- Page 1 DRAKE GOLF, COMMERCIAL & LIFESTYLE CARTS OWNER’S / OPERATOR’S MANUAL READ THIS MANUAL CAREFULLY! It contains important safety information. DK L617 SERIES 48 VOLT GOLF CARTS ALL MODELS Drake_Manual.indd 1 2017/03/06 10:47 AM...
- Page 2 INTRODUCTION Congratulations on your purchase of a DRAKE golf cart. DRAKE vehicles are designed and built to provide the ultimate in performance efficiency; however proper maintenance and repair are essential for achieving maximum enjoyment from your new DRAKE Golf cart.
-
Page 3: Important Manual Information
If you have any questions concerning this manual, please consult your DRAKE dealer. DRAKE reserves the right to change specifi cations and designs at any time without notice and without the obligation of making changes to units previously sold. - Page 4 NOTES...
-
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT LABELS SAFETY OPERATOR SAFETY SAFETY CONSIDERATIONS MAINTENANCE REQUIRED FOR GOLF CAR SAFETY SAFETY PRECAUTIONS DURING MAINTENANCE BATTERY STORAGE AND CHARGING CONTROLS OPERATION PROCEDURES PRE-OPERATION OPERATION MAINTENANCE STORAGE SPECIFICATIONS WARRANTY... -
Page 6: Important Labels
• Come to a complete stop before reversing direction. • Read the Owner’s/Operator’s Manual for more information. ATTENTION • This vehicle was not manufactured for use on public streets and does not comply with Federal motor vehicle safety standards applicable to passenger cars. DRAKE... - Page 7 IMPORTANT LABELS...
-
Page 8: Safety
SAFETY SAFETY CONSIDERATIONS Many vehicles are used for a variety of tasks beyond the original intended use of the vehicle. No warnings can take the place of good common sense and prudent driving practices. PRE-OPERATION SAFETY Read this Owner’s/Operator’s manual and observe all warnings and opera- tion instruction labels affi xed to the vehicle. - Page 9 SAFETY SAFETY CONSIDERATIONS This section contains broad safety practices required for safe golf car operation. If you are responsible for the operation and maintenance of this golf car, we recommend you implement this golf car safety program. Allow only authorized people to operate golf cars. It is recommended that only people who possess a valid motor vehicle driver’s license be allowed to operate golf cars.
-
Page 10: Maintenance Required For Golf Car Safety
SAFETY MAINTENANCE REQUIRED FOR GOLF CAR SAFETY This section contains broad safety practices required for safe golf car operation. If you are responsible for the operation and maintenance of this golf car, we recommend you implement this golf car safety program. Preventative Maintenance. -
Page 11: Safety Precautions During Maintenance
Provide operator comment cards to assist in identifying non-periodic maintenance needs for specifi c golf cars. Maintain in a legible condition all nameplates, warnings, and instructions provided by the manufacturer. If new nameplates, warnings, or instructions are needed, contact your Drake Golf, Lifestyle and Commercial Carts Company dealer. -
Page 12: Battery Storage And Maintenance
SAFETY BATTERY STORAGE AND MAINTENANCE The following precautions must be adhered to in order to ensure Maintenance worker safety. Only use battery charging facilities and procedures that are in accordance with applicable ordinances and regulations to avoid explosions, electrical shock or damage to the electrical system. Periodically inspect charging facilities and procedures to be certain that applicable safety codes, regulations, and procedures are being followed to avoid any fi res or explosions. -
Page 13: Controls
CONTROLS MAIN SWITCH The main switch controls the following items: “OFF” All electrical control circuits are switched off (controller remains energized). The golf car cannot be operated. The key can be removed only in this posi- tion. “ON” Electrical circuits are switched on. The golf car can be driven. 48 V VOLTAGE INDICATOR 48 V... -
Page 14: Park Pedal
CONTROLS PARK PEDAL Press down on the park pedal whenever car is stationary. NOTE Disengage the parking brake by depressing the accelerator pedal. WARNING The parking brake will automatically disengage if the accelerator pedal is depressed. If the main switch is in the “ON” position, depressing the accelerator may suddenly cause the golf car to move. -
Page 15: Pre-Operation Procedures
PRE-OPERATION PROCEDURES OPERATOR SAFETY Pre-operation checks should be made each time you use your golf car. Get into the habit of performing the following checks in the same way so that they become second nature. WARNING To keep car from moving while performing pre-operation checks: Remove main switch key. - Page 16 • turning the steering wheel slightly to the right and left. If you feel excessive free play, or hear rattling sounds which may indicate loose steering com- ponents, consult a DRAKE dealer. REVERSE ALARM Check the reverse alarm by moving the drive 48 V select switch to “REV”...
-
Page 17: Operation
OPERATION PROCEDURES STARTING 1. With the parking brake applied, turn the drive 48 V select switch to “FWD” for forward, or “REV” for reverse. CAUTION Do not shift from “FWD” forward to “REV” reverse while the golf car is moving. Transmission damage can result. -
Page 18: Maintenance
MAINTENANCE BATTERY CARE WARNING Battery electrolyte is poisonous and dangerous, causing severe burns, etc. It contains sulphuric acid. Avoid contact with skin, eyes, or clothing. Antidote: EXTERNAL: Flush with water. INTERNAL: Drink large quantities of water or milk. Follow with milk of magnesia, beaten egg, or vegetable oil. - Page 19 3. Using a hydrometer, check the specifi c gravity of the battery fl uid in each cell against the readings on the chart below. Consult a DRAKE dealer if any low readings are found, or if readings vary more than one point between cells.
