HW980 Handheld Fiber Laser

Welding Head User Manual

Version V1.0

Wuhan Au3tech Intelligent Technologies Co., Ltd.

www.au3tech.com

info@au3tech.com

www.au3laser.com

Daijiashan Science and Technology Park, Jiang'an District, Wuhan，China

Phone:027-82726630 Fax:027-82726630

Table of Contents

Need help?

Do you have a question about the HW980 and is the answer not in the manual?

Questions and answers

Виктор

May 13, 2025

Нет связи с контролем

1 comments:

Mr. Anderson

May 21, 2025

For connection issues with the Au3Tech HW980, follow these troubleshooting steps:

1. Touch Screen and Controller (Alarm Err-E001):
- Check that the touch screen is properly connected to Controller 1.
- Ensure Controller 1 is powered on and has started correctly.

2. Welding Head Communication (Alarm Err-W001):
- Verify the connection between the welding head and the controller is correct.
- Check if the welding head screen displays an image.

3. Wire Feeder Communication (Alarm Err-S001 – optional):
- Inspect the communication line between the controller and the stepping wire feeder.
- Power off the device, reconnect the communication interface, then power on.

4. Stepping Wire Feeder Driver (Alert Err-S002 – optional):
- Check wiring between the motor and the driver.
- Confirm the power supply voltage is 24V.

5. Stepping Wire Motor Interface (Alarm Err-S003 – optional):
- After powering off, check the connection between the motor and the interface.

These steps help resolve communication and connection errors in the system.

