Recoil M1-65 User Manual

Marine speakers with rgb led system 6.5-inch
Hide thumbs

Advertisement

Quick Links

Download this manual
MARINE SPEAKERS WITH RGB LED SYSTEM
M1-65/M1-65K
Marine Speakers with RGB LED System 6.5-inch
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the M1-65 and is the answer not in the manual?

Questions and answers

Summary of Contents for Recoil M1-65

  • Page 1 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K Marine Speakers with RGB LED System 6.5-inch User Manual...

  • Page 2: Installation

    Failure to follow instructions can result in unintentional damage or product damage. To install M1-65/ M1-65K speakers, it is recommended to contact a professioanl audio installation service. Correct acoustics setting allows you to achieve excellent sound and extend the service life.

  • Page 3: Packing List

    • Use a grommet for the speaker wires (not included) when pulling through sheet metal, otherwise the wire may be damaged by the metal edges of the hole. PACKING LIST M1-65 Bill of Material M1-65K Bill of Material 6.5" Speakers X 2 6.5" Speakers X 2...
  • Page 4 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K 1 Speaker DC resistance M1-65/M1-65K 1 Speaker 3.20 2 1.60 Parallel 3 1.10 Connection 4 0.8 Mixed 3.20 Connection Measurements in Ohm (Ω)

  • Page 5: Preparing For Installation

    MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K INSTALLATION To install the M1-65 speakers, the help of a professional installation service is required. In this manual, only the basic rules for connecting speakers and technical specifications are presented. SELECTING SPEAKER LOCATIONS The choice of where the speaker will be installed has the greatest influence on sound quality.
  • Page 6 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K 1. Choose a place to install the speaker. Make sure the mounting surface is flat and fits the mounting dimensions of the speaker. Placing the speaker on an uneven surface will damage the speaker. 2. Make sure that the chosen location for the speaker does not interfere with the operation, 3.
  • Page 7 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K CONNECTION Spkeaker RGB LED Ring Adapter Cable RGB LED Controller RGB/LED Output 1 RGB/LED Output 2 RGB/LED Output 3 RGB/LED Output 4 Yellow Wire (10A) Battery or Switched +12V Red Remote In (12V) Black Ground (-12V) * Please refer to the RGBLED-4C user manual for the usage of...
  • Page 8 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K SPEAKER DIMENSIONS M1-65 Code M1-65 90.5 6-4.2 INSTALLATION DIMENSIONS M1-65 Installation dimensions（mm） Model M1-65...
  • Page 9 MARINE SPEAKERS WITH RGB LED SYSTEM M1-65/M1-65K SPECIFICATIONS M1-65 Type Marine speaker Configuration: 2-way Size: 165mm (6.5") Minimum Input (RMS): 60 W Rated Power (RMS): 120 W Peak Power: 240 W Nominal Resistance (Ohm): 4 Ω Minimum Resistance (Ohm): 3.2 Ω Mounting Depth: 66 mm (2.6") Mounting Diameter: 140 mm (5.52")
  • Page 10 ® www.RecoilAudio.com ©2022, all rights reserved. Recoil and its ® logo are registered trademarks of Ningbo AVS Industrial Company, Limited. All other trademarks are property of their respective owners. AVS Industrial assumes no responsibility or liability for damages incurred with the improper use of this product.

This manual is also suitable for:

M1-65k
