Summary of Contents for Dormakaba TENSOR Double-Acting Hinge
- Page 1 TENSOR Double-Acting Hinge Wall and glass mount Installation instructions 812001 – 01-2018 | EN |...
-
Page 2: Table Of Contents
TENSOR - Wall and Glass Mount Installation Instructions Table of Contents Table of contents 1 Technical specifications Overview 1.1.1 General information 1.1.2 Intended use 1.1.3 Glass requirements/fittings/mounting 1.1.4 Requirements for glass panel 1.1.5 Safety instructions 1.1.6 Symbols used - Safety/Installation 1.1.7 Maintenance, care, repair... -
Page 3: Technical Specifications
TENSOR - Wall and Glass Mount Installation Instructions Technical specifications 1 Technical specifications 1.1.6 Symbols used - Safety/Installation Overview CAUTION These instructions are for installation of TENSOR Double-Acting Hinges for the following mounting and style versions: Mounting components must meet the requirements of substructure/wall and door weight. -
Page 4: Application Variations
TENSOR - Wall and Glass Mount Installation Instructions Applications 2 Application variations Fig 1 Wall mount Double- acting hinge 1/8” Gaskets 1/8” 1/8” [x4 each] 1/32” [1] 1/16” [2] 1/8” [3] 1/4” Wall plate M6x12 Cover flat head screws (x8) -
Page 5: Installation Instructions - Wall Mount
TENSOR - Wall and Glass Mount Installation Instructions Wall mount - disassemble Wall mount - secure wall plate Wall mount - secure hinge to glass 3 Installation instructions - wall mount Disassemble and prep hinges Fig 3 Gasket size reference chart... -
Page 6: Mount Door To Wall
TENSOR - Wall and Glass Mount Installation Instructions Wall mount - install door Mount door to wall Fig 5 2-3/4” NOTE: Place glass door on setting blocks [70] during installation. 2-3/8” [60] 3.3.1 Tip glass up and into place, aligning door 3.3.2 Mark holes for drilling (upper and lower... -
Page 7: Installation Instructions - Glass Mount
TENSOR - Wall and Glass Mount Installation Instructions Glass mount - disassemble Glass mount - secure sidelite hinge plate 4 Installation instructions - glass mount Prep door frame, disassemble and prep hinge Fig 6 Gasket size reference chart Glass thickness 1/2”... -
Page 8: Secure Glass Door Hinge
TENSOR - Wall and Glass Mount Installation Instructions Glass mount - install door Glass mount - install door stops Secure glass door hinge Fig 8 NOTE: Place glass door on setting blocks Hex key size during installation. TENSOR 4.3.1 Tip glass door up and onto Sidelite glass setting blocks. -
Page 9: Adjustments
TENSOR - Wall and Glass Mount Installation Instructions Adjustments Cover caps 5 Adjustments Adjust door to “0” position Fig 10 Hex key size TENSOR Adjustment screws NOTE: Ideal “0” position 5.1.1 Remove all setting blocks. 5.1.3 Tighten adjustment screws 5.1.2 Bring door panel to ideal “0”... - Page 10 USA, Inc. 1 Dorma Drive, Drawer AC Reamstown, PA 17567 T: 717-336-3881 F: 717-336-2106 www.dormakaba.com...
