- Page 1 EXOR International Industrial Computing Solutions Fanless Computer eCC104 User Manual www.exorint.net...
-
Page 2: Table Of Contents
LAN1 Port ..................16 Knowing Your eCC104 ................3 LAN2 Port ..................17 Mechanical Dimensions ................5 Internal Connectors ................17 NISB 104 ...................17 Chapter 2: Jumpers and Connectors CPU Fan Connector ................17 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 3 Installing the DDR3 SODIMM ..............30 Installing a SATA Hard Drive ..............32 Installing a CompactFlash Card .............33 Installing a Wireless LAN Module ............35 Installing the SIM Card ................39 Installing the SATA DOM ...............40 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 4: Preface
Declaration of Conformity in any form or by any means without the prior written consent from EXOR International S.p.A. The product(s) described in this manual complies with all applicable Disclaimer European Union (CE) directives if it has a CE marking. -
Page 5: Rohs Compliance
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, EXOR has established an engineering and manufacturing task force in to implement the introduction of green products. -
Page 6: Warranty And Rma
(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, If RMA goods can not be repaired, EXOR will return it to the customer please note clearly which components are included. Otherwise, EXOR is without any charge. - Page 7 ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 8: Safety Information
There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. viii eCC104 User Manual... -
Page 9: Safety Precautions
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. 10. All cautions and warnings on the equipment should be noted. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 10: Technical Support And Assistance
Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of EXOR products, visit EXOR’s website Warning: at www.exorint.net. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2. -
Page 11: Package Contents
Preface Package Contents Before continuing, verify that the eCC104 package that you received is complete. Your package should have all the items listed in the following table. Item Description 2 Pin Phoenix Contact: (1777989), 5.08mm pitch FLAT HEAD SCREW LONG F3x5ISO+NYLOK NIGP... -
Page 12: Ordering Information
Preface Ordering Information The following provides ordering information for eCC104. • Barebone eCC104 - Intel® Atom™ Dual Core D2550 Fanless System Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 13: Chapter 1: Product Introduction
1x DVI-I & 1x HDMI display output Support 10-28V DC input Dual Intel® 82574L GbE LAN ports Supports ATX power mode, WoL, LAN teaming and PXE function 2x RS232/422/485 and 2x RS232 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 14: Hardware Specifications
1x DVI-I (support VGA & DVI-D display via cable) Certifications 1x 2-pin DC input, Support 9-36V DC input CE approval 1x external screwed type CFast socket Device 1x 2.5” HDD drive bay 1x External CFast Socket Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 15: Knowing Your Ecc104
Used to connect RS232 compatible devices. Empty antenna holes reserved for installing optional Mini-PCIe Wi-Fi mod- ule. COM2 and COM3 RS232/RS422/RS485 Used to connect RS232/422/485 compatible serial devices. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 16: Gigabit Lan Ports
Used to connect a digital LCD panel. Dual Gigabit LAN ports to connect the system to a local area network. HDMI CompactFlash Used to connect a high-definition display. Used to insert a CompactFlash card. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 17: Mechanical Dimensions
Chapter 1: Product Introduction Mechanical Dimensions 185.00 194.00 206.00 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 18: Chapter 2: Jumpers And Connectors
Chapter 2: Jumpers and Connectors 2: J HAPTER UMPERS AND ONNECTORS This chapter describes how to set the jumpers and connectors on the eCC104 dry environments. A grounding strap is warranted whenever danger of motherboard. static electricity exists. Before You Begin Precautions Ensure you have a stable, clean working environment. -
Page 19: Jumper Settings
Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off). Two-Pin Jumpers: Open (Left) and Short (Right) Three-Pin Jumpers: Pins 1 and 2 are Short Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 20: Locations Of The Jumpers And Connectors For Nisb104