This answer is automatically generated

Summary of Contents for Au3Tech HW980

Page 1 HW980 Handheld Fiber Laser Welding Head User Manual Version V1.0 Wuhan Au3tech Intelligent Technologies Co., Ltd. Daijiashan Science and Technology Park, Jiang'an District, Wuhan，China www.au3tech.com www.au3laser.com Phone:027-82726630 Fax:027-82726630 info@au3tech.com...
Page 2: Table Of Contents
Beam focusing ..........15 Cleaning and maintenance ........16 Instructions for welding head control module ....23 HW980 handheld fiber laser welding control system Equipment installation and wiring......29 Main interface description ........ 34 Equipment alarm and handling ......45 Program update ...........
Page 3: Abstract
Abstract Key Points This manual covers the safe use, basic installation, factory settings, operating instructions, and maintenance services of the HW980 (handheld welding) series products. Audience This manual is mainly applicable to the following staff: ⚫ Installation Engineer ⚫ Maintenance Engineer ⚫...
Page 4: Overview
Overview This manual describes the safe use, basic installation, factory settings, operation instructions, and maintenance services of the HW980 (handheld welding) series products. There are many specific optical and mechanical custom configurations, and this manual only introduces its main unit components.
Page 5 2. Please ensure that do not look directly at the laser beam at any time or under any circumstances. Do not look at the laser emitter port directly even if wearing laser protective goggles. 3. It is forbidden to aim the laser at any human body, animal, vehicle, sky, etc.
Page 6: Product Appearance
Product appearance Figure 1 - Appearance of HW980 Structure composition As shown in Figure 2, the welding head consists of QBH connector, copper nozzle， nozzle pipe, protective glass, focus lens, reflector, collimating lens, motor, Wi-remote(control screen and buttons), etc.
Page 7 Collimating lens QBH connector Control lines and Water and Gas pipe Figure 2 - Structure of HW980 ⚫ QBH connector: Complete the access and lock of the optical fiber connector. ⚫ Collimating lens: Complete the fiber collimation function and collimate the incident laser into a parallel beam.
Page 8: Product Highlights
⚫ Focus lens: Focus the reflected beam into a convergent beam with high power density. ⚫ Protective glass: The protective glass can protect the focusing lens from the damage of returning slag and prolong the service life of the focus lens. ⚫...
Page 9: Product Configuration
Product configuration HW980 handheld fiber laser welding head is mainly used for plane processing applications within 3000W, and has very high versatile. Standard configuration model: HW980-Z50-F150. Configuration parameter Parameter name Technical index Maximum applicable laser power 3000W Optical fiber interface type Focus lens specifications（welding）...
Page 10: Configuration Checklist
Configuration checklist Product name Quantity Handheld laser welding head HW980 1set 4pcs Spare copper nozzle 5pcs Spare protective lens Note: This checklist is only for the standard factory configuration Operation steps 1. Connect the circuit between the laser, the controller, and the galvanometer driver.
Page 11: Mechanical Installation
Mechanical installation Waterway installation The HW980 handheld welding head is equipped with a set of cooling water channels. It should be noted that when the laser power is greater than 500 watts, it is recommended to use water cooling. The location and number of water-cooling interfaces can be seen in Figure 3, and the table below details the recommended water flow rates.
Page 12 Industrial pressure gauges will suck in air, and if a rubber diaphragm is used, hydrocarbons will be produced due to aging and other reasons. HW980 provides 1 way welding gas connection. The outer diameter of the gas pipe is 6mm. As shown in Figure 4 below.
Page 13: Optical Fiber Interface
HW980 is suitable for most industrial laser generators. It is equipped with a collimator lens assembly. The connection between the end of the optical fiber and the welding head is called the optical fiber connector. HW980 comes standard with QBH optical fiber connector, as shown in Figure 5 below.
Page 14 Figure 5 HW980 optical fiber input interface - QBH Note: The optics must be kept clean, and all dust must be removed before use. If the welding head is to insert the optical fiber vertically, the welding head must be rotated 90 degrees to a horizontal position, and then insert the optical fiber to prevent dust from entering the interface and falling on the surface of the lens.
Page 15: Beam Focusing
Figure 6 HW980 QBH fiber optic connector insertion and locking diagram Beam focusing Adjust the focus position The welding head can adjust the focus position. The adjustment method is to rotate the locking ring counterclockwise. After loosening, adjust the length of the copper nozzle to obtain the required spot energy.
Page 16: Cleaning And Maintenance
Spot centering adjustment Adjust the light spot to the horizontal center position of the nozzle. Adjustment method: power on the HWS980 galvanometer handheld welding system and then set the "Width" to 0mm on touch screen → click "advanced parameters" → enter the password "2000" → click "ENTER" → set the "optical core offset" parameter.
Page 17: Clean The Lens
It is recommended to check it before each use. Please refer to Figure 9 for lens structure. Figure 9 HW980 protective glass module split diagram ■ Lens cleaning tools： Dust-proof gloves or finger cots, polyester cotton swabs, absolute ethanol, rubber air blower (clean compressed air), etc.
Page 18 （3）Gently pinch the side edge of the lens with the thumb and index finger of the left hand. (Note that the finger cot cannot touch the surface of the lens to avoid leaving traces); （4）With the lens facing both eyes, hold the polyester cotton swab in your right hand, gently wipe the lens from bottom to top or from left to right in a single direction (do not wipe back and forth to avoid secondary pollution of the lens), and use rubber air blower (clean compressed air) blows the surface...
Page 19 Protective glass cover Sealing ring D20.55X2.3 Protective glass D20X3 Picture 10 HW980 protective glass split diagram ■ Disassembly and assembly of the upper protective glass and focusing lens: （1）As shown in Figure 11, pinch both sides of the drawer-type lens holder and slowly pull out the focusing lens drawer;...
Page 20 20.55 sealing ring Protective glass D20X3 Focusing lens D20-F150 Figure 11 Split diagram of upper protective glass and focusing lens on HW980 ■ Direction of protective glass drawer and focusing lens drawer: Please pay attention to the direction when inserting the drawer.
