OPERATING MANUAL
POWER LINE
COUPLING DECOUPLING NETWORK
P/N: FCC-801-M2/M3-16A
150 kHz - 230 MHz
Fischer Custom Communications Inc.
700307 P/N: FCC-801-M2/M3-16A Rev. E
03/2019
©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the FCC-801-M2/M3-16A and is the answer not in the manual?

Questions and answers

Summary of Contents for FCC FCC-801-M2/M3-16A

  • Page 1 OPERATING MANUAL POWER LINE COUPLING DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A 150 kHz - 230 MHz Fischer Custom Communications Inc. 700307 P/N: FCC-801-M2/M3-16A Rev. E 03/2019 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...

  • Page 2: Electric Shock

    POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A SAFETY PRECAUTIONS Our objective is to maintain or improve standards of health, safety and welfare for persons at work, to protect others against risks to health, safety and welfare. To the best of current knowledge, there is no risk or safety where Fischer Custom Communications Inc.
  • Page 3 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A ADDITIONAL SAFETY PRECAUTIONS Prior to the connection of RF power or mains power conductors to the CDN, the CDN must be securely fastened to the earth ground plane. The proper grounding of the CDN prevents the following: ...
  • Page 4 EUT. Immunity measurements shall be carried out over 150 kHz to 230 MHz. The FCC-801-M2/M3-16A CDN is equipped with a push button switch on the EUT side of the CDN. This switch is used to configure the FCC-801-M2/M3-16A between the M2 and M3 Coupling sections. When the switch is pushed in and showing green the device is set to couple the RF disturbance to the M2 section on L1 and L2.
  • Page 5 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Green M2 Coupling Section M2 Switch Position Black M3 Coupling Section M3 Switch Position ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 6 ELECTRICAL CHARACTERISTICS SCHEMATIC The schematic of the M2 section of the FCC-801-M2/M3-16A CDN is shown in Figure 1and the M3 section in figure 2. All components and characteristics are in compliance with IEC 61000-4-6 annex D. COMMON MODE EUT TERMINAL IMPEDANCE...
  • Page 7 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Connect a RF test generator to the RF input connector of the CDN. D. The first step is to establish the correct setting of the unmodulated test level.  Therefore, the test generator shall be set for CW without modulation.
  • Page 8 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A EXPECTED AMPLIFIER POWER The CW amplifier power required to generate the maximum level is expected to be no more than 10 watts. This wattage takes into account a realistic maximum 10 to 16 dB attenuation value of the CDN over its 150...
  • Page 9 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Accommodations and Environmental Conditions The standard upper and lower limits of operation FCC-801-M2/M3-16A are: Low – 17 C High – 29 C Temperature: Humidity: Low – 15 % High – 80 % ** The recommended calibration interval for this unit is 1 year.
  • Page 10 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 2 Frequency band Parameter 0.15 MHz – 26 MHz 26 MHz – 80 MHz Z  150 Ω ± 20Ω 150 Ω + 60Ω -45Ω NOTE 1 Neither the augment of Z nor the decoupling factor between the EUT port and the AE port are specified separately.
  • Page 11 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 4 Note the Impedance Requirement shall be met with open and closed switch S Figure 5 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 12 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 6 M2 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 13 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 7 M3 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 14 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 8 M2 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 15 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 9 M3 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 16 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 10 M2 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 17 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 11 M3 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 18 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 12 Figure 13 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 19 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A Figure 14 ©2019 Fischer Custom Communications, Inc. All rights reserved  Printed in USA...
  • Page 20 POWER LINE COUPLING/DECOUPLING NETWORK P/N: FCC-801-M2/M3-16A CDN SPECIFICATION Frequency Range: 150 kHz -230 MHz. Supply Lines: Impedance: equency dependent 150 KHz to 26 MHz 150  20  26 MHz to 80 MHz 150 +60 -45 Published IEC 61000-4-6, Tables 3 80 MHz to 230 MHz 150...
