Summary of Contents for FUELCLOUD CloudLink V1.4

  • Page 1 CloudLink V1 4 Installation Manual Hardware Version 1.4 Manual Version 1.1 Revised 6/17/24...
  • Page 2 Physical installation cannot be completed without an online account.

 For help on the FuelCloud website, please see the Quick Setup Guide video on the dashboard. Get the installer...
  • Page 5 Board power fuse: .
 Pump control fuses:...
  • Page 9 Hazardous Area E amples: Classified areas adjacent to dispenser mounted on aboveground storage tank: 18 in. (0.5 m) 18 in. (0.5 m) Classified areas adjacent to dispensers: 18 in. (0.5 m) 18 in. (0.5 m)
  • Page 11 Get the installer app today...
  • Page 13 BEFORE IN TALLATION Identify Your Installation Location Ensure the following: • Line of sight to the CloudBox • Good LTE cellular coverage • Fueling within 75' of the CloudBox 75’+...
  • Page 14: Turn Power Off

    BEFORE IN TALLATION Turn Power Off Turn off all power to the pump at the breaker. BEFORE IN TALLATION Mount Attach the 4 included Mounting Brackets and screws to the CloudLink. Use any available fasteners to mount the CloudLink. Included with CloudLink (4x) 12.59"...
  • Page 15 RS-4 5 The CloudLink and CloudBox must be connected together through RS-485 in order to communicate. Both hardware units have 3 wiring terminals that must be connected to each other. A, B, and GND on the CloudLink need to be connected to A, B, and GND on the CloudBox.
  • Page 16 2+ CloudLink If more than 1 CloudLink is used, an identification (ID) board must be installed on all but the first CloudLink in the chain. Multiple CloudLinks are daisy chained to each other using the RS485 connection. The ID board connects directly to the CloudLink with arrows indicating which ID board connector to use.
  • Page 17 CloudBox 2 CloudBox 2 CloudLink #1 CloudLink #2 Shield To more CloudLinks The selector on the ID board must be set to 1 for the second CloudLink, 2 for the third, and so on.
  • Page 20 DC Powe DC Boa d Powe 12V DC+ DC + 12V DC- DC - INPUT Note: AC/DC switch only applies to fuel position 1. Fuel positions 2-5 can accept either AC or DC power.
  • Page 32 Revised 6/17/2 FuelCloud, Inc. 124 SW Dennis Ave Hillsboro, OR 97123...
