pro comp 58103 Installation Instructions

Ph:(619) 216-1444 Fax:(619) 216-1474
INSTALLATION INSTRUCTIONS:
⇒
PLEASE READ ALL INSTRUCTIONS FROM START TO
FINISH BEFORE YOU BEGIN INSTALLATION
⇒
Secure and properly block rear wheels prior to installation.
⇒
Check hardware list to assure your kit is complete.
BILL OF MATERIALS:
PART#
90-1001
90-1002
90-2076
90-2075
90-6050
70-0506001500
70-0505501500
70-0501501500
72-05000100816
73-05000032
1) Remove front shocks.
2) Assemble upper shock mount and position shocks as shown in illustration. The .312"
spacer will go between the original shock mount and the secondary shock. Use 6" bolt for up-
per mounts.
3) Install 1.25" spacer into factory lower shock mount and position shocks on both sides of
lower mount. Use 5 1/2" bolts for lower mounts.
4) Position upper shock mount so the new mounting holes are centered in the frame.
PRO COMP SUSPENSION, Inc. Chula Vista, CA USA
E-Mail: tech@explorerprocomp.com
DESCRIPTION
Shock Bracket (Driver)
Shock Bracket (Passenger)
.750" x 1.25" Spacer
.750" x .31" Spacer
Hardware Pack Containing:
1/2" x 6" USS Gd 5 Hex Bolt
1/2" x 5 1/2" USS Gd 5 Hex Bolt
1/2" x 1 1/2" USS Gd 5 Hex Bolt
1/2" USS Stover Nut
1/2" USS Flat Washer
Website: www.explorerprocomp.com
1
Revised: 6 /16/05
Part # 58103
'73-'87 GM 4WD
Front Double
Shock Kit
QTY.
1 ea
1 ea
2 ea
2 ea
2 ea
2 ea
4 ea
8 ea
8 ea
