Software Utility Installation Guide
Dynamic Image Utility 2.0
Viewer PPT Converter 2.0
Image Express Utility 1.0
Please see the Help functions of the software
programs for information about their
functions and operation.
Contents,
1. Introduction---------------------------------------------------------------- 3
• Contents of the Supplied CD-ROM ----------------------------- 3
• Projetor "Easy Connection" Settings ---------------------------- 5
• Supported Projectors --------------------------------------------- 5
• Operating Environment ------------------------------------------- 6
2. Equipment Connections and Settings ---------------------------- 7
• When Using a Network Environment ---------------------------- 7
• When Making Connections with Serial Cable ------------------ 8
3. Software Installation ---------------------------------------------------- 9
• Installation ---------------------------------------------------------- 9
• Uninstalling ------------------------------------------------------- 10
4. Starting/Exiting the Software --------------------------------------- 11
• Dynamic Image Utility 2.0 -------------------------------------- 11
• Viewer PPT Converter 2.0 -------------------------------------- 12
• Image Express Utility 1.0 --------------------------------------- 13
5. Troubleshooting --------------------------------------------------------- 14
Based on Edition 3, Jan, 2004
(End User LIicense Agreement) ------ 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dukane ImagePro 9066
Summary of Contents for Dukane ImagePro 9066
-
Page 1: Table Of Contents
Software Utility Installation Guide Dynamic Image Utility 2.0 Viewer PPT Converter 2.0 Image Express Utility 1.0 Please see the Help functions of the software programs for information about their functions and operation. Contents, Based on Edition 3, Jan, 2004 Be sure to read this before installing and using the accompanying software. (End User LIicense Agreement) ------ 1 1. - Page 2 To Our Customers When using the Projector in a network environment, please be sure to perform the various settings according to the instructions of the network administrator. • IBM and PC/AT are registered trademarks of International Business Machines Corporation. • Microsoft, Windows, PowerPoint, MS-DOS and Direct X are registered trademarks or trade- marks of Microsoft Corporation in the U.S.A.
-
Page 3: (End User Liicense Agreement)
IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT, CLICK THE "No" BUTTON. THE INSTALLATION PROCESS WILL NOT CONTINUE. Dukane grants you ("User") a license to use the DUKANE PROJECTOR USER SUPPORTWARE ("Software") provided with this End User License Agreement ("EULA"). - Page 4 In no event shall DUKANE be responsible for any indirect, consequential or special damages or lost profits even if DUKANE has been advised of the possibility of such damages, and/or for any claim for compensation or damage by any third party to User.
-
Page 5: Introduction
1. Introduction 1. Introduction Thank you for your purchase of the Dukane projector (hereafter referred to as "unit" or "projec- tor"). This projector is connected to a personal computer or other equipment and clearly projects text or graphics to a screen. - Page 6 1. Introduction Viewer PPT Converter 2.0 Converts files created with Microsoft PowerPoint 95/97/2000/2002 to an indepen- dent index format with a simple operation to enable direct playback with the viewer function of the projector. When using Microsoft PowerPoint 2000/2002, Viewer PPT Converter 2.0 can be started from PowerPoint (by means of add-in registration to PowerPoint).