Locations of the Jumpers and Connectors for NISB104 The figure below shows the location of the jumpers and connectors. Top View LAN2 LAN1 USB2 USB1 COM1 COM2 COM3 COM4 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 21: Bottom View
Chapter 2: Jumpers and Connectors Bottom View JP10 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 22: Locations Of The Jumpers And Connectors For Niskio2
Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors for NISKIO2 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 23: Nisb104
Connector location: JP6 Normal c l e a r (default) CMOS Settings Settings 1-2 On Normal 2-3 On Clear BIOS I_PWRBT# I_PWRBT# NOTE: 1-2 On: default PWRLED_N PWRLED_P Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 24: Com1 Serial Port
DCD1 RXD1 Definition Definition Definition TXD1 DTR1 SP2_DCD SP2_DATA- SP2_TX- DSR1 SP2_RXD SP2_DATA+ SP2_TX+ RTS1 CTS1 SP2_TXD SP2_RX+ SP2_DTR SP2_RX- SP2_DSR SP2_RTS- SP2_RTS SP2_RTS+ SP2_CTS SP2_CTS+ SP2_RI SP2_CTS- Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 25: Com3 Serial Port
DCD4 RXD4 Definition Definition Definition TXD4 DTR4 SP3_DCD SP3_DATA- SP3_TX- DSR4 SP3_RXD SP3_DATA+ SP3_TX+ RTS4 CTS4 SP3_TXD SP3_RX+ SP3_DTR SP3_RX- SP3_DSR SP3_RTS- SP3_RTS SP3_RTS+ SP3_CTS SP3_CTS+ SP3_RI SP3_CTS- Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 26: External I/O Interfaces - Rear Panel
Connector location: CN4A (DVI) and CN4B (VGA) Definition Definition Definition TX2+ VIN+ DDC_CLK DDC_DATA VSYNC_VGA TX1- TX1+ DVI_VCC(+5V) HotPlugDet TX0- TX0+ DDCCLK_VGA DDCDATA_VGA TXCLK+ TXCLK- GREEN BLUE HSYNC_VGA VGADET CHASSIS_GND CHASSIS_GND Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 27: Hdmi
Connector location: CN5 Connector location: USB1 Definition Definition Definition Definition HDMI_DATA2_P Data 0- HDMI_DATA2_N HDMI_DATA1_P Data 0+ HDMI_DATA1_N Data 1- Data 1+ HDMI_DATA0_P HDMI_DATA0_N HDMI_CLK_P HDMI_CLK_N HDMI_CTRL_CLK HDMI_CTRL_DATA HDMI_VCC5 HDMI_HPD_R Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 28: Usb2/3 Ports
Data 3- No link Data 3+ Status Flashing Yellow Data activity No activity Definition Definition LAN1_MDI0P LAN1_MDI0N LAN1_MDI1P LAN1_MDI1N LAN1TCT LAN1TCTG LAN1_MDI2P LAN1_MDI2N LAN1_MDI3P LAN1_MDI3N LAN1_LEDACT# LAN1_ACTPW LAN1_LINK LAN1_LINK1G# Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 29: Lan2 Port
No link Definition Status Flashing Yellow Data activity +12V No activity CPUFANIN(CPU_FAN_SPEED) CPUFANOUT(CPU_FAN_PWM) Definition Definition LAN2_MDI0P LAN2_MDI0N LAN2_MDI1P LAN2_MDI1N LAN2TCT LAN2TCTG LAN2_MDI2P LAN2_MDI2N LAN2_MDI3P LAN2_MDI3N LAN2_LEDACT# LAN2_ACTPW LAN2_LINK LAN2_LINK1G# Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 30: Dc Input/Output Connector
Connector type: 1x4 JST, 4-pin, 2.5mm pitch Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: CN2 Connector location: JP9 Definition Definition Definition Definition SIO_GPO24(Pin58) SIO_GPI20(Pin52) SIO_GPO25(Pin59) SIO_GPI21(Pin54) SIO_GPO26(Pin60) SIO_GPI22(Pin56) SIO_GPO27(Pin61) SIO_GPI23(Pin57) Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 31: Keyboard/Mouse Connector
Definition Definition KBMSVCC KBMSVCC LKBDAT LMDAT LKBCLK LMCLK Definition Definition VCC5 VCC5 I_USBN5 I_USBN4 I_USBP5 I_USBP4 I_USBOC#45 VCC3 HDD_LED_PWR POWER_LED_PWR HDD_LED_N PWR_LED_N CODEC_HDASYNC CODEC_HDASDO CODEC_HDARST# CODEC_HDABCLK I_SPKR I_HDASDI0 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 32: Pwr_Bt/Ret_Bt/Led/Sm Bus Pin Header
Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP8 Connector location: JP4 Definition Definition Definition PWR_LED_N PWR_LED_P LAN1_ACTPW SATA_LED# SATA_LED_P LAN1_LEDACT# SMB_C SMB_D LAN1_LINK1G# 3VSB LAN1_LINK PM_SLP_S3 PSON POWER BOTTOM RESET BOTTOM Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 33: Lan2 Led
Connector type: 2x2 4-pin header, 2.0mm pitch Connector type: 1x6 6-pin header, 2.0mm pitch Connector location: JP5 Connector location: J2 Definition LAN2_ACTPW LAN2_LEDACT# LAN2_LINK1G# LAN2_LINK Definition Definition Data 6- Data 6+ Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 34: Sata Connector
Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector type: 1x2 JST, 2-pin header, 2.5mm pitch Connector location: CN6 Connector location: J4 Definition Definition SATA_TXP0_C SATA_TXN0_C SATA_RXN0_C SATA_RXP0_C Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 35: Sim Card Connector
3.5G Line-out Pin Header Connector location: CN7 Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP2 Definition Definition Definition UIM_PWR UIM_RESET LOUT_RL UIM_CLK LOUT_RR UIM_VPP UIM_DATA ANGND Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 36: Cfast Con
Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: CN9 Connector location: JP3 Definition Definition Definition MIC_RL SATA_TXP1 MIC_RR SATA_TXN1 ANGND SATA_RXN1 SATA_RXP1 CFAST_ACCESS PC10 PC11 PC12 PC13 +3.3V PC14 +3.3V PC15 PC16 PC17 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 37: Mini-Pcie Slot
Definition Definition Definition Definition PCIEWAKE# +3VSB +1.5V SMBCLK +1.5V PCIETX0- SMBDATA CLKREQ# PCIETX0+ USB_D- REF CLK- USB_D+ REF CLK+ +3VSB +3VSB Disable# RST# +1.5V PCIERX0- +3VSB PCIERX0+ +3VSB Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 38: Niskio2
Connector location: JP1 Connector location: SPK1 Definition Definition Definition VCC5 VCC5 I_USBN4 I_USBN5 OUT_L I_USBP4 I_USBP5 EXLINEOUT_JD VCC3 I_USBOC#45 OUT_R POWER_LED_PWR HDD_LED_PWR PWR_LED_N HDD_LED_N CODEC_HDASDO CODEC_HDASYNC CODEC_HDABCLK CODEC_HDARST# I_HDASDI0 I_SPKR Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 39: Line-Out Internal Speaker
Connector type: 1x5 5-pin header, 2.0mm pitch Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP3 Connector location: JP2 Definition Definition FRONT_L+ FLIN_L FRONT_L- LIN_JD FRONT_R+ FLIN_R FRONT_R- Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 40: Usb1~ Usb2 Connector
Connector type: USB port, Type A Connector type: 3.5mm TRS Connector location: CN1 and CN2 Connector location: MIC1 Definition Definition AU_GND VCC5 MIC_OUT-L DATA_N AU_GN DATA_P MIC_JD1 MIC_OUT-R Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 41: Power Led/ Hdd Led
Chapter 2: Jumpers and Connectors Power LED/ HDD LED HDD Access LED Power Status LED Definition Green Yellow Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 42: Chapter 3: System Setup
1.With the bottom side of the chassis facing up, remove the mounting screws of the bottom cover and then put them in a safe place for later use. 2.Lift up the cover and remove it from the chassis. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 43 You will hear a distinctive “click” sound, indicating the module is The gold-plated connector on the edge of the module will almost completely correctly locked into position. disappear inside the socket. SODIMM SODIMM Clip Socket Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 44: Installing A Sata Hard Drive
Align the mounting holes of the SATA drive with the mounting holes on the cover. in place. SATA Drive Cover Inner Side of the Cover Outer Side of the Cover Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 45: Installing A Compactflash Card
1.The CompactFlash slot is located at the rear side of the chassis SATA Data/Power Cable SATA Drive CompactFlash Slot 4.Connect the SATA data/power cable to connectors CN6 and J4 on the motherboard respectively. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 46 2. Remove the mounting screws on the CompactFlash slot’s cover. 3. Remove the slot’s cover to access the CompactFlash slot. Mounting Screws CompactFlash Slot 4. Fasten the CompactFlash cover after installation. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 47: Installing A Wireless Lan Module
Wireless LAN Module Mini PCI Express Slot Mini PCI Express Slot Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 48 4.Remove the antenna hole covers located at the front panel of the chas- sis. Antenna Hole Covers Mounting Screws Note: If it is full-size module, please remove this bracket. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
- Page 49 5.Insert the antenna jacks into the antenna holes. 6.Insert the 2 rings (ring 1 and ring2) onto the antenna jacks Antenna Jack (with long cable) Antenna Jack (with short cable) Ring 1 Ring 2 Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
- Page 50 Chapter 3: System Setup 7.Attach RF cables of the antenna jacks onto the module. 8.Connect an external antenna to the antenna jack. RF Cables Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 51: Installing The Sim Card
Chapter 3: System Setup Installing the SIM Card 1.Slide the SIM card holder to the “OPEN” position. 2.Slide the SIM card into the SIM card holder. SIM Card Holder SIM Card Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 52: Installing The Sata Dom
3. Move the holder down and then slide it to the “LOCK” position. 1.Locate the SATA connector on the motherboard and remove the screw as marked. SATA Connector Screw Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 53 3.Install the SATA DOM and connect the SATA power cable to the SATA the screw hole. DOM connector on the motherboard. Screw Copper Post 4.Tighten a screw on the top of the copper post. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 54: Installing Wallmount Brackets
