
  • Page 3 Rugged Tablet Features This chapter briefly describes the features of Rugged Tablet-TRT-3493-12 which has three products repsectively as well as purchased individually as optional peripherals. • TRT-3493-12 Tablet (system) • TRT-3493-12 Docking Station (optional peripheral) (including one standalone Tablet Battery) •...
  • Page 4 Microphone Charging LED LED Indicator Power LED Main Battery 19.532Whr Removable lithium battery with latch lock (2570mAh, 7.6V)* Hot-Swappable Battery Yes, 2.66Whr back-up battery (700mAh*1, 3.8V, 1S1P) 1 x USB 3.0 Type-A ; 1 x Nano-SIM (Support by Request w/LTE feature) I/O Port 1 x Audio Jack ;...

  • Page 5: Docking Station

    TRT-3493-12 optional peripheral- Docking Station DOCKING STATION Desktop Cradle with Power Charging. Key Features Battery Charging Bay and I/O Expansion 1 x Powered 24V USB 1 x USB 3.0 Type-A 2 x USB 2.0 Type-A 1 x HDMI 1.3 1 x Powered 5V/12V Serial Port...
  • Page 6 TRT-3493-12 Dimensions and I/O Placement Figure shows the dimension and I/O placement of Tablet, Docking Station and Extension Cover. Figure1:Teguar TRT-3493-12 Tablet Dimension...
  • Page 7 Figure2: Teguar TRT-3493-12 Docking Station Dimension (without Cable Cover) Figure3: Teguar TRT-3493-12 Docking Station Dimension (with Cable Cover)
  • Page 8 Figure4: Teguar TRT-3493-12 Extension Cover Dimension Figure5: Teguar TRT-3493-12 Battery Charger Dimension...
  • Page 9 Figure6: Teguar TRT-3493-12 Tablet Placement Figure7: Teguar TRT-3493-12 Docking Station Placement (without Cable Cover)
  • Page 10 Figure8: Teguar TRT-3493-12 Docking Station Placement (with Cable Cover) Figure9: Teguar TRT-3493-12 Extension Cover Placement...
  • Page 11 Figure10: Teguar TRT-3493-12 Battery chager Placement...
  • Page 12 Quick Start Guide This chapter briefly describes the how to install Shoulder-strap and Cable Cover along with Docking Station as well as Capacitive Function Key on front panel side. Shoulder-strap Quick Installation Guide Shoulder-strap installation SOP as follows: Step1: Place Shoulder-strap this way in front of you on the desk Step2: Loose strap from buckle...
  • Page 13 Step3: Make strap go through the hole of Rear Cover and tighten well Step4: Repeat same way as Step2 and Step3 on the other side (as following circle) Step4: Complete...
  • Page 14 Cable Cover Quick Installation Guide Cable Cover installation SOP as follows: Step1: Place Docking Station this way in front of you on the desk Step2: Put down the front side of Docking Station on the desk...
  • Page 15 Step3: Assemble Cable Cover Step4: Assemble Bottom Plate Step5: Screw on Bottom Plate with 4 screws...
  • Page 16 Battery charger Quick Installation Guide Step1: Use TRT-3493-12’s adapter to access the DC jack of the battery charger Step2: Insert Battery to charge...
  • Page 17 Capacitive Function Key Default key function in F1, F2 and F3 are: F1: Rotation Lock F2: Power Key F3: Windows Home Key However, any other requirements of usage would be considered as “support by request” from customized BIOS. Please refer usage list as below Table1-1, Table1-2 and Table1-3 for detail. Table1-1: Capacitive Function Key Usage List...
  • Page 18 Table1-2: Capacitive Function Key Usage List...
  • Page 19 Table1-3: Capacitive Function Key Usage List...
  • Page 20 Managing System Power This chapter briefly describes the guideline on external power supply, battery pack as well as Safety Notice. AC Adapter  Two AC adapters are designed for use with Tablet and peripheral respectively. Tablet & Battery Charger : 19V/65W ...

  • Page 21: Battery Pack

    Battery Pack The battery pack is hot-swappable design as well as the internal power source for Tablet. It is rechargeable by using the AC adapter. Hot-swappable features  Main Battery (2570mAh) supports hot-swappable and back-up battery(700mAh, non-  removable) can provide provisional(30sec to 45sec) power to remain system awake until new main battery(2570mAh) reload.

  • Page 22: Initializing The Battery Pack

    Initializing the Battery Pack Users need to initialize a new battery pack before using it at the 1 time or when the actual operating time of the battery pack is much less than expected. Initializing would be the prcoess of fully charging, discharging, and then charging.

  • Page 23: Solving Startup Problems

    Solving Battery Problems The battery does not charge (Battery Charge indicator does not light orange). Make sure that the AC adapter is properly connected.  Make sure that the battery is not too hot or cold. Allow time for the battery pack to return to room ...

  • Page 24: Safety Notices

    Display Grant section of www.fcc.gov/eot/ea/fccid after searching on FCC ID: 2ADL6-TRT-3493-12. To ensure that RF exposure levels remain at or below the tested levels, use a belt-clip, holster, or similar accessory that maintains a minimum separation distance of 0mm between your body and the device.

  • Page 25: Bios Specification

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. BIOS Specification MAIN PAGE...
  • Page 26 BIOS Setup option name Type [Default] / Select Value Show Help string Main Page BIOS Information Header BIOS Vendor Information string American Megatrends BIOS Version Information string D8080X0x Build Date and Time Information string xx/xx/2019 hh:mm:ss Line separator Processor Information Header Processor Type Information string...

  • Page 27: Advanced Page

    ADVANCED PAGE...
  • Page 29 BIOS Setup option name Type [Default] / Select Value Show Help string Advanced Page LAN 1 Select item [Disabled] / Enabled Enable/Disable LAN1 LAN 2 Select item [Disabled] / Enabled Enable/Disable LAN2 LAN 3 Select item [Disabled] / Enabled Enable/Disable LAN3 MSATA Select item [Disabled] / Enabled...
  • Page 30 BIOS Setup option name Type [Default] / Select Value Show Help string Advanced Page ► NCT6683D Super IO Configuration System Super IO Chip Parameters. Super IO Chip Information string NCT6683D ► Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port Select item [Enabled] / Disabled...
  • Page 31 SECURITY...
  • Page 32 BIOS Setup option name Type [Default] / Select Value Show Help string Security Page Password Description If Only the Administrator's password is set then this only limits access to Setup and is only asked for when entering Setup If ONLY the User’s password is set, then this Information string Is a power on password and must be entered to boot or enter Setup.
  • Page 33 BIOS Setup option name Type [Default] / Select Value Show Help string Security Page ► Key Management Enables experienced users to modify Secure Boot variables without full authentication. Factory Key Provision Provision factory default keys on next re-boot only Select item [Disabled] / Enabled Depend when System in Setup Mode...
  • Page 34 BOOT...
  • Page 35 BIOS Setup option name Type [Default] / Select Value Show Help string Boot Page Boot Configuration Information string Setup Prompt Timeout Number of seconds to wait for setup activation key. Input value 65535(0xFFFF) means indefinite waiting. Bootup NumLock State Select item [On] / Off Select the keyboard NumLock state Line separator...

  • Page 36: Save And Exit

    SAVE & EXIT BIOS Setup option name Type [Default] / Select Value Show Help string Save & Exit Page Save Options Information string Save Changes and Reset Dialog [Yes] / No Reset the system after saving the changes. Discard Changes and Reset Dialog [Yes] / No Reset system setup without saving any changes.
