Summary of Contents for b&t JET
- Page 1 JET & MINI-JET PISTOL SUPPRESSOR OPERATOR MANUAL B&T AG 3608 Thun • Switzerland Tel +41 33 334 67 00 info@bt-ag.ch www.bt-ag.ch TM-988003-JET-00-EN...
-
Page 2: Table Of Contents
2. Technical specifications ......................4 Nomenclature ..........................4 General description ........................4 Technical data ..........................5 3. Thread sizes ..........................5 Type description ..........................6 3.1.1 JET ..........................6 3.1.2 Mini-JET ........................6 4. Assembly & Disassembly ......................7 Mounting suppressor ........................7 Dismounting suppressor ......................7 Replacing rubber baffels ......................8 5. -
Page 3: General Rules
WARNUNG! Suppressed firearms make less noise than non-suppressed firearms, it’s easy to forget that they are still firearms. It’s of vital importance to remember that a sound suppressed firearm is just as dangerous as a non-suppressed firearm and the same safe handling procedures apply. Failure to follow the operating instructions can result in serious injury to the user and damage to the firearm. -
Page 4: Technical Specifications
1 Mini-JET spacer General description The JET pistol suppressor has been specially designed for use on pistols and is fitted with baffles. Thanks to the integrated thread he can be mounted quickly on the weapon without any tools. PAGE 4 OF 12... -
Page 5: Technical Data
Technical data JET pistol suppressor Mini-JET pistol suppressor Description cal. 9 mm (Hush Puppy) cal. 9 mm Manufacturer B&T AG - Switzerland Product ID See chapter „3. Thread sizes“ Caliber max. 9 mm Weight [g] Overall length [mm] Tube diameter [mm] Thread See chapter „3. -
Page 6: Type Description
Country and year of manufacture Serial number Suppressor type Revision number Calibre Article number xx-xxxx .32 ACP - 9 mm SD-988003 CH 20xx JET SD Rev.00 B&T AG Switzerland Manufacturer 3.1.2 Mini-JET Country and year of manufacture Serial number Revision number Article number... -
Page 7: Assembly & Disassembly
Assembly & Disassembly Mounting suppressor SAFETY ADVICE! Unload the firearm and carry out an unloading check, following the operating instructions for the firearm. a. Remove the thread protection nut from the barrel (if present). Therefore turn the nut as follows: »... -
Page 8: Replacing Rubber Baffels
Push the baffels out. c. Using the ejection tool (not included in the scope of deliv- ery), push the residue out of the pistol in the direction of firing. JET (3 spacers, 4 baffles) Mini-JET (1 spacer, 2 baffles) PAGE 8 OF 12... - Page 9 d. Replace the baffles. Therefore prepare the inner parts and insert them into the suppressor body. e. Reinstall the cover. f. Using the disassembly tool, tighten the cover (right-hand thread) by hand. To do this, place the bulged end of the dis- assembly tool in the cover and turn it clockwise.
-
Page 10: Maintenance Procedures
Maintenance procedures Storage Weapons with installed suppressor should be stored upside down with the barrel pointing down. This is especially import- ant after cleaning the suppressor to prevent any cleaning fluid remaining from flowing into the barrel. Field maintenance / use Field maintenance shall be performed in the following se- quence : »... -
Page 11: Workshop Maintenance
Workshop maintenance Perform periodic maintenance in the workshop if one or more of the following criteria are met : » If sand, mud, water or other liquids got inside the suppressor and then had to be fired without being able to remove the residue from the inside. »... -
Page 12: Accessories
Accessories Picture Art.-No. Designation BT-12609 Rubber baffle - 1 piece SD-988004 Rubber baffle - Set of 4 pieces BT-231328 Ejection tool Warranty statement Warranty claims on behalf of the client are to be explicitly declared as such. During the legal warranty pe- riod, B&T provides warranty cover solely for defects that arise as a result of faulty materials, construction errors or poor workmanship.
