Summary of Contents for HICOZY HIM-D4
- Page 1 USER MANUAL ICE MAKER HIM-D4 VERSION: 1.0...
-
Page 2: Table Of Contents
Contents Introduction Warnings Package Includes Diagram Specifications Installation Button Functions Instructions Maintenance Troubleshooting/FAQ Recycling Warranty Period... -
Page 3: Introduction
To get the best performance from your new bullet ice maker, please carefully read and follow all the instructions in this manual before use. We hope you enjoy your new HiCOZY ice maker! Thank you again for choosing HiCOZY. Questions or concerns? You are welcome to contact us via support@hicozy.com. -
Page 4: Warnings
Warnings HiCOZY recommends using chilled water for faster ice production. Before using, ensure the power outlet’s voltage corresponds to the value shown on the appliance nameplate. The wrong voltage will damage the product. The product should always be grounded correctly. Only use a grounded power strip with a power rating greater than 1000W. -
Page 5: Package Includes
Do not immerse any part of the product into water, or touch the plug with wet hands. To avoid frostbite, do not touch the ice-making part while in use. Do not use this product in outdoor, hot, or corrosive environments. Always use this product on a dry, even, and stable surface. -
Page 6: Diagram
Diagram Control Panel Drain Plug Air Inlet Heat Dissipation Vent Ice Basket Handle Power Cord Ice Scoop EN > 06... -
Page 7: Specifications 0
Water Tank Max Water Level Ice-Making Part Ice-Making Box Infrared Sensor Specifications Ice-Making Time 6 ~ 10 Minutes Ice Basket Capacity 1.3lbs (600g) Water Tank Capacity 47.3oz (1400mL) Working Voltage AC 115V 60Hz 1.5A (US/CA/MX) AC 220 ~ 240V 50Hz 0.8A (UK/AE) Power 110W Weight... -
Page 8: Installation
Installation 1. Open the package and take out all the accessories. 2. Place the ice maker vertically on an even surface. 3. Use a clean towel to wipe the water tank, ice basket, and ice scoop. 4. Keep the ice maker upright for 6 hours before using it for the first time. - Page 9 Water shortage This indicator illuminates when the water level is low. Full ice basket This indicator illuminates when the ice basket is full. Large ice mode This indicator will stay illuminated when choosing the large ice mode. Small ice mode This indicator will stay illuminated when choosing the small ice mode.
-
Page 10: Instructions 1
Instructions Add Water 1. Place the ice maker upright for more than 6 hours before using it for the first time. 2. Ensure the drain hole is blocked by the drain plug. EN > 10... - Page 11 3. Slowly pour 47.3oz (1400mL) of potable water into the ice basket. Note: Do not exceed the “MAX” water level indicator. Plug In Check that the power outlet’s voltage corresponds to the value shown on the appliance nameplate. After plugging in, all the indicators will flash for 1 second and then turn off.
- Page 12 Start Ice-Making 1. Press the Power Button to turn on the product. 2. Press the Mode Button to choose the desired ice size. Note If the product has been idle for a long time or if using it for the first use, please refer to the “Maintenance”...
- Page 13 Drain Water 1. Disconnect the power plug before draining. 2. Carefully move the ice maker to an area appropriate to drain water, such as a sink. （Note: Move it evenly to avoid dropping.） 3. Remove the drain plug and ensure the residual water flows into the sink.
-
Page 14: Maintenance 1
Maintenance To keep your ice tasting fresh and your ice maker clean, we recommend cleaning your ice maker at least once per week. Pull out the ice basket, and add some citric acid and water to the water tank. Then, put the ice basket back. Note: Do not use organic solvents, boiled water, strong acids, or bases for cleaning. -
Page 15: Troubleshooting/Faq
Troubleshooting/FAQ The Ice Maker Does Not Work Check if the product is powered correctly. Check if the water tank has sufficient water. Check if the compressor works. The Ice Maker Leaks Do not exceed the MAX water level when adding water. Check if the drain plug is tightly plugged. -
Page 16: Warranty Period
Labor and other charges to install and/or remove the product. Each HiCOZY Ice Maker will be free from defects in material and craft. This warranty does not cover damage from neglect, misuse, contamination, alteration, accident, or abnormal condi- tions of operation or handling.
