USER & INSTALLATION GUIDE
VYPR 3 Series
3p, 3x, DUO 3x2
GLOBAL
THANK YOU FOR CHOOSING FLUENCE!
Please confirm that all hardware and accessories received are correct for your
VYPR application before you begin the installation.
1. SYSTEM HARDWARE & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Light Fixture and Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Dimensions and Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Mounting Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 DC Power Extension Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5 DC Dimming Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6 AC Power Extension Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. CAUTIONS AND WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. IMPORTANT SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 11
4. CULTIVATION BEST PRACTICES . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. GENERAL CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6. SYSTEM WIRING DIAGRAMS AND SPECIFICATIONS . . . . . . . . . . . . . . 12
7. SYSTEM INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . 15
8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) . . . . . . . . . . . . . . . 19
8.1 Combo Mount Hanger Kit (Fixture and PSU2) . . . . . . . . . . . . . . . . . . . 19
8.2 Perpendicular Mount Kit (Fixture) . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.3 Parallel Mount Kit (Fixture) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8.4 Unistrut Hanger Kit (Fixture and PSU2) . . . . . . . . . . . . . . . . . . . . . . 21
8.5 Pipe Hanger Kit (Fixture and PSU2) . . . . . . . . . . . . . . . . . . . . . . . . 21
8.6 Square Hanger Kit (Fixture and PSU2) . . . . . . . . . . . . . . . . . . . . . . . 21
8.7 Combo Mount Hanger Kit (PSU2) . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.8 Power Supply Surface Mount Kits (PSU2) . . . . . . . . . . . . . . . . . . . . . 23
9. MOUNTING INSTRUCTIONS (DUO 3X2 CRADLE MOUNT). . . . . . . . . . . . 25
10. PRODUCT GUARANTEE & WARRANTY . . . . . . . . . . . . . . . . . . . . . . 28
© Copyright 2023 Fluence Bioengineering 102023 | Subject to change without notice
Advertisement
Related Manuals for FLUENCE VYPR 3 Series
Summary of Contents for FLUENCE VYPR 3 Series
-
Page 1: Table Of Contents
10. PRODUCT GUARANTEE & WARRANTY ..... . 28 © Copyright 2023 Fluence Bioengineering 102023 | Subject to change without notice... - Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 3: System Hardware & Accessories
1. SYSTEM HARDWARE AND ACCESSORIES 1.1 Light fixture and Power Supply SKU MATRIX FOR LIGHT FIXTURE AND POWER SUPPLY FAMILY MODEL PhysioSpec™ SPECTRUM INPUT VOLTAGE PACKAGING VYPR Gen 3 PLUS BROAD R3 (Greenhouse) 120-277V AC Bulk Pack BROAD R4 Gen 3X 347-480V AC Single Pack BROAD R6... -
Page 4: Dimensions And Weights
1. SYSTEM HARDWARE AND ACCESSORIES 1.2 Dimensions and Weights VYPR 3p VYPR 3x Length Width Height Weight Region Length Width Height Weight Region 42.17" 2.91" 3.23" 7.8 lb 24.09" 2.91" 3.23" 4.8 lb Global Global 1071 mm 74 mm 82 mm 3.5 kg 612 mm 74 mm... - Page 5 1. SYSTEM HARDWARE AND ACCESSORIES 1.2 Dimensions and Weights VYPR DUO 3x2 Cradle Mount COMPONENTS CRADLE MOUNT KITS WITH POWER SUPPLY A. Cradle Mount Kit B. T-Cable LVG & HVE Power Supplies HVG Power Supply (AMV3-10492-10) (AMV3-10493-10) C. VYPR 3x A1.