-
Page 7: Projetor "Easy Connection" Settings
(Using the Easy Connection mode on Windows XP Tablet PC Edition requires the Image Express Utility version 1.01.0004 or later. ) • Easy Connection is available only when both PC and projector use the Dukane optional wireless cards. • Easy Connection is not available on Dynamic Image Utility included on the supplied CD-ROM. -
Page 8: Operating Environment
• For information on supported LAN cards, visit: http://www.nec-pj.com/ • For wireless LAN connection, use Dukane optional wireless LAN card (SWL-2100N-N*). * Last digit of the model code varies depending on which country you live in. For more information, visit the above Website. -
Page 9: Equipment Connections And Settings
2. Equipment Connections and Settings 2. Equipment Connections and Settings When Using a Network Environment © What Can Be Accomplished • Using Image Express Utility 1.0, the screen image displayed by the personal computer can be sent to the projector and then projected to a screen. •... -
Page 10: When Making Connections With Serial Cable
2. Equipment Connections and Settings © Settings at the Personal Computer Side Perform the regular LAN connections settings according to the instruction manual of the LAN card (adapter). There are no special settings to be made in the connections with the projector. When Making Connections with Serial Cable or USB Cable * USB cable connection may not be supported by some models. -
Page 11: Software Installation
"Administrators" authority. When using Windows XP, perform with "Computer Administrator" authority. • If you have Dukane Projector User Supportware (Dynamic Image Utility 2.0 and Image Express Utility 1.0) already installed on your computer, before installing the new NEC Projector User Supportware, first uninstall the current one. -
Page 12: Uninstalling
3. Software Installation If you agree, click [Yes]. • If you do not agree, please click [No] and exit the installer. Now, follow the operations described in the screen messages. • Viewer PPT Converter 2.0 will be installed together at the time of installation of Dynamic Image Utility 2.0. -
Page 13: Starting/Exiting The Software
4.Starting/Exiting the Software 4. Starting/Exiting the Software NOTE: Windows XP operations will be described in examples given here. Dynamic Image Utility 2.0 © Start the Software Preparation: Install the software on the personal computer from the supplied CD-ROM. (Page 9) The software cannot be started from the supplied CD-ROM. -
Page 14: Viewer Ppt Converter 2.0
4.Starting/Exiting the Software Viewer PPT Converter 2.0 © Start the Software Preparation: (1) Check that Microsoft PowerPoint has been installed. Viewer PPT Converter 2.0 cannot be used unless PowerPoint has been installed. (2) Install the software on the personal computer from the supplied CD-ROM. (Page 9) The software cannot be started from the supplied CD-ROM. -
Page 15: Image Express Utility 1.0
4.Starting/Exiting the Software Image Express Utility 1.0 © Start the Software Preparation: Install the software on the personal computer from the supplied CD-ROM. (Page 9) The software cannot be started from the supplied CD-ROM. From the [Start] menu click [All Programs] [NEC Projector User Supportware] [Image Express Utility 1.0]. -
Page 16: Troubleshooting
5. Troubleshooting 5. Troubleshooting • In this chapter, the software names have been abbreviated as follows: Dynamic Image Utility 2.0 to DIU 2.0, Viewer PPT Converter 2.0 to PPTC 2.0, and Image Express Utility 1.0 to IEU 1.0. <Problem> Installation does not complete normally. Check Points Countermeasures When using Windows 2000, did you log on with... - Page 17 5. Troubleshooting <Problem> You want to delete the PowerPoint add-in registration. (PPTC 2.0) Countermeasures Check Points Installing this projector software when Microsoft Please see the PowerPoint Help function for the PowerPoint 2000/2002 has already been method of deleting PowerPoint add-in registra- installed on the personal computer, will result in tions.
- Page 18 <Problem> The colors become strange when Windows is set to 256 colors. (IEU 1.0) Countermeasures Check Points Image Express Utility 1.0 does not support 256 Please set the Windows number of colors setting colors. to High Color (15 bit) or higher. <Problem>...
- Page 19 5. Troubleshooting 5. Troubleshooting Check Points Countermeasures Transmission time will be longer when the We recommend that the resolution of the resolution of the personal computer and that of personal computer and that of the projector the projector differ since there will be an increase except GT6000 be set to the same setting value.
- Page 20 Audio Visual Products Dukane Corporation Phone: (630) 762-4040 Audio Visual Products Division Orders: (800) 676-2485 2900 Dukane Drive Information: (800) 676-2486 St. Charles, IL 60174-3395 Fax: (630) 584-5156 E-mail: avsales@dukcorp.com Parts & Service: (800) 676-2487 Fax: (630) 584-0984 401-9066-00 Software Guide...
