Summary of Contents for Colours AZ-1
- Page 1 Owners Manual AZ-1 Portable Hand Controls www.colourswheelchair.com 2061 Cecilia Circle Corona, CA 92881 800-892-8998 951-808-9131 951-808-9949 fax...
-
Page 2: Table Of Contents
Colours ‘N Motion, Inc. Table of Contents Page About the AZ-1 Portable Hand control AZ-1 Features Package Contents Safety Information Operator type and usage Installation Instructions Removing Instructions Operation Accessories Maintenance and Service Instructions 100% Money Back Guarantee Warranty Safety Information... -
Page 3: About The Az-1 Portable Hand Control
AZ-1 portable hand control. If you are unable to operate or have limited function this portable hand control is not for you!! The AZ-1 is for a portable application for periodic use. These controls are not for regular everyday use. -
Page 4: Package Contents
Package Contents Package contents will include the complete assembled portable hand control system. Note: when portable hand control is shipped it is adjusted to it narrowest adjustment. It is essential that you follow the assembly instructions that suit each individual driver. Contents are as follows:... -
Page 5: Safety Information
The AZ-1 is only recommended to be used on vehicles with an emergency brake that is accessible by hand. This is in the event that an emergency occurs and the AZ-1 fails and you must stop the vehicle with the vehicles emergency brake. Therefore when renting or operating a vehicle, be sure to verify that the car has a hand pull emergency brake. -
Page 6: Operator Type And Usage
Operator type and usage The AZ-1 is only produced for disabled drivers with strong hand function and good upper mobility. And the AZ-1 is for portable use. It is not recommended to use the AZ-1 for daily use while operating your everyday vehicle. - Page 7 DO NOT OPERATE THE VEHICLE with the AZ-1 portable hand controls. Test the brake with the vehicle in park before driving. If the AZ-1 cannot be adjusted to the proper length contact the company where you purchased and return for replacement immediately.
-
Page 8: Removing Instructions
Removing Instructions To remove the AZ-1 portable hand controls loosen (do not remove) the finger screws to slide the clamps over the pedals. If storing in a bag for travel it is not recommended to disassemble the AZ-1 portable hand control. To collapse for storage remove pins and slide the tubes to the smallest design. - Page 9 General • Always keep you left hand on the AZ-1 portable hand control. Do not remove your hand from the hand control unless the vehicle is safely positioned in park. • Never depress the accelerator while you are braking.
-
Page 10: Accessories
100% Money Back Guarantee Within 30 days if you are dissatisfied in any way we will happily refund the cost of the AZ-1 portable hand control in full less shipping. Must be returned in New, Original Condition to receive 100% money back. -
Page 11: Warning
You must have a valid drivers license to operate a vehicle. Caution If anything appears unsafe in the use of AZ-1 do not operate vehicle with the portable hand control system. Automobiles can cause death and or serious injury during operation. - Page 12 AAZ-1 Hand Control Assembly Instructions There are four parts in the box. STEP1- Insert A Into B and screw in and tighten properly. STEP2- Insert C Into D and screw in and tighten properly. STEP3- Remove pin on B and insert into D top of opening and adjust to desired length. Then install pin. *Note: Make sure to secure and tighten all nuts and bolts properly before use.
- Page 13 Address ___________________________________________________________________ City ___________________ State/Province ___ Zip __________ Country _______________ Phone ______________________________ Fax __________________________________ Email address ______________________________________________________________ Disability _______________________________ Age_____ Male/Female________________ How did you find out about the AZ-1 Portable Hand Controls __________________________ __________________________________________________________________________ Comments (over if nec.): ______________________________________________________ __________________________________________________________________________...
- Page 14 __________________________________________________________________________...