-
Page 6: Mounting Hardware
1. SYSTEM HARDWARE AND ACCESSORIES 1.3 Mounting Hardware (Sold and Packaged Separately) Power Supply Power Supply Quantity per MOUNTING HARDWARE PSU2 LVG 600W PSU2 HVG 600W Ordering Code QTY/ Carton Light Fixture 120-277V AC 347-480V AC Unistrut Wire Hanger (unistrut width ≤ 1-5/8” / 45 mm) 1 Kit 1 Kit 1 Kit... -
Page 7: Dc Power Extension Cables
1. SYSTEM HARDWARE AND ACCESSORIES 1.3 Mounting Hardware (Sold and Packaged Separately) Power Supply Power Supply Power Supply QTY/ MOUNTING HARDWARE (VYPR DUO 3x2 Only) PSU2 LVG 600W PSU2 HVG 600W PSU2 HVE 600W Ordering Code Carton 120-277 V AC 347-480 V AC 400 V AC VYPR Cradle Mount Kit for System with LVG/HVE 600W PSU2 Power Supply... -
Page 8: Ac Power Extension Cables
1. SYSTEM HARDWARE AND ACCESSORIES 1.6 AC Power Cables (Sold and Packaged Separately) AC POWER CABLE (Power Supply to AC Line) AMERICAS Quantity per Power Supply Ordering Code QTY/ Carton 6-FT (1.83 m) AC Extension Cable, NEMA 5-15P Plug, M19 Push Lock, Max 125 V AC 1 pc CACA-70748-10 10 pcs... -
Page 9: Cautions And Warnings
LED manufacturer’s bin tolerance. 2 Wattage values are typical expected values. Fluence maintains a tolerance of ±10% on flux and power specifications. Target light levels can vary from projected levels depending on ambient temperature, room reflections values and dirt accumulation. - Page 10 2. CAUTIONS AND WARNINGS scossa elettrica grazie al sistema a bassissima tensione (SELV) che non supera le tensioni SELV. E El producto protege contra riesgo de descarga electrica con voltaje bajo extra seguro (SELV) que no exceda los voltajes superiores a SELV. P O produto protege contra o risco de choque eletrico Importer: com a tensao de seguranca muito baixa (SELV), nao excedendo as tensoes acima de SELV.
-
Page 11: Important Safety Precautions
3. IMPORTANT SAFETY PRECAUTIONS 5. GENERAL CARE • The system should only be cleaned as directed in the Fluence’s Fixture VYPR lighting systems are passively cooled with zero moving Cleaning Recommendations which can be downloaded from the components. They are designed for accepted horticulture environments Fluence Support Center https://fluence-led.com/support-center/... -
Page 12: System Wiring Diagrams And Specifications
6. SYSTEM WIRING DIAGRAM AND SPECIFICATIONS VYPR 3P with Power Supply LVG, HVG AMERICAS INTERNATIONAL AC Cable AC Cable Wire Colors Wire Colors AMERICAS INTERNATIONAL Dimming Cable Dimming Cable Wire Colors Wire Colors AMERICAS INTERNATIONAL COMPONENTS Power Supply DC Power Cable to Light Fixture Light Fixture DC Dimming Signal Cable to Power Supply AC Power Cable to Power Supply... - Page 13 6. SYSTEM WIRING DIAGRAM AND SPECIFICATIONS VYPR 3x with PSE2 HV (5) VYPR 3x with PSU2 LVG, HVE Americas Americas or International AC Cable AC Cable AC Cable Wire Colors Wire Colors Wire Colors AMERICAS AMERICAS INTERNATIONAL Dimming Cable Dimming Cable Wire Colors Wire Colors AMERICAS...
- Page 14 Male M12, 3-pin Pin 4: 12VDC+ WIELAND© is a copyright of Wieland Electric GmbH. All rights reserved. Maximum Ambient Operating Temperature: 95° F /35° C SYSTEM SPECIFICATION SHEETS For complete product information and system specifications please visit https://fluence-led.com/support-center/ or email support@fluence-led.com...
