Summary of Contents for Sencor 3CAM 4K10WRD
- Page 1 3CAM 4K10WRD User Manual OUTDOOR CAMERA Uživatelská příručka OUTDOOROVÁ KAMERA Používateľská príručka OUTDOOROVÁ KAMERA Felhasználói kézikönyv SZABADIDO-KAMERA Podręcznik użytkownika KAMERA OUTDOOROWA...
- Page 2 1. Warning The product has been manufactured with a high precision and designed with respect to its multi-purpose outdoor use for individual entertainment. While recording, please observe the privacy protection laws in force, especially in your absence. Protect the product from falls and collisions, particularly with sharp and angular objects, stones etc.
- Page 3 Storage Keep in mind that this product is also designed for outdoor use where it may get dirty. Before storing the product for a short or long period of time, such as off-season, clean it carefully including the accessories and blow the dust off dirty areas. Dust may impair the contact conductivity and reduce or eliminate the product immunity to dust.
-
Page 4: Outdoor Use
Outdoor Use Before using outdoors, assemble the camera and its accessories at ease in a dry environment. Check if the camera is ready to record the scenes you want to capture and is not obstructed by any equipment or clothing parts. In this way, you can avoid the need to adjust the device and open the sealed camera housing in environment with dust, sand, rain or while wearing gloves. - Page 5 2. Introduction This product is designed for recording digital video at a very high resolution. It provides a number of superior features including digital video and still image recording, sound recording, video playback and a replaceable battery, thus becoming an ideal solution for taking photographs, recording during sport activities, diving, slow-motion recording of fast actions and time-lapse of slow actions etc., allowing you to record video at any time and anywhere.
- Page 6 Get a new quality branded tape if needed. The camera holder (bottom) was designed with ruggedness and ease of use in mind while the window unveils only part of the display. If you need to adjust the camera, remove it from the holder and put it back when done. 2.1.
-
Page 7: Putting Into Operation
3. Putting into Operation 3.1. Inserting and Removing a MicroSD Card Insert the microSD card into the camera slot with the contacts first and press until a click is heard. To remove the card, press it gently until it clicks and ejects from the slot. The remove the card from the camera with your fingers. - Page 8 Insert the battery fully into the camera (with the correct contact orientation). Make sure that the battery ribbon is still accessible. Replace the battery compartment cover (towards the camera side) and close it carefully until the latch clicks. Removing the battery: open the cover and pull the ribbon to remove the battery. Tip: We recommend to fully charge the battery (until the red LED goes out) and let it fully discharge until the camera turns off.
- Page 9 To turn the camera on or off (according to the current settings, see below), connect or disconnect the power supply. In a car, for example, this is achieved by turning the ignition key to appropriate position. 3.5. Switching the Modes To switch to the camera mode, press the following key briefly: Video Recording/Fast Event Recording/Loop Recording/Time Lapse/Photo/Photo Auto/Photo Set/Timer/.
-
Page 10: Hdmi Connection
3.6. Recording Video and Photo Shooting Recording (Video recording mode) and photo shooting (Camera) will be available if a correctly formatted memory card is inserted into the camera. This can be easily achieved by pressing OK in the camera top section while the display is enabled. If the display is disabled (PowerSave mode), pressing the first time enables the display, pressing the second time starts the required function. - Page 11 3.9. Operating Indicator Lights Blue LED – operation 1. Video recording - while recording video, the blue indicator flashes. Yellow (next to the ON 1. While connecting to WiFi, the indicator is flashing; button) LED – WiFi 2. When connected to WiFi, the indicator lights steadily. Red LED - charging 1.
- Page 12 4. PC Connection Connect the camera to your PC (Windows) USB port with the supplied cable. In addition to the battery charging, you can use the cable to transfer data. As soon as the camera detects a PC connection, a message appears with the option to select USB storage mode, PC camera, charging.
- Page 13 5. Wi-Fi Control The camera can capture video and receive basic control commands from a smartphone (Android/iPhone) using a wireless Wi-Fi connection. By default, the Wi-Fi feature is disabled to save energy. Enabling Wi-Fi (long pressing Up) will enable the camera transmitter which waits for an external control application to be connected, the display will show Wi-Fi and once the transmitter is initialized, transmitter name (WiFi- SSID) and connection message will be shown.
