OWNER'S MANUAL
TRINITY BASICS STAINLESS STEEL UTILITY SINK
W/PULL-OUT FAUCET
Model # THA-0329 / THAPBK-0329 / THAPWH-0329
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
Intelligent Instructions
Directives intelligentes
POUR DES DIRECTIVES D'ASSEMBLAGE 3D
Instrucciones Inteligentes
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Trinity Basics THA-0329
- Page 1 OWNER’S MANUAL TRINITY BASICS STAINLESS STEEL UTILITY SINK W/PULL-OUT FAUCET Model # THA-0329 / THAPBK-0329 / THAPWH-0329 Important / Important / Importante FOR 3D ASSEMBLY INSTRUCTIONS Intelligent Instructions Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D...
-
Page 2: Parts List
PARTS LIST Your TRINITY BASICS Stainless Steel Utility Sink w/ Pull-out Faucet should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 3 ASSEMBLY INSTRUCTIONS STEP 1 A (1) D (16) B (4) Carefully lay SINK (A) upside-down on a Screwdriver not included smooth flat surface. Two people are needed. Do NOT attempt this alone. Attach LEGS (B) to four corners of sink bottom with SCREWS (D).
- Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Carefully turn sink right-side up, standing it upright. E (1) Unscrew large 3-3/8” Nut from bottom of DRAIN ASSEMBLY (E). From inside SINK (A), insert Drain through White Seal and opening at bottom. From under SINK (A), first slide on Black Gasket and Paper Gasket then screw large 3-3/8” Nut back on tightly.
- Page 5 ASSEMBLY INSTRUCTIONS STEP 4 F (1) Unscrew Lock Nut from bottom of FAUCET Spray On top of Head ASSEMBLY (F) and remove Lock Nut, White the sink Washer and Black Flat Gasket. From top side, make sure Metal Base w/ Metal Base w/ Gasket Gasket is on top of SINK (A) and all 4 hoses...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 5 Carefully move sink against wall at your desired location. If needed, G (1) H (2) I (2) use a pencil to mark off mounting height of BRACKET (G). Position BRACKET (G) on wall, marking off fastening location on wall through holes on BRACKET (G).
- Page 7 SERVICE PARTS LIST – THA-0329 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBS-19-007-1600 Bracket XBS-19-022-1700 Leg Brace XGR-01-032-0440 Anchor XBK-98-018-4080 Feet Leveler XSV-01-033-0440 Mounting Screw XBS-18-036-1816 Sink XBS-18-035-2122 Sink Skirt XGL-02-003-0002 Drain Assembly...
- Page 8 SERVICE PARTS LIST – THAPBK-0329 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBS-19-007-1600 Bracket PBK-19-021-1700 Leg Brace XGR-01-032-0440 Anchor XBK-98-018-4080 Feet Leveler XSV-01-033-0440 Mounting Screw PBK-18-036-1816 Sink PBK-18-035-2122 Sink Skirt XGL-02-003-0002 Drain Assembly ZSV-01-004-0610 Screw XBS-02-009-0008...
- Page 9 SERVICE PARTS LIST – THAPWH-0329 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBS-19-007-1600 Bracket PWH-19-021-1700 Leg Brace XGR-01-032-0440 Anchor XBK-98-018-4080 Feet Leveler XSV-01-033-0440 Mounting Screw PWH-18-036-1816 Sink PWH-18-035-2122 Sink Skirt XGL-02-003-0002 Drain Assembly ZSV-01-004-0610 Screw XBS-02-009-0008...
- Page 10 WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner.
-
Page 11: Care And Maintenance
CARE AND MAINTENANCE • Avoid harsh, abrasive cleaners, and other corrosive chemicals. Do not leave salt in sink or near saltwater environment. • Rinse surface thoroughly with hot water after using soaps and detergents containing chlorides to prevent corrosion. • Do not use scouring pad, carbon steel brushes, or steel wool for cleaning. - Page 12 © 2024 TRINITY - 800.985.5506...
-
Page 13: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY BASICS Stainless Steel Utility Sink w/Pull-out Faucet. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 14 © 2024 TRINITY - 800.985.5506...
-
Page 15: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY BASICS Stainless Steel Utility Sink w/Pull-out Faucet (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s... - Page 16 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
