AV Link 128.832UK User Manual

A compact 4K HDMI repeater to connect HDMI cables of up to 40m combined length with minimal signal
degradation. Combine up to 10m cable for 4K@60Hz resolution, or up to 40m for 4K@30Hz and FHD
resolutions. This updated version compatible with the latest 4K digital TV boxes producing 3840 x 2160 @
60Hz resolution.
• Maintains 4K@60Hz resolution without signal loss over combined 10m cable length
• Maintains 4K@30Hz and FHD resolution without signal loss over combined 40m cable length
• Easy connection and installation
• Supports High-Definition resolutions up to 3840x 2160 @ 60Hz
• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats
• No external power source required
• NOTE: poor quality HDMI cables will affect the maximum resolution and transmission distance
Technical specifications:
Video resolution
Display colours
Audio format
HDCP version
Max. bandwidth
Max. baud rate
Max. working current
Transmission distance
Dimensions
Weight
Application diagram:
www.avsl.com
Up to 3840 x 2160 @ 60Hz
8/10/12bit deep colour
DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD
2.2
600 MHz
3x 6Gbps
300mA
10m 4K@60Hz (5m input/5m output), 40m 4K@30Hz and 1080p (20m
input/20m output)
50 x 30 x 18mm
21g
4K HDMI Repeater
Item ref: 128.832UK
User Manual
128.832UK User Manual