Secure with screws Wallmount Bracket Fasten screws to mount the system to the wall Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 55: Chapter 4: Bios Setup
HAPTER ETUP This chapter describes how to use the BIOS setup program for the eCC104. The settings made in the setup program affect how the computer per- The BIOS screens provided in this chapter are for reference only and may forms. -
Page 56: Default Configuration
When “ “ appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press <Enter>. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 57: Bios Setup Utility
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 58: Advanced
F4: Save & Exit F4: Save & Exit ESC: Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 59: Hyper-Threading
ESC: Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. This field is used to enable or disable hyper-threading. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 60: Execute Disable Bit
OS (Windows Server 2003 SP1, Windows XP SP2, SuSE F4: Save & Exit ESC: Exit Linux 9.2, RedHat Enterprise 3 Update 3). Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 61: Sata Controller(S)
This option configures the Serial ATA drives to use AHCI (Advanced AHCI Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 62: Super Io Configuration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. This field configures the maximum baud rate of the serial port 0, the options are 115200 bps and 921600 bps. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 63 This field is used to configure the mode of serial port 1 as RS232, RS422, This field configures the maximum baud rate of the serial port 1, the options RS485 or RS485 AUTO. are 115200 bps and 921600 bps. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
- Page 64 F4: Save & Exit F4: Save & Exit ESC: Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 65: Ppm Configuration
ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Setting incorrect field values may cause the system to malfunction. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 66: Host Bridge
Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 67: Intel Igd Configuration
Please refer to the following table for the display reference Intel IGD Confi guration Select the Video Device Which will be activated IGFX - Boot Type when a HDMI monitor is connected to eCC104. [DVI] during POST. Fixed Graphics Memory Size [128MB] This has no effect if external graphics present. - Page 68 This section disables Azalia or enables HD Audio. SMBus Controller This section is used to configure SMBus. High Precision Timer This section is used to configure High Precision Event Timer. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 69: Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. This field is used to configure the AC power state when power is restored after power failure, the options are Power Off and Power On. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 70: Interrupt 19 Capture
This field is used to adjust the boot sequence of the system. Boot Option #1 User Password is the first boot device that the system will boot from, next will be #2 and Sets the user’s password. so forth. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 71: Save & Exit
To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 72: Restore User Defaults
<Enter>. Launch EFI Shell from filesystem device To launch EFI shell from a filesystem device, select this field and press <Enter>. Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... -
Page 73: Appendix A: Gpi/O Programming Guide
IO base address : A00h This appendix provides definitions and its default setting for the Digital I/O Bit0 : GPI20 pins in the eCC104. The pin definition is shown is the following table: Bit1 : GP I21 Bit2 : GP I22... -
Page 74: Appendix B: Watchdog Timer
#Initial Watchdog Timer. Users can select second or minute. Step3. See “TimeCountWDT” procedure #Set Watchdog Timer Time-out Value. Users can set time-out value. Step4: See ExitSetup procedure #Exit Setup Environment Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual... - Page 75 ENDP al, 07h ;Select logical device for Watch Dog. =============================================== 2fh, al SetupWDT ENDP =============================================== TimeBaseWDT PROC al, 72h 2eh, al al, 10h ;Set WDT reset upon PWROK Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
-
Page 76: Appendix C: Power Consumption
Microsoft Wired Keyboard 600 Sys #1 Sys #1 Mouse Microsoft Basic Optical Mouse +12V +24V Full-Loading Mode 1.81A 0.96A Total 21.72W 23.04W Standby S1Mode 0.84A 0.45A Total 10.08W 10.8W Copyright © 2014 EXOR International S.p.A. All Rights Reserved. eCC104 User Manual...