-
Page 20: Battery Charging
MAINTENANCE BATTERY CHARGING The battery charger is designed to fully charge the battery set. If the batteries are severely deep cycled, some automatic battery chargers contain an elec- tronic module that may not activate and the battery charger will not function. Automatic chargers will determine the correct duration of charge to the battery set and will shut off when the battery set is fully charged. -
Page 21: Transaxle Oil
MAINTENANCE TRANSAXLE OIL The only maintenance required for the fi rst fi ve years is the periodic inspection of the lubricant level. The rear axle is provided with a lubricant level check/fi ll plug located on the bottom of the differential. Unless leakage is evident, the lubricant need only be replaced after fi ve years. -
Page 22: Brake Pedal Free Play Adjustment
WARNING Consult your DRAKE dealer before using your golf car if you suspect any brake problems. Brake failure could result in a serious accident. Death or serious personal injury can result from failing to comply with the safety instructions in this manual. -
Page 23: Maintenance Charts
When in doubt the work should be done by a Drake dealer or other qualifi ed mechanic. CS – CHECK CA – CHECK & ADJUST R – REPLACE S – SERVICE CL – CLEAN & LUBRICATE L – LUBRICATE... -
Page 24: Storage
STORAGE Perform the following preparations when not using your golf car for extended periods of time: NOTE Turn the main switch key to the “OFF” position, lift the seat and move the tow switch into the “TOW” position. Remove the key from main key switch, and store key in a safe place. - Page 25 NOTES...
- Page 26 SPECIFICATIONS MODEL DK LUX-L617.2 SYSTEM 48V 4.0KW AC system Key Components . 4.0 C motor l l o Curtis 1234e (275A) Performance y t i at road @ 20 km/h 80-90 km i n i i l c t i l i <...
-
Page 27: Specifications
SPECIFICATIONS MODEL DK LUX-L617.2+2 SYSTEM 48V 4.0KW AC system Key Components l l o Curtis 1234e (350A) Performance y t i at road @ 20 km/h 80-90 km i n i i l c t i l i < 6 Dimensions *photo for reference only l l a... - Page 28 SPECIFICATIONS MODEL DK RA-L617.2+2 SYSTEM 48V 5.0KW AC system Key Components l l o i t r s 1234e (350A) Performance y t i Range (loaded) based on flat road @ 20 km/h 80-90 km i n i i l c t i l i <...
- Page 29 SPECIFICATIONS MODEL DK RA-L617.4+2 SYSTEM 48V 5.0KW AC system Key Components l l o s i t 1234e Performance y t i at road @ 20 km/h 70-80 km i n i 5.05 i l c t i l i <...
- Page 30 SPECIFICATIONS MODEL DK FLEET-22G SYSTEM 48V 4.0kW D.C. system Key Components KDS 4.0kW D.C. motor l l o Curtis 1234 (275A) Performance y t i at road @ 20 km/h 60-70 km 30 km/h i n i i l c t i l i 460 kgs Dimensions...
- Page 31 SPECIFICATIONS MODEL DK LUX-L617.4+2 SYSTEM 48V 5.0KW AC system Key Components 5.0KW AC Motor l l o is 1234e (350A) Performance y t i Range (loaded) based on flat road at road @ 20 km/h 80-90 km 25 km/h i n i i l c t i l i <...
- Page 32 SPECIFICATIONS MODEL DK LUX-L617.6+2 SYSTEM 48V 5.0KW AC system Key Components C motor l l o s i t 234e Performance y t i Range (loaded) based on flat road at road @ 20 km/h 70-80 km i n i i l c t i l i <...
- Page 33 SPECIFICATIONS MODEL DK U-L617.H2 SYSTEM 48V 4.0KW AC system Key Components 4.0KW AC Motor l l o s i t 1234e (350A) Performance y t i *photos for reference only at road @ 20 km/h 80-90 km i n i i l c t i l i Dimensions...
-
Page 34: Warranty
DK L617 series electric DRAKE golf car purchased from an authorized DRAKE golf car dealer in South Africa will be free from defects in material and work- manship for THREE years from date of purchase, subject to the stated limitations. - Page 35 Operate and maintain the golf car and charger as specified in the appropriate Owner’s/Operator’s Manual; Give notice to an authorized DRAKE golf car dealer of any and all apparent defects within ten (10) days after discovery, and make the vehicle or charger available at that time for inspection and repairs by the Drake’s authorized representative.
- Page 36 DRAKE GOLF, COMMERCIAL & LIFESTYLE CARTS DRAKE Golf, Commercial & Lifestyle Carts Head Office: 1 Estee Ackerman Street, Jet Park, 1459 CONTACT US: +27 11 397 1191 This manual may not be reproduced in any way, whole or in part, without the express permission of DRAKE GOLF CARTS Company.