Page 21 Replace the copper nozzle: In the process of laser welding, the nozzle will touch the welding pieces and rub against the metal parts. Nozzle is consumable accessory and needs to be replaced after a period of use. The nozzle equipped is a combination nozzle, which is composed of a stainless-steel bottom tube and a copper nozzle.
Page 22 Loosen the thumb screw, then replace the nozzle module with a cleaning dustproof hood. Replace the focus lens module (D20-F150) with the focus lens module (D20-F600) Cleaning focus lens module - F600 Cleaning dustproof hood Welding focus lens module – F150 Nozzle module Thumb screw 2.
Page 23: Instructions For Welding Head Control Module
Enter the cleaning interface. After switching to the cleaning mode, the light can be emitted only when the ground wire clamp is clamped on the wire feeding assembly. Click "switch to welding mode" in the upper right corner of the cleaning interface to switch to the welding interface.
Page 24 2. Click the "controller config" button to enter the controller configuration interface. 3. Select "Welding gun handle configuration" to enable the control function of the welding head. Instructions for use of handheld welding head control module Operation instructions for the welding gun control...
Page 25: Function Introduction
module Display screen Left button Right button Ok button 1. Display screen: Display parameter functions and other human-computer interaction interfaces. 2. OK button: short press to enter the parameter editing state. Each time you press it, the next parameter item is selected. When the selected parameter flashes, set the parameter by the left or right button.
Page 26 ⚫ 2. Light emitting mode: (status: spot\continuous\swing) ⚫ Corresponding to the touch screen "laser mode" parameter, the "continuous" light mode, "spot" light mode, and "swing" light mode can be adjusted. ⚫ 3. Laser power: (range 0%-100%) ⚫ Corresponding to the "peak power" parameter of the touch screen, adjust the maximum power during the stable light emission period.
Page 27 Adjusting the light spot size of the handheld laser welding head 1) Set "WobbleFreq". The larger the parameter setting, the faster the spot swing frequency. 2) Set "WobbleWidth". The larger the parameter setting, the greater the swing amplitude of the spot. 3) Turn on the "LightSpot Wobbling".
Page 28: Hw980 Handheld Fiber Laser Welding Control System
HW980 Handheld Laser Welding Control System Manual For Holding Welding System Equipment (control part)
Page 29: Equipment Installation And Wiring
version：V1.00 1、 Equipment installation and wiring Wiring instructions for touch screen terminals USB flash drive upgrade interface Communication interface Power connector Coin cell batteries Touch screen wiring terminal Terminal wiring instructions: Power terminal: The screen uses 24V DC power supply. The terminals from top to bottom are: power supply positive, power supply negative, and ground wire.
Page 30 Controller wiring terminal description Controller wiring terminal For detailed description of the controller terminals, please refer to the table below. Controller terminal description Port Input/ screen Terminal description Output Definition printing 24VI POWE Controller DC24V power PGND input PWM+ DC24V\DC5VPWM output CON1 signal PWM-...
Page 31 (The output amplitude can be configured) 0 ～ 0～10V\0～4V analog output 10V(0 ～ 4V) signal (The output range can be AGND configured) DC24V laser enable output signal LA-EN- CON2 GAS+ output connected to solenoid valve to control blowing GAS- (Drive current Max 2A) ALM+ Laser alarm input port (DC24V high level valid) ）...
Page 32 Welding head power supply RS485- IN/OU Welding head communication RS485- CON5 Connect the handheld laser head switch button. Close to emit light. (Short-circuit two points to produce light and gas) IN/OU USB interface (U disk download) RS485- IN/OU Touch screen RS485 Screen communication interface...
Page 33 DRV- enable output Water cooler alarm input SW-IN- CTRL1 Reserved CTRL1- CON9 CTRL2 DC wire feeder control port CTRL2- Reserved output CON10 Reserved input CON11 Definition of controller wiring terminal In order to improve the safety performance of the product, the hand-held welding head adopts the method of contacting light, that is, the welding head...
Page 34: Controller Wiring Diagram
and the welding workpiece must be in contact, and the light can be emitted after pressing the light switch of the hand-held welding head. Controller wiring diagram System wiring diagram 2、 Main interface description Homepage After the system is powered on and initialized, the welding work interface is entered by default.
Page 35: System Setting Interface
page interface. Under the home page interface, you can enter the system settings, start welding, and controller configuration interfaces. System Setting Interface Click the "System Settings" button under the home page interface to enter the system settings interface. "System Upgrade": Please refer to the program update part for details. "Language switch": This system supports simplified Chinese, traditional Chinese, English, Japanese, Korean, Turkish, Vietnamese, Slovak, Hungarian, Polish, Russian, Spanish, Portuguese, Slovenian, Croatian, French, German.
Page 36 "Version Information": Display the current system's touch screen version, controller software version, and controller hardware version. "Product Activation": Query the current device ID and encryption status. The activation code is divided into six segments, each with 4 digits. After entering the correct activation code, click "Activate" to update the encryption time or permanently decrypt.
Page 37 Welding handle configuration: Choose to enable or disable the welding head control module (for users using our HW980 series handheld laser welding heads, please set this option to enabled). Temperature monitoring configuration: Select whether to enable detection of focusing lens temperature.
Page 38 default, as shown in the figure below: The welding work interface is the most used interface for users. Under this interface, users can set parameters, turn on/off enable control, switch working modes, and light emitting methods. Output power of the welding head = laser power x peak power x PWM duty cycle Click the "LaserMd"...
Page 39 light will be emitted only once per press. The light emission time is determined by the spotting time. If you need to spot the light again, you need to release the switch and press the light switch again. Swing: after the laser is enabled, the light emitting conditions are met, the light spot swings slowly to achieve the effect of scale pattern.
