- Page 1 OWNER's INSTRUCTIONS MANUAL Gas Fire Table User's Guide and Instruction Manual ITEM # 70789.00-40K Noble House Home Furnishings LLC...
-
Page 2: Fire Or Explosion Hazard
Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. If you are assembling this unit for someone else, give this Owner's Manual to them to read. Noble House Home Furnishings LLC... -
Page 3: Limitation Of Warranty And Liability
This Limitation of Warranty and Liability may not be amended by any oral or written agreement. Noble House Home Furnishings LLC... -
Page 4: Safety Information
• Use LP propane tanks with the following dimensions: diameter 12 in, height 18 in - capacity 20lbs. • You must use a Propane Gas Tank that has a collar to protect the Gas Valve. Noble House Home Furnishings LLC... - Page 5 • Combustible material should NOT be within 72 inches of the top of the unit, and within 48 inches around the entire unit. Min.Clearance 48 in(1219mm) Min.Clearance Min.Clearance 48 in(1219mm) 48 in(1219mm) Min.Clearance 48 in(1219mm) Noble House Home Furnishings LLC...
- Page 6 • Keep the appliance area clear and free from combustible material, gasoline and other flammable vapors and liquids. • If the flame goes out while burning, turn the gas valve off. Wait 5 minutes before repeating the initial lighting procedure. Once you have a flame started, hold down the control knob for 1 minute. •...
- Page 7 : 1- 818-435-3985. NOTE: You must follow all steps to properly assemble this Fire Table / Column. Make sure the Gas Valve is turned “OFF” before assembling. DO NOT attempt to assemble without proper tools. Noble House Home Furnishings LLC...
- Page 8 Herebelow is an exact visual display of the Operation Tablet as found on your Fire Table / Fire Column. Read carefully before using. , ins t ead BOUTON-POUSSOIR D ALLUMAGE For Technical Support, please call: 1-818-435-3985 Monday-Friday 8 a.m. to 5 p.m. PST Noble House Home Furnishings LLC...
- Page 9 SHORTER than 5 feet. In some cases, some Customers purchases separate Gas Tank Holder to hold the Gas Tank. In this case, the 5 feet distance between the Fire Table / Column to the Gas Tank applies too. Noble House Home Furnishings LLC...
- Page 10 If you smell gas or a leak is discovered, IMMEDIATELY turn the gas valve off, disconnect Propane Gas tank. Do not use the appliance until the leak is repaired Pic B: Hose From Fire Table/ Column Noble House Home Furnishings LLC...
- Page 11 In the event of servicing and or operational issues, contact Qualified Services Technical Support and or seek Qualified Service Technician. This line art below demonstrates the internal components of the Burner. For your conveneince all of the above components are individually desribed herebelow. Noble House Home Furnishings LLC...
- Page 12 --Back Wooden frame Control Knob for door Ignitor Wooden door MGO table face Control panel Leveler Burner plate CSA Warning Ignition Pin Label Wing Screw Thermocouple with Nut Cylinder Stand Guard Metal lever Burner Nozzle Noble House Home Furnishings LLC...
- Page 13 Wooden frame --Back AAA Battery 1 pc Wooden frame for door 1 pc Protective Cover Bolt (M6*40mm) Wooden door 1 pc 13pcs Screw 7pcs Cylinder Stand 1 pc Allen Key 1 pc 1 pc Metal lever Noble House Home Furnishings LLC...
- Page 14 Tabulated herebelow are the basic steps to help you light and use your Fire Table / Column. STEP 1 1. Check that the Control Knob (16) for the gas supply system is turned to the “OFF” position before starting any assembly. Noble House Home Furnishings LLC...
- Page 15 Black Regulator Coupling Nut (24 ) clockwise. Make sure it is fastened securely and tighten connections - by HAND only. STEP 4 4. Replace and Close the Door (5) back to the Mainframe of the Fire Table / Column (C ). Noble House Home Furnishings LLC...
- Page 16 Note : Do not place more than 3KG of lava rocks above the burner holes. Doing so will suffocate the flame. WARNING To ensure proper function, the Guard (10) on the Burner (11) should never have lava rocks (B) covered over it. Noble House Home Furnishings LLC...
- Page 17 1. ) Flame color should be yellow / blue. 2. ) Flame height burns at 2 - 10 inches high. Wait 10 minutes after extinguishing flame prior to replacing a lid (if applicable) or protective cover onto the Fire Table / Column. Noble House Home Furnishings LLC...
- Page 18 8. Observe flame height when lit: 2 inches to 10 inches. 8.1. ) Flame color should be yellow / blue. 8.2. ) Flame height burns at 2 - 10 inches high. Noble House Home Furnishings LLC...
- Page 19 • Visually inspect Burner (11) for obstructions and keep tank enclosure free and clear from debris. • Place Lid (if applicable) and Protective Cover (D) on the Fire Table / Column when not in use. Noble House Home Furnishings LLC...
- Page 20 Cover your product with an outdoor Protective Cover(D) when not in use to protect it from the elements. Store your product indoors during winter months, leave the gas tank outside. Avoiding extreme cold temperatures, as extreme cold temperatures may cause cracking of the tabletop. Noble House Home Furnishings LLC...
-
Page 21: Troubleshooting
High or gusting winds Increase flame to ‘HIGH’ Flame blows out No gas flow Check that the gas tank isn’t empty easily Excess flow safety valve has See ‘Sudden drop in gas flow’ above been activated Noble House Home Furnishings LLC... -
Page 22: Warranty
• Use and installation other than what is listed in this Owner's Manual. Please contact the manufacturer for replacement parts. Part Q. CONTACT If you have any questions or concerns, our Trained Staff are ready to assist you. Contact: 1-818-435-3985 Monday-Friday 8 a.m. to 5 p.m. PST Noble House Home Furnishings LLC...
