ESL INTELLISENSE SoloSense -ISS-SSEN-03 Quick Start Manual

INTELLISENSE™ HIGH BAY SENSORS
SoloSense™ PIR Occupancy & Daylight Harvesting – ESL-ISS-SSEN-03
Overview:
The ESL Vision ESL-ISS-SSEN-03 is a standalone PIR occupancy
and daylight harvesting sensor designed for quick installation into
our IntelliSense™ quick connect high bay lighting fixtures. This
sensor controls each fixture independently, offering simplified
management for precise lighting adjustments.
Key Features & Benefits:
• PIR Occupancy Sensing
• Daylight Harvesting
• Standalone Lighting Controls
• Remote Operated
Product Specifications:
INPUT
Input Voltage: 12 VDC
Input Current: 8mA Max
Input Power: 0.1W
Dimming: Class 2, 0–10 VDC, 10mA Max
Sinking Current: 10mA Max
OUTPUT
Output Current: 10mA Max
Output Power: 0.1W
ENVIRONMENT
Housing Material: UL 94-5VA Plastic
Location of Use: Indoor/Outdoor Use
Detection Range: 40–80 Feet Max
Mounting Height: 20–40 Feet
IR Remote Distance: Max 26 Feet
Operating Temperature: -22°F to 158°F (-30°C to 70°C)
Storage Temperature: -22°F to 185°F (-30°C to 85°C)
IP Rating: IP40
CERTIFICATIONS
Compliance: UL8750
Warranty: 5 Years
Ordering Guide:
ESL - FAMILY
ESL - ISS
(ISS) IntelliSense™ Series
FIELD INSTALLED ACCESSORIES
ESL-ISS-REM-01
Catalog Data:
ITEM #
ESL-ISS-SSEN-03
†Not All Part Numbers DLC Qualified. For a Complete Listing Please Consult the DLC Qualified Products List (QPL).
- TYPE -
- SSEN -
(SSEN) SoloSense™ (03) Highbay Sensor
IntelliSense™ remote control
DESCRIPTION
SoloSense™ – plug in sensor 3.5mm audio jack stand alone PIR occupancy and daylight harvesting sensor
Project:
Catalog #:
Notes:
MODEL
03
Page 1 of 3
Date:
Copyright © 2024 ESL Vision, LLC. All rights reserved. Rev: 06/03/24