Page 40 wire feeding, if the wire feeding is turned on, the wire will be fed automatically during the light emitting process, and the wire will stop automatically when the light is stopped. "Wire feeding direction" button: It can be switched to wire feeding and wire return.
Page 41 1. Turn on the laser enable; 2. The LA-ON-pin of the controller is connected to the metal welding workpiece through a wire (refer to the device wiring chapter); 3. The tip of the gun contacts the metal welding workpiece; 4. Press the light control switch of the welding gun; 5.
Page 42 Common process interface Select a material Displays the laser Select a power thickness Click the "PARAM" button under the welding interface to enter the process selection interface. The process interface can store 4 materials, 18 thicknesses, and 6 types of processes.
Page 43 Click the "Customize" button under the common process interface to enter the process selection interface. The customized process interface can store 9 groups and 6 types of processes. After selecting a certain group of processes, click "Apply" to directly export the process parameters of this group to the welding work interface.
Page 44 from the starting power to the peak power); 3)Laser power Set the power of the laser. 4) Power ramp down Set the power slow-down delay (the time it takes for the output power to drop from the peak power to the cut-off power). Note: Only the system with optional wireless control module has the power slow down function! 5) Power start:...
Page 45: Equipment Alarm And Handling
Open/close solenoid valve 11) Off centering Adjust the lateral offset of the optical core 12) Wire retract when light off: After the light emission stops, the welding wire will automatically return to a certain length to facilitate the next welding. The length of the retracted welding wire is determined by the set parameters.
Page 46 indicator light will only disappear after all alarms are cleared (currently no alarms), as shown in the following figure: Alarm not cleared Alarm cleared Solutions to the warning Once the equipment is alarmed, the user must stop using the handheld laser welding equipment immediately and troubleshoot the fault.
Page 47: Program Update
Check the communication This alarm Alarm Err-S001: Wire line between the controller and is only for the feeder communication the stepping wire feeder, and optional failure! plug the communication interface stepping wire again after power off. feeder. This alarm Check the line connection AlertErr-S002: is only for the between the motor and the drive,...
Page 48 Insert the USB drive with updated files into the USB interface on the back of the touch screen, wait for the screen to display the upgrading interface, wait for the program upgrade to complete, and then unplug the USB drive. Controller program update Click on the "Home"...
Page 49 2) The progress bar indicates the current update progress. After the program update is completed (100%), follow the prompts to remove the U disk and restart the system; 3) If the update fails, you can click the "Start Update Button" again. Notice: 1) The update files of the touch screen and the controller should be placed in the root directory of the U disk, as shown in Figure 6-4.
Page 50: Product Size
5、 Product size Touch screen dimension drawing (unit: mm) Controller dimension drawing (unit: mm)
Page 51 MARS9000P Laser Welding Automatic Wire Feeder User Manual...
Page 52 Thank you for purchasing the multifunctional laser welding automatic wire feeder manufactured by our company. In order to use this wire feeder correctly, you should carefully read the safety regulations and detailed instructions before use!
Page 53: Safety Rules
1．Safety rules: Warning: This machine is connected to power. Unsafe procedures and operations may cause personal injury or death! All users, operators and support personnel of this equipment must read and understand these safety rules. 1.1 To prevent electric shock: Contact with live parts will cause serious injury and fatal blow.
Page 54 11. During welding, the metal part of the guide wire tube is charged, please do not touch it. 1.2 Provides protection against fumes and gases: Breathing fumes and harmful gases will harm human health. 1. Keep your head away from fumes. 2.
Page 55 1.4 Prevent arc rays from damaging eyes and skin, and prevent noise from damaging hearing: The welding arc generates intense radiant heat and ultraviolet light that can burn eyes and skin. Noise from work processes can damage hearing. 1. Wear a helmet with an appropriate shade of filter; 2.
Page 56: Performance Advantages And Configuration
2. Performance advantages and configuration 2.1 Performance advantages Laser welding automatic wire feeder is a device dedicated to laser welding for wire filling without preheating. 1、It is controlled by an industrial-grade high-speed microprocessor, with automatic memory storage, strong anti-interference ability, stable performance, and easy operation. 2、Light, small and convenient 3、The welding head control module can adjust the feeding speed, manual wire feeding, and manual retraction.
Page 57: Machine Fault Diagnosis And Solutions
Supply voltage: DC 24V Power: 72W Wire feeding speed range: 1mm/S-55mm/S (adjustable) (the upper limit can be increased as needed) Motor type: DC24V stepper motor, reduction ratio 8 Speed regulation method: digital open loop speed control Applicable welding wire diameter: 0.8mm, 1.0mm, 1.2mm, 1.6mm, 2.0mm Dimensions: length 520*width 245*height 420 Weight: 13KG 3.
Page 58 The wire feeding motor is broken Replace the wire feeding motor Used up of welding wire Replace the welding wire reel shaft locking fault/Loose drive Re-plug the socket board motor plug Loosen the pressing wheel and rewind Welding wire knotting the wire Wire feeding hose knotting Straighten the wire feeding hose...
Page 59: Wire Feeder And Welding Machine Connection Installation
The curvature angle of the wire Straighten the wire feeding hose as feeding hose is less than 30 degrees much as possible Wire feeding hose deformed Replaced the wire feeding hose after extrusion Other fault phenomena Difficult to describe Return to the manufacturer for repair 4.
Page 60: Routine Maintenance
wire out of the wire guide tube interface of the wire filling machine, insert it into the inlet end of the wire feed tube, and tighten the nut at the inlet end of the wire feed tube to the wire feeder. 5、Disassemble the wire filling nozzle on the wire feeding tube.
