Assembly Instructions
Cherry Blossom Arch
Code: 25225
V2
(W x D x H) 2.00m x 0.71m x 2.50m
ONLINE ASSEMBLY VIDEO AVAILABLE
Please scan the QR code or visit zestoutdoorlivingsupport.co.uk
PLEASE KEEP THESE INSTRUCTIONS
www.zestoutdoorliving.co.uk | 01352 873555 option 1 | sales@zestoutdoorliving.co.uk
Advertisement
Related Manuals for Zest 25225
Summary of Contents for Zest 25225
- Page 1 Assembly Instructions Cherry Blossom Arch Code: 25225 (W x D x H) 2.00m x 0.71m x 2.50m ONLINE ASSEMBLY VIDEO AVAILABLE Please scan the QR code or visit zestoutdoorlivingsupport.co.uk PLEASE KEEP THESE INSTRUCTIONS www.zestoutdoorliving.co.uk | 01352 873555 option 1 | sales@zestoutdoorliving.co.uk...
- Page 2 Every Zest product is unique because each piece of timber has its own distinctive, natural features. Zest sources all of its timber from This is vital not only for the health responsibly-managed forests of the planet, but also shows Zest’s...
-
Page 3: Item Description
Cherry Blossom Arch Assembly Instructions Requires: 2 person assembly. Tools required: Corded / cordless drill, 3mm drill bit as all screw holes need to be pre-drilled, *Pozi- drive bit /Screwdriver (*Crosshead), Tape measure. Please take a few moments to check all pack contents listed Cherry Blossom Arch Pack List Code Item... - Page 4 Position ‘K’ Section (B) 50mm down from the ends of 2x Posts (A) and using 1x Trellis Panel (C) to ensure posts are parallel, attach using 4x 90mm screws as shown. Place 1x Trellis Panel (C) centrally between posts and directly beneath ‘K’ Section (B) and attach using 6x 50mm screws (1x 50mm screw to each corner and 2x 50mm screws to centre) Repeat steps 1 &...
- Page 5 Allowing an overlap of 270mm (nominal) (see Fig. 4a), position 1x board assembly flush to the top of 1x post assembly as shown in Fig. 4b. Ensure angled boards are both parallel with each other and perpendicular to post assembly with equal overlap on both sides . Fix in position using 4x 60mm screws (2x 60mm screws per board).
- Page 6 Cherry Blossom Arch is now complete. www.zestoutdoorliving.co.uk | 01352 873555 option 1 | sales@zestoutdoorliving.co.uk...
