Summary of Contents for Lavor AC 71
- Page 1 User Manual Model: AC 71 Thank you very much for choosing the product of this brand! In order to use this product safely, correctly and efficiently, please read this manual...
-
Page 2: Table Of Contents
carefully and keep it properly! Table of Contents 1.Safety Signs and Precautions 2.Technical Parameters 3.Electrical Schematic Diagram 4. Production Structure 5. Installation Method 6. Operation Method 7. Water Tank 8. Drain Pipe 9. Requirements for Machine’s Work Place 10. Maintenance and Inspection 11.Fault Causes and Solutions... -
Page 3: Safety Signs And Precautions
1.Safety Signs and Precautions Meanings and Identification of signs Please read the safety signs and precautions carefully before use. The mis-operation due to ignoring the sign will cause casualties, fire or property losses. Danger The mis-operation due to ignoring the sign will cause casualties, fire or property losses. - Page 4 Please do not use the spot cooler in the places where the use or storage of volatile substances (such as diluents, gasoline, kerosene, liquefied gas and other volatile liquids, volatile dust and steam of magnesium, aluminum, lead and other metals) in case of ignition, explosion, fire, burn or other dangers.
- Page 5 Electrical installation must be carried out by the professionals in accordance with the equipment standards and wiring requirements, otherwise it will cause safety accidents. To prevent deformation of the machine, keep it away from the fire. Please equip the machine with a safe and reliable grounding wire and an earth leakage protective device.
- Page 6 Please be sure to hold the plug when unplugging the power plug, and do not pull the power line directly.Otherwise, it may do damage to the plug, generate cause spark or cause safety accidents. If you do not use the machine for a long time, please remove the power plug from the socket.
-
Page 7: Technical Parameters
2.Technical Parameters AC 71 Model 220-240V/50Hz Power Supply 7100W Refrigerating Capacity 2900W Rated Power 13.3A Rated Current 1200m Air Volume 2.5/4.5MPa Working Pressure on Suction/Exhaust Side 4.5MPa Maximum Working Pressure of Heat Exchanger R410a/1150g Refrigerant/ Refrigerant Charge 18℃～45℃ Operating Condition... - Page 8 Cold exhaust pipe Hot air outlet Head cover Display window Control panel Right-side plate Front housing Handle Water tank Bottom cover of front housing Castor...
-
Page 9: Installation Method
5. Installation Method Installation method of elbow: Align the convex part of the elbow with the concave part of the release elbow seat installed on the machine, then insert it and rotate it counterclockwise. When you hear a "click", it means that the elbow is installed in place (Figure 1). - Page 10 Installation method of hot exhaust pipe: Insert the hot exhaust pipe into the heat exhaust port and make sure that it shall be installed in place in order to make sure that the hot exhaust pipe is installed stably and firmly (Figure 2). exhaust pipe Insert it...
-
Page 11: Operation Method
6.Operation Method Full Fault Compr Set Temp. Ambient Temp. essor Low High Refrigeration Cold air Supply air Dehu SPEED MODE Timer ON/OFF POWER key Insert the power line into the AC220-240V power supply, turn on the air switch, and then the "I"power button when you hear a sound of "do-mi-sol"... - Page 12 machine only enters the air blowing state;In cold air mode, if you press and hold the "J" wind speed key an the "K"mode key for more than two seconds at the same time, the refrigeration indicator light will start flashing, the wind speed will be switched to low speed, at the moment, the low-speed indicator light will be on, and the dehumidifier mode will be enabled.
- Page 13 timing time. Note ※ The timing range is "0--24" hours. In the timing ON/OFF mode, when you press "D" key to increase the timing time, the timing hour indicated shall be display is "3-3.5-4...The 10-11-12...24"hours in order. Usage Method of Water Tank and Full-Water Alarm Hint When the water tank is full of water, the "E"...
-
Page 14: Water Tank
Notes Please adjust the outlet air direction of cold exhaust pipe and hot exhaust pipe before use.When adjusting the air outlet angle of the cold air pipe, please hold the elbow for adjustment, and never directly hold the cold air pipe for adjustment. -
Page 15: Drain Pipe
is ON, please empty the water tank and then re-install the water tank so that the spot cooler can be started and work normally. Note: Do not move the machine when the water tank is full of water. Please move the machine after the tank is empty. 8. - Page 16 When using the machine, make sure that the filter and cold air pipe should be 30cm away from the wall surface or other obstructions or more, and the hot exhaust pipe should be 90cm away from the roof or obstructions or more.
-
Page 17: Maintenance And Inspection
10. Maintenance and Inspection Please clean the filter regularly.If there is dust, dirt and other sundries on the filter, it will affect the supply air rate, and it is easy to cause frosting in the heat exchanger, which leads to the machine failure. ... -
Page 18: Fault Causes And Solutions
11.Fault Causes and Solutions 1. In case of any fault of the spot cooler, please immediately cut off the power supply and unplug the power plug from the socket to check the following items: Symptom Reason Analysis Troubleshooting Whether the power plug is Please insert the power plug into the loose of falls off power socket in place... - Page 19 from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
