Masson MFL TORANT 231080 Installation Instructions

Installation Instructions
Thank you for purchasing this quality MFL product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
Warranty
•
This luminaire is covered by a 3 year warranty. The warranty is from date of purchase, not the date of installation.
•
If the luminaire is not assembled and installed by a licensed electrician the warranty will be void.
•
Please retain proof of purchase and evidence of assembly and installation by a licensed electrician.
•
Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.
Installation Requirements
•
This luminaire must be assembled and installed by a licensed electrician.
•
All wiring and installation of the luminaire must adhere to latest local and national wiring rules.
eg. AS/NZS 3000 Electrical installations.
•
This luminaire is a Class I product and must be earthed.
•
Select a suitable location for installation:
- This fitting is protected against water penetration to IP65 standards, which is against low pressure jets of water
from all practicable direction. This must be maintained during installation.
- It is suitable for indoor or outdoor use.
- The mounting point must support 2 times the weight of the fitting.
•
Take care not to pull any electrical wires during unpacking as this may damage the connection.
•
Lay out all the components on a smooth surface and make sure there are no components missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
•
Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
•
Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.
Installation Directions
1. Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material. If assembly is required, lay the luminaire on a smooth non-scratch surface.
2. Use the mounting bracket as a template to mark the position of the holes onto the ceiling. Drill holes into the wall and
place the plastic anchors into the holes. (Step 1)
3. Secure the mounting bracket onto the wall with the screws provided. Ensure the screws and anchors used are
suitable for the mounting surface and the surrounding environment. (Step 2)
4. Connect the mains supply wire to the terminal connectors. (Step 3)
Mains Supply Wire
Earth – Yellow/Green
Neutral – Blue or Black
Live – Brown or Red
Ensure the wires are secure and no bare wires are exposed.
NOTE: It is recommended that a non-corrosive bead of silicone be applied before installation onto the wall
ensuring that no water can run down into the cabling.
5. Install the main body on the mounting bracket by tightening the screw with the provided allen key. (Step 4)
1 | P a g e
TORANT LED FLOOD LIGHT WITH SENSOR
SKU# 231080, 231081
Rated Voltage 220-240V~ 50Hz
Luminaire Wire / Terminal block
Yellow/Green or
Blue or N
Brown or L
v 1 . 1 ( 1 2 / 2 0 1 8 )
