- Page 1 B02NU display Instructions V1.1 B02NU Display Instructions Modify the record Date of version Reviser Modifications remark revision V1.1 MO,HAOQI 2023.11.02 page optimization and modification; Added factory reset menu instructions; Add battery information menu description; Add a change record; 1 / 23 Huiye IoT Technology Co., Ltd...
-
Page 2: Table Of Contents
B02NU display Instructions V1.1 DIRECTORY 一、PRODUCT INTRODUCTION ....................3 1. N ........................... 3 2. P ........................3 RODUCT MODEL 3. P ......................3 RODUCT APPEARANCE 4. P : ....................3 RODUCT PECIFICATIONS 5. T ............5 HE MAIN URFACE AND NAVIGATION INTERFACE DISPLAY 6. -
Page 3: 一、Product Introduction
B02NU display Instructions V1.1 一、Product introduction 1. Name Smart Display Controller. 2. Product model B02NU_BF_PUB 3. Product appearance 4. Product Specifications: 3 / 23 Huiye IoT Technology Co., Ltd www.huiye.com... - Page 4 B02NU display Instructions V1.1 General parameters 86.8*50.5*12.5（mm） Length*width*height size Screen size 2.4’’ Fit the handlebar 22.2/26(mm) type IPS full-view screen color screen pixel 320*240px type M5 waterproof connector connector length 20cm Operating voltage 12V-60V Operating temperature -20℃-+70℃ Core data Waterproof rating...
-
Page 5: The Main Surface And Navigation Interface Display
B02NU display Instructions V1.1 5. The main Surface and navigation interface display Bluetooth Navigatio Maintena function n features nce tips Headlight Cruise display control Battery level Gear indicatio display Real-time speed display Mileage Average Single accrual riding speed mileage ① Headlight display: headlight on/off state, display logo when the system headlight is on;... - Page 6 B02NU display Instructions V1.1 ⑥ Power Prompt: Prompt real-time power level; ⑦ Real-time speed display: real-time speed value of the vehicle; ⑧ Gear display: current gear; ⑨ Single mileage: the mileage of this ride; ⑩ Mileage accrual: The number of miles accrued Average Riding Speed: Displays the average riding speed of this time;...
-
Page 7: Button Definition
"Subtraction Key-". The key definitions are shown in the figure below: 7. Routine operations The B02NU meter provides 4 themed style UI and 8 languages for users to set, this specification is based on Theme1 and the English version is used as an example. - Page 8 B02NU display Instructions V1.1 in the power-on state, long press power button " to power down the the " system. In the shutdown state, the leakage current of the meter is less than 1uA. The boot interface is shown in the figure below.
- Page 9 B02NU display Instructions V1.1 Turn off the lights: Press and hold +" the " button when the lights are on, the screen headlight logo will not disappear, the gray display, and the headlight switch display interface is shown in the figure below.
-
Page 10: 二、Information Viewing And Setting
B02NU display Instructions V1.1 二、Information viewing and setting 1. Meter settings Click the "Power Button" key to enter the setting information list, use the "+" key or "-" key to move the cursor up and down, and select "Display Setting", "Information", Language”，“Themes”，“Password”，“Bluetooth”, “Reset Factory"... - Page 11 B02NU display Instructions V1.1 ② Automatic power off Go to the "Display Setting key or "- key to move the " menu, use the " " " cursor up and down, select Auto Off", and click the Power button" Enter the "...
- Page 12 B02NU display Instructions V1.1 Back → "Exit". " " Reset Trip clears avg, max, and time as shown in the simultaneously, following figure. ④ Backlight brightness setting Go to the "Display Setting menu use the key or "- key to move the "...
-
Page 13: Information Viewing
B02NU display Instructions V1.1 turn, and 5 is the farthest. Note: There are slight differences between different mobile phones and different environments. 2. Information viewing Information use the key or (1) Wheel Size Information——Enter " " menu, " " "- key to move the cursor up and down, select "Wheel Size", and click ".Power... - Page 14 B02NU display Instructions V1.1 (3) Meter information——Enter Information menu use the or "- the " " " " key key to move the cursor up and down, and select "Display Info". Click Power " the " Button confirm, the instrument interface displays the instrument software and "...
-
Page 15: Language Selection
" " is shown in the following figure: 4. Theme menu The B02NU meter offers 4 different styles of themes for users to choose from. Click to enter the setting information list the "Power Button" , use the "... -
Page 16: Password Settings
B02NU display Instructions V1.1 or the key to move the cursor up and down, select Themes", and click the " " " "Power Button". key or the key to toggle 1" - Theme " - Use the " " "-"... - Page 17 B02NU display Instructions V1.1 (2) Turn on the password function—— Power Button enter the click the " " to setting information list or "- key to move the cursor up and down, , use the " " key " select Password"...
- Page 18 B02NU display Instructions V1.1 Reset Password cursor and click the the Password option interface, select " " with the Power Button" to confirm " enter your old password", and interface prompts "Please use the "+" 1、 key or " key to switch the number "0-9".Click the Power Button"...
-
Page 19: Bluetooth Connection
B02NU display Instructions V1.1 ③ Bluetooth lock settings (Bluetooth unlocking is on by default). Click the "Power Button" to enter the setting information list, use the " " key or key to move the cursor up and down, select the "Password the "-"... -
Page 20: Factory Reset
B02NU display Instructions V1.1 7. Factory reset This function only restores the backlight level, light sensitivity level (if any), Bluetooth distance level, language, theme (if any) password menus, and other parameters are not restored. Select Factory Reset menu and click the "... -
Page 21: Error Code Comparison Table
B02NU display Instructions V1.1 Error code comparison table Error codes Fault description Troubleshooting methods Stop riding and check if the “02” Faulty brake handlebar brakes are back in place and for damage Check if the speed control “04” Speed control is no return... - Page 22 B02NU display Instructions V1.1 KM5S: Handlebar Check speed control “22” abnormality handlebar “23” KM5S: Motor phase loss Check the motor “24” KM5S: Motor Hall abnormality Check the motor Bafang: The torque signal of Bafang: Check the torque “25” the torque sensor is faulty...
- Page 23 B02NU display Instructions V1.1 “48” How low the SOC is (battery). Check the battery “71” The electronic lock is stuck Check the electronic lock 23 / 23 Huiye IoT Technology Co., Ltd www.huiye.com...