-
Page 15: System Installation Instructions
7. SYSTEM INSTALLATION INSTRUCTIONS AC and DC Cable Installation WARNING: Risk of Electrical Shock. Turn off and disconnect the power before installing, moving, or cleaning to reduce the possibility of serious injury. DO NOT connect or disconnect cables to or from the power supply or LED light bar while energized. Test all cable connections for correct and secure engagement after installation. - Page 16 Optional: if connecting to a dimmer system or controller, remove the dust cap on the power supply, and connect a Fluence wet location dimming cable, i.e p/n CDMA-71561-10. CAUTION: To protect the LED ARRAY, • Do NOT remove the protective cover during installation.
- Page 17 • NE PAS mettre en contact la matrice de DEL ou le couvercle de protection avec un objet pointu ou une force qui a Fluence wet location dimming pourrait endommager les DEL. cable, i.e p/n CDMA-71561-10.
- Page 18 (Refer to Section 6). Optional: if connecting to a dimmer system or controller, remove the dust cap on the power supply, and connect a Fluence wet location dimming cable, i.e p/n CDMA-71561-10. CAUTION: To protect the LED ARRAY, •...
-
Page 19: Mounting Instructions (3P, 3X, 3X2 Remote)
8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) Front View 8.1 Combo Mount Kit (AMV3-10569-20) (For 3p, 3x AC Input Voltage 277-480 V ONLY) Suitable for pipes up to 1 3/4” (45 mm) in diameter, and for trusses or channel up to 2 3/4” (70 mm) wide. 11.48”... -
Page 20: Parallel Mount Kit (Fixture)
8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) 8.2 Perpendicular Mount Kit (AMV3-10572-20) Take (2) mounting hangers. Hang both brackets over the support structure as shown. Hold the VYPR fixture up to the hangers, perpendicular to the support structure, as shown. Hook the hanger ends on each side onto the VYPR fixture as shown between the cooling fins. -
Page 21: Unistrut Hanger Kit (Fixture And Psu2)
8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) 8.4 Unistrut Hanger Kit (AMV2-10120-20) Suitable for Unistrut up to ” (45 mm) wide. 8.5 Pipe Hanger Kit (AMV2-10121-20) Ideal for mounting under pipes up to 1 3/4” (45 mm) in diameter, or can be paired with chain or cable to suspend the fixture lower while the pipe bracket levels the fixture. - Page 22 8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) Light Fixture with Unistrut, Pipe, or Square Hanger Kit Take (2) mounting brackets. Hang a bracket over the support structure and hold up the VYPR fixture under it. While maintaining a firm grip on both, pinch the bottom of the bracket inward and insert it into the top of VYPR heatsink between the fins, release the tension of the bracket.
-
Page 23: Bracket Positions
8. MOUNTING INSTRUCTIONS (3P, 3X, 3X2 REMOTE) 8.8 Power Supply Remote with Surface Mount Kit (For AC Input Voltage 277-480 V ONLY) Surface mount brackets are PSU2 LVG 1.52” (38.62 mm) + PS Height suitable for mounting to any flat surface that will support the weight of the power supply. - Page 24 Suitable for Unistrut up to 1 5/8” (41.28 mm) wide and 1 5/8” (41.28 mm) tall. Place the power supply on a flat work surface as shown, with the “FLUENCE” name upside down. Place one bracket behind the power supply end plate and align the screw holes.
-
Page 25: Mounting Instructions (Duo 3X2 Cradle Mount)
Suitable for pipes up to 1 3/4” (45 mm) in diameter, and for trusses or channel up to 2 3/4” (70 mm) wide. Place the power supply on a flat work surface as shown, with the “FLUENCE” name upside down. Place one bracket behind the power supply end plate and align the screw holes. - Page 26 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 27 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 28: Product Guarantee & Warranty
Fluence lighting systems comply with applicable standards and are intended to be used with Fluence power supplies, cables and mounting hardware. The use of Fluence lighting systems with power supplies, cables and mounting hardware by others will limit specifications and void the warranty.
