ROMAN Haven6 H3SQ Series Instruction Manual

One door quadrant
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Handling
Be aware toughened glass can shatter if not handled correctly. It should not be subjected
to any sharp impact and it is essential to protect the glass by resting it on a soft protective
surface during installation such as cardboard or carpeting. It is recommended to wear PPE at
all times during installation.
Pre-Installation Checks
1.
Please take time to read these instructions prior to installing your product, including the Tray Sizes section below.
2.
Check you have the correct product, by looking at the labels on the side of the product packaging.
3.
Check all the product components and fixing kits are in the box - these are listed on the next page.
4.
Please check the product for defects or damage, once the installation has commenced we cannot accept responsibility for any
defects or damage.
5.
Before you commence any drilling check there are no hidden electrical cables and/or water pipes.
6.
No attempt should be made to re-work the toughened safety glass.
7.
The installation of the product should be performed by two persons.
8.
It is strongly recommended the product is fitted on a tiled surface or similar waterproof surface - which are tiled and grouted
before product is installed.
9.
It is strongly recommended that the walls the product is going to be installed on are vertical, and the floor/tray is level.
10. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the
glass protection pre-coating. If this does occur this can easily be removed with a soft, dry cloth.
Tray Sizes
Important: You MUST measure your tray before you proceed with installation. Please refer to the adjustment stated in the brochure
or Step 1 of this instruction manual for the adjustment details for Haven6. If your tray exceeds this given value, you may need a
bespoke product. T Your Tray must be larger than the size given for Corner Adjustments.
Refer to Step 1 for a guide on how to measure your tray accurately before proceeding any further - Roman will not be liable if you
begin installation without correctly measuring your tray, to the realisation it doesn't fit.
Consumer Guarantee
Please make sure the purchaser/end user completes and returns the guarantee card
which is enclosed with this product. Failure to validate the Guarantee will mean only the 1
Year Statutory Guarantee will apply.
Haven6
One Door Quadrant
H3SQ#

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Haven6 H3SQ Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ROMAN Haven6 H3SQ Series

  • Page 1 T Your Tray must be larger than the size given for Corner Adjustments. Refer to Step 1 for a guide on how to measure your tray accurately before proceeding any further - Roman will not be liable if you begin installation without correctly measuring your tray, to the realisation it doesn’t fit.
  • Page 2 Equipment Checklist: Not Supplied Fixing Kit Components 6X 40mm 4.5mm 90min 8X 25mm 6X 9mm 1X 2.5mm Description Qty. Description Qty. Door Seal Wall Profile Straight Panel Assembly Curved Panel Assembly Top Rail (Right Hand) Curved Panel Seal Flat Panel Seal Bottom Bearing Assembly Door Stop Bottom Rail (Left Hand)

  • Page 3: Step 2 - Pre-Installation Checks

    Step 1 - Tray Sizes Your area must be tiled and grouted before measuring your tray - refer to your tray installation instructions and ensure this is done correctly. This is because tray measurements are taken from the tiled wall. Once tray installation is complete you can proceed to measuring the area, measure the bottom, middle and top across a 1900mm height.
  • Page 4 Step 3 - Wall Profile Positioning On both wall profiles drill three 4.5mm holes through the lip. Place them 7mm in from the ① edge and approximately 100mm from each end and the other positioned in the centre. Drill this •...

  • Page 5: Step 6 - Assembling The Door

    Step 5 - Fitting the Framework & Second Wall Profile Place the remaining Wall Profile onto the end of the Framework where it is required. Gently lift the Framework onto the tray and into position, take care that the glass stays between the glass clips and the Horizontal Rails. Where the remaining Wall Profile meets the tiled wall and tray apply a generous bead of sealant.

  • Page 6: Step 7 - Fitting The Door

    Step 7 - Fitting the Door Carefully lift one assembled door into the enclosure ensuring that it is the correct way round. Position the top Wheel Bearings into the Horizontal Top Rail (you may need to have the Door at a slight angle) and drop the Door gently down.
  • Page 7 Step 9 - Door Adjustment and Sealing Close the Door and check to see if it is hanging parallel between the Panels, also check to see if the door is running smoothly. The Door can be adjusted by turning the Screws on the Top Bearing Assemblies using a screwdriver.

  • Page 8: Troubleshooting Guide

    Trouble Shooting Guide Should you experience any problems during installation please refer to the Trouble Shooting Guide or contact Customer Relations on: +44 (0) 1325 328033 To enable customer relations to provide you with an excellent level of service it is important that you quote your product Code and Reference Number - these can be found on the Guarantee card.

This manual is also suitable for:

Haven6 h3sq9Haven6 h3sq10Haven6 h3sq98Haven6 h3sq810Haven6 h3sq812Haven6 h3sq129
