Feniex Converter Instruction Manual
1.800.615.8350 / feniex.com
Spe ci f ic a t i o ns
Fl a s h Pa t ter n s
16 - pin W i re H a r n es s
I np u t Re co rd
p p. 0 3
p p. 0 3
p p. 0 4 - 0 5
p p.0 6
Advertisement
Summary of Contents for Feniex Quantum Q-0020
- Page 1 Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S. Patent &...
-
Page 2: Safety Regulations & Warranty
Feniex Industries' speakers, sirens, rocker The products described in this document panels, AM600 Beacons, Torch Lights, AI are the property of Feniex Industries, Inc. It is lightbars, AI Cubes, AM900 Work Lights, 8.5” furnished by express license agreement only Dome Lights, Cargo Lights, flashlights, Remote... -
Page 3: Specifications
BOX CONTENTS SPECIFICATIONS 1x - Feniex Converter 3.95" x 2.6" x .75" DIMENSIONS 2x - 1ft. 16-pin Wire Harnesses 2 Years WARRANTY 10-18VDC VOLTAGE Amp @ 13V CURRENT PATTERNS Attack One-One Single Figure 8 Chase Cluster One-One Triple Night Ride Crossover... - Page 4 12V+, Input 4 Blue 12V+, Input 5 Blue/White 12V+, Input 6 Yellow/Black 12V+, Input 7 Brown/White 12V+, Input 8 White/Grey 12V+, Input 9 Black/White 12V+, Input 10 Green/Grey 12V+, Input 11 Black/Grey 12V+, Input 12 Red/White Feniex Converter Instruction Manual v52824...
- Page 5 12V+, Input 20 Blue 12V+, Input 21 Blue/White 12V+, Input 22 Yellow/Black 12V+, Input 23 Brown/White 12V+, Input 24 White/Grey 12V+, Input 25 Black/White 12V+, Input 26 Green/Grey 12V+, Input 27 Black/Grey 12V+, Input 28 Red/White Feniex Converter Instruction Manual v52824...
- Page 6 Input 6 Input 20 Input 7 Input 21 Input 8 Input 22 Input 9 Input 23 Input 10 Input 24 Input 11 Input 25 Input 12 Input 26 Input 13 Input 27 Input 14 Input 28 Feniex Converter Instruction Manual v52824...
- Page 7 2. Power your Quantum product by connecting the red wire to a 12V+ terminal and the black wire to Ground. 3. Power your Feniex Converter to a 12V battery by connecting the red wire to a 12V+ terminal and the black wire to Ground.
- Page 8 Each input shows in the illustration below is a direct correlation with the inputs on the Feniex Converter. The end-user is required to map out their specific configurations to a 12V+, triggering a controller like the 4200 Data Link, Mini 4200, Typhoon, Feniex One (analog 12V+ triggers).
Need help?
Do you have a question about the Quantum Q-0020 and is the answer not in the manual?
