- Page 1 ATS-CT-ABTL-APANTMNT1 Above Ceiling Tile AP and Antenna Mount Installation Guide ATS-CT-ABTL-APANTMNT1 VERSION 1.1...
- Page 2 ATS-CT-ABTL-APANTMNT1 Installation Guide INSTALLATION GUIDE (Above Ceiling Tile AP and Antenna Mount) Contents Overview ........................................ 2 Installation Safety ....................................2 Tools Required ....................................... 2 Parts Needed ......................................2 Installation ......................................3 Inspect Mounted Conduit ..................................3 Assemble Mount ....................................4 Overview This is a quick installation guide on how to install the AccelTex Above Ceiling Tile AP and Antenna Mount.
- Page 3 ATS-CT-ABTL-APANTMNT1 Installation Guide Installation Inspect Mounted Conduit Make sure the Mount placement is at the network drop location on the ceiling. Directions 1. Remove the ceiling tile and cut a 3 3/8” X 3 3/8” slot in the middle as shown in Fig 1. Figure 1 –...
- Page 4 ATS-CT-ABTL-APANTMNT1 Installation Guide Figure 3 – Mount, AP and Antenna Assemble Mount 3. Install the Access Point onto the AP Mount bracket as shown in Figure 2. NOTE: use the hardware that comes with the access point to secure the AP to the mounting bracket. 4.