-
Page 14: Remote Control
Note: There is a two-point connection between the camera and the smartphone meaning that once connected to one smartphone, you cannot establish connection to another smartphone until the connection to the first smartphone is cancelled. Smartphones with Android 4.4 or higher or iOS are supported. The video being transferred slightly lags behind the real time. - Page 15 7. Camera Settings The camera settings must correspond to working in different modes. Before you start working with the camera in full, take time to test the camera and make correct settings. In this way, you will avoid possible disappointment if the work result fails to meet your expectations. You should consider whether or not the camera will move during the recording, how long the recording will take, how to power the camera etc.
- Page 16 Metering – Select the focus metering method Exposure (Exposure setting) – Select an EV number from -3 to +3 Sharpness – Select the degree of sharpening of the image Video Quality (Video Quality) – Select the quality of video storage EV –...
- Page 17 Format – matching the card to optimal use in the camera in a format suitable for making recordings. This “card cleaning” is irreversible! Note: if a card with inappropriate data format is inserted, a prompt to format will be shown; without formatting, no recording can be made. Tip: After a longer single-purpose use, it’s suitable to perform a full (slow) formatting in a PC from time to time.
- Page 18 Note: If some features or their combinations cannot work together or are illogical, their menu selection will grey out and cannot be enabled or changed. Similarly, options restricted by hardware will also remain greyed out, such as selecting a video loop for a card with insufficient free space.
-
Page 19: Technical Data
8. Technical Data LCD display 2“+ 1.3“ Lens Wide-angle HD lens with 170° field of view Video/codec formats MP4/H.264 Resolution: Recorded video resolution 3840×2160p, 60 fps 3840×2160p, 30 fps 2688×1520p, 30 fps 1920×1080p, 120 fps 1920×1080p, 60 fps 1920×1080p, 30 fps 1280×720p, 240 fps 1280×720p, 120 fps 1280×720p, 60 fps... - Page 20 Recording duration approximately 2 hours with a new, fully charged battery (and the display turned off) Charging time approximately 2 hours Dimensions 60 × 44 × 32 mm Camera weight including battery 70 g Operating temperature –10°C ~ +55°C Storage –20°C ~ +70°C Humidity 5% ~ 95% Water tightness in housing...
- Page 21 INSTRUCTIONS AND INFORMATION ON THE DISPOSAL OF PACKAGING MATERIALS Dispose of packaging material at a collection yard. DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol on the product, accessories or packaging indicates that the product must not be treated as ordinary household waste. Please dispose of this product in a collection yard designated for the recycling of electrical and electronic equipment.
- Page 22 Changes in the text, design and technical specifications may be made without prior notice and we reserve the right to make such changes. The original version is in the Czech language. Manufacturer’s address: FAST ČR, a. s., U Sanitasu 1621, Říčany CZ-251 01 EN 23 Copyright ©...
-
Page 23: Warranty Conditions
Warranty conditions Warranty card is not a part of the device packaging. This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty is limited to the following conditions. Warranty is referred only to the customer goods using for common domestic use. - Page 24 Manufacturer: FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
- Page 25 Product image / Obrázek produktu / Obrázok produktu / A kamera rézei / Zdjęcie produktu Copyright © 2024, Fast ČR, a. s. Revision 06/2024...
- Page 26 1. Objektiv 1. Objektív 1. Lens 2. Přední obrazovka 2. Predná obrazovka 2. Front screen 3. Obrazovka 3. Obrazovka 3. Screen 4. Modré světlo LED 4. Červené svetlo LED 4. Red LED - charging – provoz – nabíjanie 5. Blue LED - operation 5.
- Page 27 1. Objektív 1. Obiektyw 2. Elülső képernyő 2. Przedni ekran 3. Képernyő 3. Ekran 4. Piros LED – töltés 4. Czerwona kontrolka LED 5. Kék LED – működés – ładowanie 6. USB 5. Niebieska kontrolka LED 7. HDMI – działanie 8.
- Page 28 Copyright © 2024, Fast ČR, a. s. Revision 06/2024...
- Page 29 FAST ČR, a.s., U Sanitasu 1621, Říčany CZ-251 01...
