- Page 1 43cc/2-CYCLE 8" GAS EARTH AUGER 3 Year Limited Warranty on tool READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS MANUAL FOR FUTURE REFERENCE. KEEP AWAY FROM CHILDREN. WEAR CSA APPROVED WEAR EAR WEAR A EYE PROTECTION PROTECTION FACE MASK...
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS 43CC/2-CYCLE 8" GAS EARTH AUGER Engine 43cc, 2 cycle Fuel Tank Capacity 28.74 oz (0.85 L) Fuel Type Unleaded Gasoline - 87 Octane or higher 2-Cycle Oil Type 2-Cycle Oil that meets or exceeds JASO - FC Specifications Fuel Mixture 50:1 (Gasoline: 2-Cycle Oil) Net Weight... -
Page 3: Table Of Contents
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER TABLE OF CONTENTS Product Specifications .................. 1 Table of Contents ..................2 General Safety Instructions ................ 3-4 Important Safety Information ..............4-7 Parts & Features ................... 8 Assembly ....................8-9 Operation ....................9-12 Routine Maintenance ................13-14 Troubleshooting .................. -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS IMPORTANT SAFETY PRECAUTIONS RETAIN FOR FUTURE REFERENCE AND READ CAREFULLY! Do not attempt to install or operate this machine until you have read the safety instructions in this manual. Safety items throughout this manual are labeled with a Danger Warning, or Caution depending on the risk type. -
Page 5: Important Safety Information
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER CONTROL AND OPERATING SYMBOLS SYMBOL MEANING CHOKE CONTROL Cold Start -Push the choke lever to the left position Run/Warm Start -Push the choke lever to the right position FUEL PRIMER Press 6 times. FUEL MIXTURE... - Page 6 use with this product. 5. Dress properly when operating Earth Auger. a. Always wear heavy long pants, boots, gloves, and a long-sleeve shirt. b. Do not wear loose clothing or jewelry that can get caught in the moving parts of the Earth Auger.
-
Page 7: Fuel Safety
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER 10. Always keep the throttle control on your right hand side, while the exhaust points away from your body. 11. Use extreme caution when using this unit. Bit thrust or Kick Back may occur when the spinning blade contacts an object that it does not immediately cut. - Page 8 3. Check for misalignment of moving parts, binding of moving parts, broken parts, mounting, and any other condition that may affect its operation. 4. Any part that is damaged should be properly repaired or replaced by a qualified service center. 5.
-
Page 9: Parts & Features
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER PARTS & FEATURES Powerhead 8" Auger Bit 6. Spark Plug 1. On/Off Ignition Switch 11. Type D Pin 7. Gear Box 2. Fuel Tank 12. 8" Auger Body 8. Air Filter Cover 3. Recoil Starter Handle 13. -
Page 10: Operation
Fig. 1 B. TO ASSEMBLE AUGER BIT TO POWERHEAD 1. Move the On/Off Switch to the off position. 2. Remove the Spark Plug boot from the Spark Plug and secure the boot away from the engine and frame. 3. Insert the Powerhead output shaft into the auger bit adapter and align the top hole of the auger bit to the hole at the output shaft. -
Page 11: Starting Engine
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER gasoline, shake container momentarily to ensure proper mixing. 6. Mix only enough fuel for your immediate needs. Do not store pre-mixed fuel. 7. Stop engine and allow to cool before refueling. 8. To fill the unit’s fuel tank with the gasoline/oil mixture, place the Powerhead upright on the ground or on a sturdy bench and wipe and any debris from around the fuel cap. -
Page 12: Starting A Flooded Engine
3. Tilt the auger to the right so that the Auger Bit is off the ground. 4. See Cold, Warm, or Flooded Engine Starting procedures below. 5. When the engine starts, raise the unit upright and with the auger bit vertical and above the location of operation for drilling. - Page 13 5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER NOTE: Follow the instruction in the Starting Position section above for the safe auger position during and after starting the engine. 3. With the Choke Lever in “Run/Warm Start” position, use right foot to hold the Throttle Lever fully depressed and pull the starter handle repeatedly until engine starts and runs.
-
Page 14: Routine Maintenance
ROUTINE MAINTENANCE A. AIR FILTER WARNING Disconnect the spark plug before performing maintenance. Your Auger has been equipped with two air filters inside the housing. Accumulated debris and dust in the air filter will reduce engine performance, increase fuel consumption and increases the risk of engine damage. Clean the air filters every 5 hours of operation. - Page 15 5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER 5. Apply anti-seize compound to the Spark Plug threads only following the manufacturer’s instructions. 6. Install the Spark Plug finger tight in the cylinder head, then tighten. Do not over tighten to 25-30 N.m.
-
Page 16: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE(S) SOLUTION(S) Engine will not 1. Ignition Switch in the “OFF” 1. Move Ignition Switch to the ON position. start. position. 2. See Starting A Flooded Engine in OPERATION 2. Engine flooded. section. 3. Fuel Tank empty. 3. -
Page 17: Exploded View
5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER EXPLODED VIEW ENGINE... -
Page 18: Parts List
PARTS LIST Key # Part Code Part Name Quan- tity AVCG011001 Two-Cycle Engine, 43 cc AVCG011002 Bolt, M6 × 20 AVCG011003 Bolt, M5 × 40 AVCG011004 Boat Washer,Ø6.5*Ø18*1 AVCG011005 Throttle Cable And Trigger Assembly AVCG011006 Handle Bar Assembly AVCG011007 Gear Box Seat AVCG011008 Bolt Assembly, M6×... - Page 19 5140-100 43CC/2-CYCLE 8" GAS EARTH AUGER AVCG011034 Cylinder AVCG011035 Bolt, M5 × 20 AVCG011036 Gasket, Cylinder AVCG011037 Spark Plug, L6 AVCG011038 Gasket, Cylinder Intake AVCG011039 Cylinder Intake AVCG011040 Bolt Assembly, M5 × 25 AVCG011041 Gasket, Carburetor AVCG011042 Carburetor Assembly AVCG011043 Bolt Assembly, M5 ×...
- Page 20 AVCG011071 Ignition Coil AVCG011072 Bolt Assembly, M5 × 20 AVCG011073 Rotor Assembly AVCG011074 Nut, M8 AVCG011075 Washer AVCG011076 Clutch Assembly AVCG011077 Washer, Spring AVCG011078 Bolt, Clutch Assembly AVCG011079 Pin, B4 × 10 AVCG011080 Magneto Cover AVCG011081 Fuel Filter AVCG011082 Fuel Tube AVCG011083 Fuel Tube, Short AVCG011084...
-
Page 21: Warranty
WARRANTY BENCHMARK GAS EARTH AUGER WARRANTY If this Benchmark tool fails due to a defect in material or workmanship within three years from the date of purchase, it has a 3-year repair warranty with the original bill of sale. This warranty does not include expendable parts including but not limited to blades, brushes, belts, light bulbs and/or batteries. - Page 22 43cc/2-CYCLE 8" GAS EARTH AUGER 3 Year Limited Warranty on tool 5140-100 BENCHMARK TOOLS CANADA Made in China ST. JACOBS, ONTARIO N0B 2N0 © 2021 Home Hardware Stores Limited CUSTOMER SERVICE/TECH SUPPORT 1-833-818-4111 * This Benchmark product carries a three (3) year LIMITED warranty against defects in workmanship and materials.
