Summary of Contents for Innova EF39FMPF
- Page 1 FOR MODELS: EF39FMPF, EF61FMPF FLUSH MOUNT KIT INSTALLATION MANUAL PLEASE SAVE THIS MANUAL FOR FUTURE REFERENCE. READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL. KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE. Version 20220224...
-
Page 2: Warnings
Note: Innova Heating Co. reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form with prior written consent from Innova Heating. www.InnovaHeatingCo.com... -
Page 3: Table Of Contents
Contents Contents WARNINGS .....................Page 2 GETTING STARTED ..................Page 4 INSTALLATION INSTRUCTIONS ..............Page 5 Step 1: Installation of the fire retardant drywall pocket ......Page 5 Step 2: Establishing an electrical connection..........Page 6 Step 3: Install the flush mount frame into the drywall pocket ....Page 7 Step 4: Completing an electrical connection ..........Page 8 Step 5: Install heater into the flush mount frame ........Page 9 Step 6: Decorative trim ................Page 11... -
Page 4: Getting Started
Getting Started This flush mount kit is designed to work with the EF40, EF50 and EF60 heater series. Innova Heating Co. offers two frame sizes; a 39-inch and a 61-inch, which can house the heaters with wattages ranging from 4000 to 6000 watts. -
Page 5: Installation Instructions
Installation Instructions STEP 1: Installation of the fire retardant drywall pocket The first step to install your flush mount kit is the installation of a one-hour rated fire retardant drywall (or otherwise known as Type X) to line the pocket, which will help to contain the heat of the unit. -
Page 6: Step 2: Establishing An Electrical Connection
Following this step, you will be ready to set up the final electrical connection. If needed, longer lengths of high temperature whips can be purchased from Innova Heating Co. or your distributor. Beam... -
Page 7: Step 3: Install The Flush Mount Frame Into The Drywall Pocket
Installation Instructions STEP 3: Install the flush mount frame into the drywall pocket There are two ways the flush mount frame can be installed into the fire-retardant pocket: 1) Drill through the internal flanges and secure it to the inside of the pocket with wood screws that are a minimum of 2 ½... -
Page 8: Decorative Trim
Installation Instructions Installation Instructions STEP 4: Decorative trim Decorative trims are suitable with our heaters, please leave a minimum 1/2” clearance to allow heat dissipation through the ventilation holes. Heater Minimum 1/2" Minimum 1/2" clearance clearance from decorative trim to allow heat dissipation through the ventilation holes... -
Page 9: Step 4: Completing An Electrical Connection
Installation Instructions STEP 5: Completing the electrical connection Reconnect all wires and attach the door plate to cover the wires before installing the heater into the metal frame. Tighten (4) screws to secure junction box with the heater www.InnovaHeatingCo.com... -
Page 10: Step 5: Install Heater Into The Flush Mount Frame
Installation Instructions STEP 6: Install heater into the flush mount frame Prior to the final heater installation, use the L-shaped bracket to adjust the heater’s height. The bracket has vertical mobility, allowing the heater to be raised and lowered to match the height with the finished ceiling. - Page 11 After www.InnovaHeatingCo.com...
- Page 12 info@InnovaHeatingCo.com 1-800-660-5391 T. 905.695.2055 33 West Beaver Creek, F. 905.695.2056 Richmond Hill, ON L4B 1L8...
