IXP20 C
SPECIFICATIONS
Working Environment
Plastic Housing ............................
Power
Input Voltage ................................
Power Requirements (ISC910)
Input Voltage 12 V DC with no
Antennas attached .................
Input Voltage 24 V DC with no
Antennas attached .................
Input Voltage 12 V DC with
Antennas attached .................
Input Voltage 24 V DC with
Antennas attached .................
Power Requirements (ISC911)
Input Voltage 12 V DC with no
Antennas attached .................
Input Voltage 24 V DC with no
Antennas attached .................
Input Voltage 12 V DC with
Antennas attached .................
Input Voltage 24 V DC with
Antennas attached .................
Relay Power Requirements ........
Real Time Clock (RTC) Backup
Battery
Battery Type ...........................
ONTROLLER
ImproX IXP20 Controller
INSTALLATION MANUAL
Designed to work in an indoor (dry)
environment similar to IP40. The Controller is
not sealed against water.
10 V DC to 30 V DC, polarity sensitive.
Current (mA)
90
50
100
60
140
65
150
75
An additional ~0.4 W per Relay in use.
1 x 3 V, CR2032, Lithium cell Battery.
MODEL NUMBER: ISC910-1-0-GB-XX
Power (W)
1.08
1.20
1.20
1.44
1.68
1.56
1.8
1.8
ISC911-5-0-GB-XX
Advertisement
Table of Contents
Related Manuals for impro technologies ImproX IXP20
Summary of Contents for impro technologies ImproX IXP20
- Page 1 MODEL NUMBER: ISC910-1-0-GB-XX ISC911-5-0-GB-XX IXP20 C ONTROLLER ImproX IXP20 Controller INSTALLATION MANUAL SPECIFICATIONS Working Environment Plastic Housing ......Designed to work in an indoor (dry) environment similar to IP40. The Controller is not sealed against water. Power Input Voltage ........
- Page 2 Real Time Clock (RTC) Backup Battery (Continued) Battery Life ......1 Year with power OFF, 5 years with power ON, 5 years storage with Battery Tab in place. Controller Communication Ethernet Port ........ Standard Ethernet RJ45 connector. 10/100 Base T, half or full duplex. Terminal Communication RS485 Terminal Port Electrical Interface ....
- Page 3 Figure 1: End of Line (EOL) Sensing Circuit NOTE: End of Line (EOL) Sensing enables the Controller to raise an alarm when somebody tampers with the circuit (that is, cutting or shorting the wires) between either Reader 1 Inputs DOS [1] or Reader 2 Inputs DOS [1] and GROUND (GND).
-
Page 4: Installation Information
Find the following when unpacking the IXP20 Controller: Either an ImproX IXP20 Twin Antenna Controller with Web Interface (ISC910) supplied in a Black ABS Plastic housing. The housing consists of a Front Cover Assembly and a Mounting Plate. The Front Cover and Mounting Plate are held together with two Combi Screws (M4 x 10 mm) at the bottom of the housing. - Page 5 General Remember the following when installing the IXP20 Controller: Communications Distance The RS485 communications distance between the first IXP20 Controller and the LAST ImproX unit in a cable run, MUST NOT exceed 1 km (1 090 yd). Achieve this by using good quality screened twisted 2-pair cable, with the screen EARTHED at one end.
- Page 6 Arc Suppression Snubber devices are recommended for EMF Flyback and Arc Suppression when driving an inductive load with the Relay, see Figure 2. Figure 2: EMF Flyback and Arc Suppression Installing the Real Time Clock (RTC) Backup Battery CAUTION: Remove the Battery Tab for the Real Time Clock from the Battery Holder IMMEDIATELY BEFORE powering up the IXP20 Controller.
- Page 7 DIP-switch Settings NOTE: Once the DIP-switch settings are modified reset the IXP20 Controller to acknowledge the new settings. Door Lock Select DIP-switch Settings DIP-switch Position Connections Reserved. Reserved. Reserved. Reserved. Reserved. Returns Controller to Factory Default Settings. NOTE: Return Switch 1 to the OFF position to resume normal operation.
-
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS Key Component Positions Figure 3: Key Component Positions ISC303-0-0-GB-06 July 2011 Page 8... - Page 9 Connecting the IXP20 Controller Figure 4 shows a detailed electrical connection diagram for the IXP20 Controller. Figure 4: Typical IXP20 Controller Electrical Connections ISC303-0-0-GB-06 July 2011 Page 9...
-
Page 10: Advanced Settings
ADVANCED SETTINGS Restoring Factory Default Settings CAUTION: The procedures below are Controller specific. Ensure that you follow the correct procedure for your model Controller. Failure to do so results in loss of the Database. Restore the Controller‟s factory default settings as follows: ISC910 Remove the Controller‟s Front Cover Assembly. - Page 11 Unit Location Chart enclosed (or your sketched site plan). IP Address NOTE: All ImproX IXP20 Controllers have the same IP Address (192.168.100.1). In the absence of a DHCP server, plug each Controller into the network individually and set the static IP Address.
- Page 12 Fixed Address Label Unique Location Description ISC303-0-0-GB-06 July 2011 Page 12...
- Page 13 Fixed Address Label Unique Location Description ISC303-0-0-GB-06 July 2011 Page 13...
- Page 14 Fixed Address Label Unique Location Description ISC303-0-0-GB-06 July 2011 Page 14...
-
Page 15: Guarantee Or Warranty
Fixed Address Label Unique Location Description Table 2: Unit Location Chart GUARANTEE OR WARRANTY CAUTION: We reserve the right to nullify the products guarantee or warranty where you have not properly installed the Metal-oxide Varistors. This product conforms to our Guarantee or Warranty details placed on our Web Site, to read further please go to www.impro.net. - Page 16 This manual is applicable to the ImproX IXP20 Controller, ISC910-1-0-GB-03 and ISC911-5-0-GB-03. (The last two digits of the Impro stock code indicate the issue status of the product). IXP20\Controller\English Manuals\LATEST ISSUE\ ISC303-0-0-GB-06 Issue 07 Jul 2011 IXP20iTT-insm-en-07.docx ISC303-0-0-GB-06 July 2011...
