  • Page 1 Version-E23-11-02 Manual VPU3400...
  • Page 2 Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cov- er all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.
  • Page 3: Table Of Contents

    Table of Contents Introduction to VPU3400 ..................... 4 VPU3400 Connection ....................5 Description of the front-panel and interface of VPU3400 ..........5 System Block Diagram ....................7 Basic Functions and Operations of VPU3400 ............8 Selection of video source .................... 8 Selection of the Display Modes .................
  • Page 4: Introduction To Vpu3400

    VPU3400 Introduction to VPU3400 The VPU3400 is a specially designed video processor for synchronic LED display. It is an image processor that can scale up and down the VGA and video images. It also does the signal selection. With the new technology of high precision A/D conversion and automatic noise reduction as well as the capability of changing from interlace to progressive scanning, the VPU 3400 boasts the function of putting out excellent video signal with high definition.
  • Page 5: Vpu3400 Connection

    Manual VPU3400 VPU3400 Connection 2.1 Description of the front-panel and interface of VPU3400 Description of the front-panel and functions of each button AC 220 V/110 V Power switch. LCD display panel. It shows basic information of the operating interface. “Exit” exit from the current menu and return to the previous menu.
  • Page 6 “S-Video” video input Notes: 1)There are two video input channels in VPU3400. Each channel accepts one video sig nal input. When different video signals are fed to the processor at the same time, the user can get the function of “Picture In Picture”.
  • Page 7: System Block Diagram

    LDU 3000 through an optical fiber. Signals like DVD, DC and TV signal should be connected to the video source input port of VPU3400, while DVI signal should be connected to the im- age port of VPU3400. Operation and parameter setting are done through the RS-232 port communication or operation on the front panel of the VPU3400.
  • Page 8: Basic Functions And Operations Of Vpu3400

    3.1 Selection of video source Before hands-on operation, we should recognize the interface below, which is shown on the LCD when the VPU3400 is under normal working circumstances. Current video source: “YPrPb”; Users can select different video sources according to their actual need.
  • Page 9 Manual VPU3400 Selection of the Video Source Steps to select a video source: Enter the function menu  Choose “Select Video”  Select the video source Properly set a video signal input on the equipment according to the video signal connection.
  • Page 10: Selection Of The Display Modes

    Manual VPU3400 3.2 Selection of the Display Modes There are six display modes: “DVI”, VIDEO, “Picture in picture-DVI on top”, “Picture in Pic- ture-video on top”, “Blending” and “Title Generator”. Usually, the user can choose the display modes of either video mode or DVI mode. Then the user can choose “Blending”, “Title Generator”...
  • Page 11: Brightness Adjustment

    Manual VPU3400 Below is one DVI output “PIP” example that is taken out from the LCD monitor. The 720x480 dotted line frames represent a LED display. On this display, there is a 360x480 video window (shown on the right) and a 360x480 image window (shown on the left).
  • Page 12: Vpu3400 Advanced Setting

    Parameters of the device are “Set Screen Size”, “Set VPU Para”, and the “Set LDU Para”. Generally speaking, the users will have to set these parameters only when the VPU3400 is being commissioned for the first time or is being initialized. After that, no more setting is re- quired.
  • Page 13: To Set The Display Window Of The Led Screen

    Manual VPU3400 2) Setting the “Set VPU Para”: It includes setting the parameters of the video “Preview” and “Ch2 X Start”. The operating interface is shown below: This parameter is mainly for “Ch2 X Start” setting of cascading. System default setting:...
  • Page 14: Setting Video Zoom Window

    When the video display window is different in size from the size of the video signal, the VPU3400 can compress and expand the video signals to match the exact screen size. VPU3400 provides 6 zooming modes: namely 16:10, 16:9, 5:4, 4:3 and 3:2 The definitions are:...
  • Page 15: Setting Video Parameters

    VPU3400 4.3 Setting Video Parameters The VPU3400 can adjust such parameters as brightness, contrast and hue on the input vid- eo signals. Different display effect can be achieved through such adjusting. Steps to set video parameters: Enter the Function menu  Select “Set video parameters”...
  • Page 16: Setting The Screen's Color Temperature

    Manual VPU3400 VPU3400 provides a default factory value restoration function. In most cases, the default pa- rameters can allow you achieve fairly good display effects. Steps to restore default video parameters: Enter the Function menu  Select “Set Video Parameter”  Select “Restore Default Values”.
  • Page 17: Gamma Correction Selection

    Sometimes you need to use more than one video processor to process the video signals. When you use three VPU3400s, for example, you need to set one VPU3400 as the master machine and two other VPU3400s as slave machines. Accordingly, you also need to set the starting column in the second channel in each slave VPU3400.
  • Page 18: Ip Setting

    We can check some of the most basic information about the video processor VPU and even the signal distributor LDU by looking up the VPU3400. This information include: 1) CPU version number of the VPU, FPGA firmware version number, serial number and IP address.
  • Page 19: Vpu3400 Self-Diagnosis

    Steps to perform self-diagnosis: 1) Use a DVI signal cable to connect the input and output terminals of the VPU3400. 2) Enter menu ”System Setting”  ”System Test”  Check the test result. 5.3 Save the Current Setting to Factory Default Value VPU3400 can save the current setting to as factory default value.
  • Page 20 Manual VPU3400 Subject to changes and misprints ALGE-TIMING GmbH Rotkreuzstraße 39 A-6890 Lustenau Austria Tel: +43-5577-85966 Fax: +43-5577-85966-4 office@alge-timing.com www.alge-timing.com Page 20...
